HIGH-CURRENT MULTILAYER FERRITE CHIP BEAD
ACML-0402H
STANDARD SPECIFICATIONS - continued:
Part No .
ACML-0402H-421
ACML-0402H-481
ACML-0402H-601
ACML-0402H-102
ACML-0402H-152
ACML-0402H-182
RoHS
Compliant
1.0 x 0.5 x 0.5mm
| | | | | | | | | | | | | |
|
Impedanc e
(Ω) ±25%
420
480
600
1000
1500
1800
Te s t Fre q.
(MHZ)
100 MHZ,200 mV
100 MHZ,200 mV
100 MHZ,200 mV
100 MHZ,200 mV
100 MHZ,200 mV
100 MHZ,200 mV
RDC
(Ω)Max.
0.5
0.5
0.6
0.95
1.15
1.4
Rated
Curre nt
(mA)Max.
300
300
300
200
100
100
Ir: Rate Current. Applied the current to coils , the temp erature ris e s hall not be more than 30
S tand ard Tes ting Condi tio n
Te mpe ra ture
Humidity
Unless o therwise s pec ifie d
Ordina ry Te mpe ra ture (15 to 35 )
Ordina ry Humidity(25 to 85% RH)
In case o f doub t
20 ±2
60 to 70 % RH
OPTIONS AND PART IDENTIFICATION
ACML-0402H-
Induc tance Co de
P lea se re fe r to the
tab le on Page 2
Tole ran ce
N: ±30 %
-
Pa ckag ing
Blan k: Bulk
T: Tape and Ree l
REFLOW PROFILE
Ite m
Te mp. sc ope
Time s pe c.
Ramp-up
R.T. ~ 150°C
--
Pre -hea ting
15 0°C ~ 200 °C
60 ~ 180 s e c
Re flo w
217 °C
60 ~ 150 s e c
Pea k Te mp.
260 5°C
20 ~ 40 s e c
Cooling
P e a k Te mp. ~ 150 °C
--
ABRACON IS
ISO9001:2008
CE RTIFIED
Revised: 06.01.12
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000| fax 949-546-800
| www.abracon.com
1
Visit www.abracon.com for Terms & Conditions of Sale
HIGH CURRENT MULTILAYER FERRITE CHIP BEAD
ACML-0402H
OUTLINE DRAWING:
Rec o mm e nd e d Land Patte rn
RoHS
Compliant
1.0 x 0.5 x 0.5mm
| | | | | | | | | | | | | |
|
Tape and reel 10,000 pcs/reel
A
B
C
D
1.00±0.1 0.5±0.1 0.5±0.1 0.25±0.1
A
0.4
B
1.2~1.4
C
0.5
Dimen s ion : mm
TAPE & REEL:
T= tape and reel (10,000pcs/reel)
A
0.65
B
1.15
T
0.60
W
8
P
2
F
3.5
A
178
B
60
C
10
D
2
Dimension : mm
ATTENTION:
Abracon Corporation’s products are COTS – Commercial-Off-The-Shelf products; suitable for Commercial, Industrial and, where designated, Automotive Applications. Abracon’s
products are not specifically designed for Military, Aviation, Aerospace, Life-dependant Medical applications or any application requiring high reliability where component failure could result in loss
of life and/or property. For applications requiring high reliability and/or presenting an extreme operating environment, written consent and authorization from Abracon Corporation is required.
Please contact Abracon Corporation for more information.
ABRACON IS
ISO9001:2008
CE RTIFIED
Revised: 06.01.12
