PE6069: DescriptionLow Power 1 Watts RF Load With Chain Up To 18 GHz With SMA Male Input Passivated Stainless Steel; CategoryThe connector The connector; File Size141KB，2 Pages; ManufacturerPasternack Enterprises; Websitehttps://www.pasternack.com/

Download Datasheet Parametric View All

PE6069 Overview

Low Power 1 Watts RF Load With Chain Up To 18 GHz With SMA Male Input Passivated Stainless Steel

PE6069 Parametric

Parameter Name	Attribute value
Maker	Pasternack Enterprises
Reach Compliance Code	unknow
ECCN code	EAR99
Characteristic impedance	50 Ω
Connector type	RF SMA CONNECTOR
Contact point gender	MALE
Coupling type	THREADED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYTETRAFLUORO ETHYLENE
MIL compliance	NO
Installation method	STRAIGHT
Maximum operating frequency	18 GHz
Options	GENERAL PURPOSE
Panel mounting	NO
voltage standing wave ratio	1.2
Base Number Matches	1

Preview

Download Datasheet

View All

50 Ohm 0.5 Watts Precision Passivated Stainless Steel

SMA Male RF Load With Chain Up To 18 GHz

TECHNICAL DATA SHEET

Configuration

RF Load Design

Connector

Connector Specification

Connection Method

Body Style

Precision

SMA Male

MIL-STD-348

Standard

Straight

PE6069

50 Ohm 0.5 Watts Precision Passivated Stainless Steel SMA Male RF Load With Chain Up To 18 GHz

Electrical Specifications

Frequency Range, GHz

Impedance, Ohms

Maximum VSWR

Maximum Input Power, Watts

DC to 18

50

1.2:1

1

Mechanical Specifications

Temperature

Operating Range, deg C

Size

Length, in [mm]

Width/Dia., in [mm]

.

-55 to +125

0.5 [12.7]

0.312 [7.92]

Connector

Type

Inner Conductor Material and Plating

Coupling Nut Material and Plating

Body Material and Plating

Dielectric Type

SMA Male

Brass/Beryllium Copper, Gold

Passivated Stainless Steel

PTFE

Compliance Certifications

(visit www.Pasternack.com for current document)

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

URL:

http://www.pasternack.com/0.5-watts-sma-male-rf-load-up-to-18-ghz-precision-pe6069-p.aspx

50 Ohm 0.5 Watts Precision Passivated Stainless Steel SMA Male RF Load With Chain Up To 18 GHz

from Pasternack

Enterprises has same day shipment for domestic and International orders. Our RF, microwave and fiber optic products

maintain a 99% availability and are part of the broadest selection in the industry.

PE6069 REV

1
