The MINMAX MAU400 series is a range of 1W DC/DC converter modules providing a high I/O-isolation voltage of 3000VAC in a small SIP-package. There
are 12 models available for 5VDC or 12VDC input voltage and single- or dual-output voltage.
This product offers an economical solution for many applications in industrial controls and Instrumentation, consumer electronics and everywhere where a
certified supplementary or reinforced insulation system is required to comply with relative safety standards.
Model Selection Guide
Model
Number
Input
Voltage
(Range)
VDC
Output
Voltage
VDC
5
12
15
±5
±12
±15
5
12
15
±5
±12
±15
Output Current
Max.
Min.
mA
4
2
1
±2
±1
±1
4
2
1
±2
±1
±1
Input Current
@Max. Load
mA(typ.)
303
291
295
303
267
287
126
121
123
126
108
117
@No Load
mA(typ.)
Load
Regulation
% (max.)
10
8
8
10
8
8
10
8
8
10
8
8
Max. capacitive
Load
µF
680
220#
680
220#
# For each output
Max.
5.5
13.2
9
29
0.3
650
MAU401
MAU402
MAU403
MAU404
MAU405
MAU406
MAU411
MAU412
MAU413
MAU414
MAU415
MAU416
5
(4.5 ~ 5.5)
12
(10.8 ~ 13.2)
mA
200
80
65
±100
±40
±35
200
80
65
±100
±40
±35
@Max. Load
%
66
66
66
66
72
73
66
66
66
66
74
75
Efficiency
(typ.)
55
30
Input Specifications
Input Voltage Range
Parameter
Input Surge Voltage (1 sec. max.)
Reverse Polarity Input Current
Internal Filter Type
Internal Power Dissipation
Model
5V Input Models
12V Input Models
5V Input Models
12V Input Models
All Models
Min.
4.5
10.8
-0.7
-0.7
---
---
Min.
---
---
---
---
---
Typ.
5
12
---
---
---
---
Unit
VDC
A
mW
Unit
%
%
%
mV
P-P
%/℃
LC Filter
Output Specifications
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise
Temperature Coefficient
Short Circuit Protection
Conditions
Dual Output, Balanced Loads
For Vin Change of 1%
Io=20% to 100%
max. 20MHz Bandwidth
Typ.
Max.
±1.0
±3.0
±0.1
±1.0
±1.2
±1.5
See Model Selection Guide
100
150
±0.01
±0.02
0.5 Second Max.
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2013/01/24 REV:10
Page 1 of 4
DC/DC CONVERTER 1W,
Reinforced Insulation, Medical Safety
MAU400 SERIES
Isolation, Safety Standards
I/O Isolation Voltage (rated)
I/O Isolation Test Voltage
I/O Isolation Resistance
Parameter
Flash tested for 1 Second
100KHz, 1V
500 VDC
60 Seconds
Conditions
4500
10
3000
Min.
Typ.
---
---
Max.
---
---
VACrms
G
V
PK
pF
Unit
I/O Isolation Capacitance
Safety Standards
Approvals
---
15
cUL/UL60950-1, CSA C22.2 No. 60950-1-03
UL60601-1,CSA C22.2 No.601-1
IEC/EN 60950-1, IEC/EN 60601-1
IEC60950-1 CB report, cUL/UL 60950-1 certificate
UL60601-1 UL certificate
---
20
---
General Specifications
Switching Frequency
MTBF (calculated)
Parameter
Conditions
MIL-HDBK-217F@25℃, Ground Benign
Min.
2,000,000
50
Typ.
80
---
Max.
100
---
Hours
KHz
Unit
Input Fuse
500mA Slow-Blow Type
5V Input Models
200mA Slow-Blow Type
12V Input Models
Environmental Specifications
Case Temperature
Operating Ambient Temperature Range (See Power Derating Curve)
Storage Temperature Range
Humidity (non condensing)
Cooling
Parameter
Conditions
Ambient
Min.
-25
---
---
Max.
+90
95
+85
Unit
℃
℃
% rel. H
℃
℃
-50
Free-Air convection
---
+125
Lead Temperature (1.5mm from case for 10Sec.)
260
Power Derating Curve
Notes
1
2
3
4
5
6
7
Specifications typical at Ta=+25℃, resistive load, nominal input voltage and rated output current unless otherwise noted.
Ripple & Noise measurement bandwidth is 0-20MHz.
