MW116
MEDICAL 60-90 WATT SERIES
#3 Connector pictured
MW116 SWITCH-MODE
P O W E R S U P P LY
•
•
•
•
•
•
•
•
•
•
•
MW116
Ault Part No.
Voltage
DC
Max
Amps
Max
Watts
100-240 VAC Universal Input
Desktop Style
Single Output to 90W
Regulated Output With Low Ripple
Meets Medical Safety Agency Requirements
Complies With EMI/RFI Regulations
CE Compliant
Impact Resistant Polycarbonate Enclosure
Private Label Marking Available
3 Year Warranty
Modified and Custom Designs Also Available
MW116XA05XX_01
MW116XA06XX_01
MW116XA09XX_01
MW116XA12XX_01
MW116XA14XX_01
MW116XA15XX_01
MW116XA16XX_01
MW116XA18XX_01
MW116XA24XX_01
MW116XA48XX_01
5V
6V
9V
12V
13.5V
15V
16V
18V
24V
48V
12.0
10.0
7.80
6.67
6.15
6.00
5.60
5.00
3.75
1.87
60.0
60.0
70.0
80.0
83.0
90.0
90.0
90.0
90.0
90.0
Ault Part No. Key
MW116 X
Product
Family
Name
Manufacturing
Location
(volume
dependent)
A
Design
Revision
Changes
05
Voltage
DC
XX
Connector
#51 - Standard
16V and
under; #3 -
Standard 18V
and over
__
Input
Configuration/
Model Type
(see pg. 2)
01
Denotes
standard
or custom
requirements
A U LT I N C O R P O R AT E D
7105 Northland Terrace
|
Minneapolis, Minnesota 55428
|
USATEL (1) 763-592-1900
FAX (1) 763-592-1911
|
E-MAIL info@aultinc.com
|
WEB www.aultinc.com
© Copyright 2005 Ault Inc.
MW116
MEDICAL 60-90 WATT SERIES
Input
Voltage
Line Frequency
Current
Protection
Power Factor Correction
100-240 VAC -10%, +10%
47 - 63 Hz
2.0A max. at 90 VAC input
Internal primary current fuse,
Inrush limiting
Complies with EN61000-3-2 and
EN61000-3-3
Environmental
Output
Combined Line and Load
Voltage Regulation
Ripple
Transient Response
Holdup Time
Protection
Cord and Connector
±1% excluding cord
1% V p-p max
0.5 msec. for 50% load change typical
16 msec min. over entire input range
Foldback overcurrent protection
Short circuit protection
5V and 6V:
6 ft, 6 conductor, 18 AWG,
Ault #51 connector. Pinout: Pins 1, 2, 3 =
+V; 4, 5 and 6 = common.
9V, 12V, 13.5V,
15V, 16V:
6 ft, 4 conductor, 18 AWG,
Ault #51 connector. Pinout: Pins 1,4=+V;
3,6=common. All with overmolded
Ferrite core.
18V, 24V, 48V,:
6 ft, 2 con-
ductor, 18 AWG with overmolded Ferrite
core, Ault #3 connector, center positive.
Mechanical
Case and Dimensions
Case Material
5.08L x 3.05W x 1.67H (in)
129L x 77W x 40H (mm)
94V0 polycarbonate; black is standard
color; other colors available - extra
charges may apply
13 ounces, 370 grams
(excluding cord)
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
Cooling
0º to 40º C with no derating
-30º to +85º C
5% to 95% non-condensing
0-10,000 feet
Convectional - non vented case
Electrical
Topology
Efficiency
EMI
CE
MTBF
Switching - Fixed frequency 100KHz
Up to 89%
Complies with EMC Directives
CE Compliant
100,000 Calculated Hours Minimum
Weight
Safety Approvals
Agency Listings
TUV EN60601-1; cURus 2601;
Australian, Japanese certification
available - extra fees apply
Input Configuration
Connector
IEC320
w/ground
C14
(F)
IEC320
w/o ground
C18
(Q)
In case IEC320 type: F=Class I C14 inlet Q=Class II C18 inlet
Specify the Input Configuration Code in your order.
A U LT I N C O R P O R AT E D
7105 Northland Terrace
|
Minneapolis, Minnesota 55428
|
USATEL (1) 763-592-1900
FAX (1) 763-592-1911
|
E-MAIL info@aultinc.com
|
WEB www.aultinc.com
© Copyright 2005 Ault Inc.
