MAW01 SERIES
DC/DC CONVERTER 1W,
SIP-Package
FEATURES
►Compact
SIP-6 Package
►Small
Footprint:17 x 11 mm (0.67”x0.43”)
►Wide
2:1 lnput Range
►Fully
regulated Outputs
►Low
Ripple and Noise
►Operating
Temp. Range -40°C to +85°C
►I/O-isolation
Voltage 1500VDC
►Continuous
Short-circuit Protection
►Fully
RoHS compliant
►CSA/UL/IEC/EN
60950-1 (Approval pending)
►
3 Years Product Warranty
PRODUCT OVERVIEW
The MINMAX MAW01 series is a range of isolated 1W dc/dc-converter modules featuring fully regulated output and wide 2:1 input voltage ranges.
This product comes in a very small SIP-6 package occupying only 1.2cm
2
(0.2 square inch) on the PCB.
A high efficiency allow operating an operating temperature range of -40°C to +85°C without Derating.
The very compact dimensions makes these converters an ideal solution for many space critical applications in battery powered instrumentations.
Model Selection Guide
Model
Number
Input
Voltage
(Range)
VDC
MAW01-05S05
MAW01-05S12
MAW01-05S15
MAW01-05S24
MAW01-05D12
MAW01-05D15
MAW01-12S05
MAW01-12S12
MAW01-12S15
MAW01-12S24
MAW01-12D12
MAW01-12D15
MAW01-24S05
MAW01-24S12
MAW01-24S15
MAW01-24S24
MAW01-24D12
MAW01-24D15
MAW01-48S05
MAW01-48S12
MAW01-48S15
MAW01-48S24
MAW01-48D12
MAW01-48D15
VDC
5
12
15
24
±12
±15
5
12
15
24
±12
±15
5
12
15
24
±12
±15
5
12
15
24
±12
±15
Output
Voltage
Max.
mA
200
83
67
42
±42
±33
200
83
67
42
±42
±33
200
83
67
42
±42
±33
200
83
67
42
±42
±33
@Max. Load
mA(typ.)
263
259
254
265
262
254
108
108
105
109
106
106
54
52
52
55
53
52
27
27
27
28
27
26
@No Load
mA(typ.)
μF
1680
820
680
470
470#
330#
1680
820
680
470
470#
330#
1680
820
680
470
470#
330#
1680
820
680
470
470#
330#
# For each output
Output Current
Input Current
Max. capacitive
Load
Reflected
Ripple
current
mA (typ.)
Efficiency
(typ.)
@Max. Load
%
76
77
79
76
77
78
77
77
80
77
79
78
77
80
80
77
80
80
77
78
78
76
79
79
5
(4.5 ~ 9)
40
80
12
(9 ~ 18)
20
40
24
(18 ~ 36)
10
30
48
(36 ~ 75)
7
20
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2012/10/31 REV:1
Page 1 of 4
®
MAW01 SERIES
DC/DC CONVERTER 1W,
SIP-Package
Input Specifications
Parameter
Model
5V Input Models
Input Surge Voltage (1 sec. max.)
12V Input Models
24V Input Models
48V Input Models
5V Input Models
Start-Up Threshold Voltage
12V Input Models
24V Input Models
48V Input Models
Internal Filter Type
All Models
Min.
-0.7
-0.7
-0.7
-0.7
---
---
---
---
Typ.
---
---
---
---
---
---
---
---
Capacitor
Max.
15
25
50
100
4.5
9
18
36
VDC
Unit
Output Specifications
Parameter
Output Voltage Setting Accuracy
Line Regulation
Load Regulation
Conditions
Min.
At 50% Load and Nominal Vin
---
---
Vin=Min. to Max.
---
Single Output Models
No Load to Full Load
---
Dual Output Models
---
Single Output Models
10% to 90% Load
---
Dual Output Models
No minimum Load Requirement
---
25% Load Step Change
---
---
Continuous
Typ.
---
---
---
---
---
---
50
250
---
Max.
±1.0
±0.2
±1.0
±1.0
±0.5
±0.8
---
---
±0.02
Unit
%Vnom.
%
%
%
%
%
mV
P-P
μsec
%/℃
Min.Load
Ripple & Noise (20MHz)
Transient Recovery Time
Temperature Coefficient
Short Circuit Protection
General Specifications
Parameter
I/O Isolation Voltage (rated)
I/O Isolation Resistance
I/O Isolation Capacitance
Switching Frequency
MTBF(calculated)
Safety Approvals(pending)
MIL-HDBK-217F@25℃, Ground Benign
Conditions
60 Seconds
500 VDC
100KHz, 1V
Min.
