DB 030088, DB 030100
Vishay Draloric
Feed-Through Capacitors with Conductor Rod
DB 030088
10 KV
P
DB 030100 7 KV
P
to 8 KV
P
M6 Thread
M6 Thread
138
±
2 (5.433
±
0.08)
88
±
2 (3.465
±
0.08)
100
±
2 (3.937
±
0.08)
ø
30
(1.181 DIA)
=
ø
30
(1.181 DIA)
SW 10
(0.394 HEX)
14
+ 1
(0.551
+ 0.04
)
SW 10
(0.394 HEX)
ø 45
(1.771 DIA)
Both ends
ø 45
(1.771 DIA)
8
+1
Both ends
(0.315
+ 0.04
)
72
±
0.5
(2.835
±
0.02)
59
±
0.5
(2.322
±
0.02)
6
+ 0.2
(0.236
+ 0.008
)
70
±
0.5
(2.755
±
0.02)
60
±
0.5
(2.362
±
0.02)
4.2
+ 0.2
Holes
(0.165
+ 0.008
)
• Dimensions in millimeters (inches)
MATERIAL:
Capacitor elements made from Class 1 ceramic dielectric
with noble metal electrodes.
Connection Terminals: Copper/brass, silver plated.
MARKING:
Type designator, Capacitance value and tolerance, Rated
voltage (peak value), Production date code, Ceramic
material code, DRALORIC Logo.
FINISH:
Noble metal electrodes completely lacquered. Contoured
rims glazed.
ACCESSORIES ADDED:
Hex. nuts and washers
ORDERING INFORMATION
DF 030100
MODEL
8 KV
P
RATED VOLTAGE
1200 pF
CAPACITANCE VALUE
± 20 %
TOLERANCE
R 85
CERAMIC
www.vishay.com
1
For technical questions contact: powcap@vishay.com
=
60°
60°
Document Number: 22104
Revision: 21-Nov-01
140
±
2 (5.512
±
0.08)
=
0.8
(0.031)
0.8
(0.031)
=
