MC100LVEL12DR2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> MC100LVEL12DR2

MC100LVEL12DR2: Description100LVEL SERIES, 2-INPUT OR/NOR GATE, PDSO8, SOIC-8; Categorylogic logic; File Size819KB，8 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

MC100LVEL12DR2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MC100LVEL12DR2	-	-	View	Buy Now

MC100LVEL12DR2 Overview

100LVEL SERIES, 2-INPUT OR/NOR GATE, PDSO8, SOIC-8

MC100LVEL12DR2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	SOIC-8
Contacts	8
Reach Compliance Code	unknown
Other features	NECL MODE: VCC = 0V WITH VEE = -3.0V TO -3.8V
series	100LVEL
JESD-30 code	R-PDSO-G8
JESD-609 code	e0
length	4.9 mm
Logic integrated circuit type	OR/NOR GATE
Humidity sensitivity level	NOT SPECIFIED
Number of functions	1
Number of entries	2
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output characteristics	OPEN-EMITTER
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	240
propagation delay (tpd)	0.58 ns
Certification status	COMMERCIAL
Maximum seat height	1.75 mm
Maximum supply voltage (Vsup)	3.8 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	ECL
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
width	3.9 mm