1500
1000
---
---
2,800,000
Typ.
---
---
---
220
---
Max.
---
---
50
---
---
Unit
VDC
MΩ
pF
KHz
Hours
CSA 60950-1 recognition,IEC/EN 60950-1(CB-scheme)
Input Fuse
5V Input Models
500mA Slow-Blow Type
12V Input Models
250mA Slow-Blow Type
24V Input Models
120mA Slow-Blow Type
48V Input Models
60mA Slow-Blow Type
Environmental Specifications
Parameter
Operating Ambient Temperature Range (See Power Derating Curve)
Case Temperature
Storage Temperature
Humidity (non condensing)
Lead Temperature (1.5mm from case for 10Sec.)
Conditions
Natural Convection
Min.
-40
---
-55
---
---
Max.
+85
+105
+125
95
260
Unit
℃
℃
℃
% rel. H
℃
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2012/10/31 REV:1
Page 2 of 4
®
Test Setup
MAW01 SERIES
DC/DC CONVERTER 1W,
SIP-Package
Input Reflected-Ripple Current Test Setup
Input reflected-ripple current is measured with a inductor Lin (4.7μH) and Cin (220μF, ESR < 1.0Ω at 100 KHz) to simulate source impedance.
Capacitor Cin, offsets possible battery impedance. Current ripple is measured at the input terminals of the module, measurement bandwidth is 0-500 KHz.
To Oscilloscope
+
Battery
+
Lin
Current
Probe
+Vin
+Out
Load
DC / DC
Converter
-Vin
-Out
Cin
Peak-to-Peak Output Noise Measurement Test
Use a Cout 0.47μF ceramic capacitor. Scope measurement should be made by using a BNC socket, measurement bandwidth is 0-20 MHz. Position the load between
50 mm and 75 mm from the DC/DC Converter.
+Vin
Single Output
DC / DC
Converter
-Vin
-Out
+Out
Copper Strip
Cout
Copper Strip
Resistive
Scope
Load
+Vin
Dual Output
DC / DC
Converter
-Vin
+Out
Com.
-Out
Copper Strip
Cout
Copper Strip
Cout
Copper Strip
Scope
Scope
Resistive
Load
Technical Notes
Maximum Capacitive Load
The MAW01 series has limitation of maximum connected capacitance at the output. The power module may be operated in current limiting mode during start-up,
affecting the ramp-up and the startup time. The maximum capacitance can be found in the data sheet.
Overcurrent Protection
To provide protection in a fault (output overload) condition, the unit is equipped with internal current limiting circuitry and can endure current limiting for an unlimited
duration. At the point of current-limit inception, the unit shifts from voltage control to current control. The unit operates normally once the output current is brought back
into its specified range.
Input Source Impedance
The power module should be connected to a low ac-impedance input source. Highly inductive source impedances can affect the stability of the power module. In
applications where power is supplied over long lines and output loading is high, it may be necessary to use a capacitor at the input to ensure startup.
Capacitor mounted close to the power module helps ensure stability of the unit, it is commended to use a good quality low Equivalent Series Resistance (ESR < 1.0Ω
at 100 KHz) capacitor of a 8.2μF for the 5V input device, a 3.3μF for the 12V input devices and a 1.5μF for the 24V and 48V devices.
+
DC Power
Source
-
+
Cin
-Vin
-Out
+Vin
DC / DC
Converter
+Out
Load
Output Ripple Reduction
A good quality low ESR capacitor placed as close as practicable across the load will give the best ripple and noise performance. To reduce output ripple, it is
recommended to use 3.3μF capacitors at the output.
+
DC Power
Source
-
-Vin
+Vin
Single Output
DC / DC
Converter
-Out
+Out
+
DC Power
Source
-
+Vin
+Out
Dual Output
DC / DC
Com.
Converter
Cout
Cout
Load
Load
Cout
Load
-Vin
-Out
Thermal Considerations
Many conditions affect the thermal performance of the power module, such as orientation, airflow over the module and board spacing. To avoid exceeding the
maximum temperature rating of the components inside the power module, the case temperature must be kept below 105℃. The derating curves are determined from
measurements obtained in a test setup.
Position of air velocity
probe and thermocouple
15mm / 0.6in
50mm / 2in
Air Flow
DUT
18, Sin Sin Road, An-Ping Industrial District, Tainan 702, Taiwan
Tel: 886-6-2923150 Fax: 886-6-2923149 E-mail:
sales@minmax.com.tw
Minmax Technology Co., Ltd.
2012/10/31 REV:1
Page 4 of 4
