MHL
multilayer ceramic inductor
features
•
Monolithic structure provides high reliability
in a wide temperature and humidity range
•
High quality ceramic material and unique manufacturing
process provides high Q at high frequency
•
Standard EIA packages: 1E, 1J
•
Nickel barrier with solder overcoat for excellent
solderability
•
Marking: Brown body color with no marking (1E)
White body color with with black stripe
and no marking (1J)
•
Products with lead-free terminations meet
RoHS requirements
dimensions and construction
W
L
Solder
Plating
Ni
Plating
Silver
Metallization
d
Size
Code
1E
(0402)
1J
(0603)
L
.039±.004
(1.0±0.1)
.063±.006
(1.6±0.15)
Dimensions
inches
(mm)
W
t
.02±.004
(0.5±0.1)
.031±.006
(0.8±0.15)
.02±.004
(0.5±0.1)
.031±.006
(0.8±0.15)
d
.01±.004
(0.25±0.1)
.012±.008
(0.30±0.2)
t
Terminations
(Metallization
Bands)
d
Electrodes
ordering information
New Part #
MHL
Type
1E
Size
Code
1E
1J
C
Material
Permeability
Code:
C
T
T
Termination
Material
T: Sn
(Other termination
styles available,
contact factory
for options)
TE
Packaging
TP: 7" paper tape 2 mm pitch
(1E only - 10,000 pieces/reel)
TD: 7" paper tape
(1J - 4,000 pieces/reel)
TE: 7" embossed plastic
TEB: 13" embossed plastic
(1J - 12,000 pieces/reel
3N9
Nominal
Inductance
3N9 = 3.9nH
R10 = 100nH
S
Tolerance
S: ±0.3nH
J: ±5%
For further information on packaging,
please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
1/10/06
KOA Speer Electronics, Inc.
• Bolivar Drive • P Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
.O.
199
inductors
MHL
multilayer ceramic inductor
applications and ratings
Part
Designation
MHL1ECTTP1N0*
MHL1ECTTP1N2*
MHL1ECTTP1N5*
MHL1ECTTP1N8*
MHL1ECTTP2N2*
MHL1ECTTP2N7*
MHL1ECTTP3N3*
MHL1ECTTP3N9*
MHL1ECTTP4N7*
MHL1ECTTP5N6*
MHL1ECTTP6N8*
MHL1ECTTP8N2*
MHL1ECTTP10N*
MHL1ECTTP12N*
MHL1ECTTP15N*
MHL1ECTTP18N*
MHL1ECTTP22N*
MHL1ECTTP27N*
MHL1ECTTP33N*
MHL1ECTTP39N*
MHL1ECTTP47N*
MHL1ECTTP56N*
MHL1ECTTP68N*
MHL1ECTTP82N*
MHL1ECTTPR10*
MHL1ECTTPR12*
MHL1JCTTD1N5*
MHL1JCTTD1N8*
MHL1JCTTD2N2*
MHL1JCTTD2N7*
MHL1JCTTD3N3*
MHL1JCTTD3N9*
MHL1JCTTD4N7*
MHL1JCTTD5N6*
MHL1JCTTD6N8*
MHL1JCTTD8N2*
MHL1JCTTD10N*
MHL1JCTTD12N*
MHL1JCTTD15N*
MHL1JCTTD18N*
MHL1JCTTD22N*
MHL1JCTTD27N*
MHL1JTTTD27N*
MHL1JCTTD33N*
Inductance
L (nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
27
33
Inductance
Tolerance
Self Resonant
Frequency
Minimum Typical Typical
Typical
(100MHz) (100MHz) (800MHz)
(MHz)
37
10000
36
Q
DC
Resistance
Maximum
(Ω)
0.12
0.13
0.14
0.16
0.17
0.19
0.22
0.24
0.27
0.32
0.37
0.42
0.50
0.55
0.65
0.8
0.9
1.0
1.2
1.3
1.4
Allowable
DC Current
Maximum
(mA)
Operating
Temperature
Range
S: ±0.3nH
34
6000
4000
32
11
8
31
3900
3500
3200
2600
2300
2000
1600
1400
1200
1100
900
750
300
inductors
NEW
-55°C
to
+125°C
30
J: ±5%
28
26
24
23
21
19
16
––
––
200
10
180
150
100
600
1.6
0.10
S: ±0.3nH
14
6000
0.13
0.15
0.20
0.23
0.20
0.28
0.30
0.35
0.40
0.45
0.50
0.55
0.60
500
100
8
4000
46
5800
3200
2600
2300
2000
1600
1400
1200
-55°C
to
+125°C
15
J: ±5%
12
10
18
15
600
*Add tolerance character (S, J)
For complete environmental specifications,
please refer to pages 202-203.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
8/28/06
200
KOA Speer Electronics, Inc.
• Bolivar Drive • P Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
.O.
MHL
multilayer ceramic inductor
applications and ratings
(continued)
Part
Designation
MHL1JCTTD39N*
MHL1JTTTD39N*
MHL1JCTTD47N*
MHL1JCTTD56N*
MHL1JCTTD68N*
MHL1JCTTD82N*
MHL1JCTTDR10*
MHL1JCTTDR12*
MHL1JCTTDR15*
MHL1JCTTDR18*
MHL1JCTTDR22*
Inductance
L (nH)
39
39
47
56
68
82
100
120
150
180
220
Inductance
Tolerance
Self Resonant
Frequency
Minimum Typical Typical
Typical
(100MHz) (100MHz) (800MHz)
(MHz)
Q
15
17
12
J: ±5%
15
46
39
37
36
29
16
8
13
1100
900
700
600
500
400
DC
Resistance
Maximum
(Ω)
0.65
0.70
0.75
0.80
0.85
0.90
1.0
1.2
1.3
1.5
500
400
Allowable
DC Current
Maximum
(mA)
Operating
Temperature
Range
-55°C
to
+125°C
300
inductors
1/09/06
—
*Add tolerance character (S, J)
For complete environmental specifications,
please refer to pages 202-203.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
KOA Speer Electronics, Inc.
• Bolivar Drive • P Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
.O.
