SMA Female to TNC Female Bulkhead Adapter
TECHNICAL DATA SHEET
SMA Female to TNC Female Bulkhead Adapter
Configuration
Connector 1
Connector Specification 1
Connector 2
Connector Specification 2
Adapter Design
Body Style
Mount Method
SMA Female
MIL-STD-348A
TNC Female
MIL-STD-348A
Standard
Straight
Bulkhead
PE9251
Electrical Specifications
Frequency Range, GHz
Impedance, Ohms
Maximum VSWR
Maximum Operating Voltage, Volts
Dielectric Withstanding Voltage, Vrms
DC to 11
50
1.3:1
500
1,000
Mechanical Specifications
Temperature
Operating Range,deg C
Size
Length, in [mm]
Width/Dia., in [mm]
.
-65 to +165
1.3 [33.02]
0.655 [16.64]
Teflon
SMA Female
Beryllium Copper, Gold
50µ in. minimum
100µ in. minimum
Brass, Nickel
TNC Female
Beryllium Copper, Gold
30µ in. minimum
Brass, Nickel
100µ in. minimum
Dielectric Type
Connector 1
Type
Inner Conductor Material and Plating
Inner Conductor Plating Specification
Coupling Nut Plating Specification
Body Material and Plating
Connector 2
Type
Inner Conductor Material and Plating
Inner Conductor Plating Specification
Body Material and Plating
Body Plating Specification
Compliance Certifications
(visit www.Pasternack.com for current document)
RoHS Compliant
Yes
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications:
SMA Female to TNC Female Bulkhead Adapter PE9251
PE9251 REV
1
SMA Female to TNC Female Bulkhead Adapter
TECHNICAL DATA SHEET
Plotted and Other Data
Notes:
Values at 25 °C, sea level
PE9251
URL:
http://www.pasternack.com/sma-female-tnc-female-straight-adapter-pe9251-p.aspx
SMA Female to TNC Female Bulkhead Adapter from Pasternack Enterprises has same day shipment for domestic and
International orders. Our RF, microwave and fiber optic products maintain a 99% availability and are part of the broadest
selection in the industry.
PE9251 REV
2