These power converters require a minimum output loading to maintain specified regulation, operation under no-load conditions will not damage these
modules; however they may not meet all specifications listed.
All DC/DC converters should be externally fused at the front end for protection.
Other input and output voltage may be available, please contact factory.
That “natural convection” is about 20LFM but is not equal to still air (0 LFM).
Specifications are subject to change without notice.
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2013/01/24 REV:10
Page 2 of 4
Output Power (%)
DC/DC CONVERTER 1W,
Reinforced Insulation, Medical Safety
MAU400 SERIES
Package Specifications
Mechanical Dimensions
22.0 [0.87]
Pin Connections
Pin
1
2
0.5 [0.02]
12.5 [0.49]
Single Output
+Vin
-Vin
Dual Output
+Vin
-Vin
5
6
[0.13]
7
No Pin
+Vout
-Vout
Common
+Vout
-Vout
0.5
[0.02]
3.5
[0.14]
2.54
[0.10]
7.62
[0.30]
2X2.54
[2X0.10]
21.0 [0.83]
7.5 [0.30]
Bottom View
1
2
5
6
7
3.2
►All
dimensions in mm (inches)
►Tolerance:
X.X±0.25 (X.XX±0.01)
►Pins
±0.05 (±0.002)
Physical Characteristics
Case Size
:
Case Material
Pin Material
Weight
:
:
:
22.0x7.5x12.5mm (0.87x0.30x0.49 inches)
Non-Conductive Black Plastic (flammability to UL 94V-0 rated)
Alloy 42
3.9g
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2013/01/24 REV:10
Page 3 of 4
2.0 [0.08]
0.50
[0.02]
0.25 [0.01]
X.XX±0.13 ( X.XXX±0.005)
DC/DC CONVERTER 1W,
Reinforced Insulation, Medical Safety
MAU400 SERIES
Peak-to-Peak Output Noise Measurement Test
Use a Cout 0.33µF ceramic capacitor. Scope measurement should be made by using a BNC socket, measurement bandwidth is 0-20 MHz. Position the load between
50 mm and 75 mm from the DC/DC Converter.
+Vin
Single Output
DC / DC
Converter
-Vin
-Out
+Out
Copper Strip
Cout
Copper Strip
Resistive
Scope
Load
+Vin
Dual Output
DC / DC
Converter
-Vin
+Out
Com.
-Out
Copper Strip
Cout
Copper Strip
Cout
Copper Strip
Scope
Scope
Resistive
Load
Test Setup
Technical Notes
Maximum Capacitive Load
The MAU400 series has limitation of maximum connected capacitance at the output. The power module may be operated in current limiting mode during start-up,
affecting the ramp-up and the startup time. For optimum performance we recommend 220µF maximum capacitive load for dual outputs and 680µF capacitive load for
single outputs. The maximum capacitance can be found in the data sheet.
Input Source Impedance
The power module should be connected to a low ac-impedance input source. Highly inductive source impedances can affect the stability of the power module. In
applications where power is supplied over long lines and output loading is high, it may be necessary to use a capacitor at the input to ensure startup.
Capacitor mounted close to the power module helps ensure stability of the unit, it is recommended to use a good quality low Equivalent Series Resistance (ESR < 1.0
Ω
at 100 KHz) capacitor of a 2.2µF for the 5V input devices, a 1.0µF for the 12V input devices.
+
DC Power
Source
-
+
Cin
-Vin
-Out
+Vin
DC / DC
Converter
+Out
Load
Output Ripple Reduction
A good quality low ESR capacitor placed as close as practicable across the load will give the best ripple and noise performance. To reduce output ripple, it is
recommended to use 1.5µF capacitors at the output.
+
DC Power
Source
-
-Vin
+Vin
Single Output
DC / DC
Converter
-Out
+Out
+
DC Power
Source
-
+Vin
+Out
Dual Output
DC / DC Com.
Converter
Cout
Cout
Load
Load
Cout
Load
-Vin
-Out
Thermal Considerations
Many conditions affect the thermal performance of the power module, such as orientation, airflow over the module and board spacing. To avoid exceeding the
maximum temperature rating of the components inside the power module, the case temperature must be kept below 90℃. The derating curves are determined from
measurements obtained in a test setup.
Position of air velocity
probe and thermocouple
15mm / 0.6in
Air Flow
50mm / 2in
DUT
