HN Male to HN Female Right Angle Adapter
TECHNICAL DATA SHEET
HN Male to HN Female Right Angle Adapter
Configuration
Connector 1
Connector Specification 1
Connector 2
Connector Specification 2
Adapter Design
Body Style
HN Male
MIL-STD-348A
HN Female
MIL-STD-348A
Standard
Right Angle
PE9205
Electrical Specifications
Frequency Range, GHz
Impedance, Ohms
Maximum Operating Voltage, Volts
Dielectric Withstanding Voltage, Vrms
Frequency 1
Frequency, GHz
VSWR
DC to 10
50
1,000
2,500
DC to 3
1.5:1
Mechanical Specifications
Temperature
Operating Range,deg C
Size
Length, in [mm]
Width/Dia., in [mm]
Height, in [mm]
.
-65 to +165
1.5 [38.1]
0.866 [22]
1.45 [36.83]
Teflon
HN Male
Brass, Gold
30µ in. minimum
Brass, Nickel
100µ in. minimum
Brass, Nickel
100µ in. minimum
Dielectric Type
Connector 1
Type
Inner Conductor Material and Plating
Inner Conductor Plating Specification
Coupling Nut Material and Plating
Coupling Nut Plating Specification
Body Material and Plating
Body Plating Specification
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications:
HN Male to HN Female Right Angle Adapter PE9205
PE9205 REV
1
HN Male to HN Female Right Angle Adapter
TECHNICAL DATA SHEET
Connector 2
Type
Inner Conductor Material and Plating
Inner Conductor Plating Specification
Body Material and Plating
Body Plating Specification
HN Female
Brass, Gold
30µ in. minimum
Brass, Nickel
100µ in. minimum
PE9205
Compliance Certifications
(visit www.Pasternack.com for current document)
RoHS Compliant
Yes
Plotted and Other Data
Notes:
Values at 25 °C, sea level
URL:
http://www.pasternack.com/hn-male-hn-female-right-angle-adapter-pe9205-p.aspx
HN Male to HN Female Right Angle Adapter from Pasternack Enterprises has same day shipment for domestic and International
orders. Our RF, microwave and fiber optic products maintain a 99% availability and are part of the broadest selection in the
industry.
PE9205 REV
2
