SEMICONDUCTOR
RECTRON
HVM5
THRU
HVM16
TECHNICAL SPECIFICATION
HIGH VOLTAGE ASSEMBLIED RECTIFIER
VOLTAGE RANGE 5000 to 16000 Volts CURRENT 0.35 Amperes
FEATURES
*
*
*
*
*
*
Low cost
Low leakage
Isolated case
Surge overload rating - 50 amperes peak
Mounting position: Any
Low forward voltage drop
HVM
MECHANICAL DATA
* Epoxy : Device has UL flammability classification 94V-0
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in millimeters
o
MAXIMUM RATINGS
(At T
A
= 25 C unless otherwise noted)
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current at T
A
= 50
o
C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Operating and Storage Temperature Range
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
T
J,
T
STG
HVM5
5
3.5
5
HVM8
8
5.6
8
HVM10
10
7.0
10
HVM12
12
8.4
12
350
50
-20 to + 150
HVM14
14
9.8
14
HVM15
15
10.5
15
HVM16
16
11.2
16
UNITS
K Volts
K Volts
K Volts
mAmps
Amps
0
o
C
ELECTRICAL CHARACTERISTICS
(At T
A
= 25 C unless otherwise noted)
CHARACTERISTICS
Maximum Instantaneous Forward Voltage at 0.35A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage
NOTES:1. Enough heat sink must be considered in application.
o
o
2. Operating and Storage Temperature : -20 C to +150 C
3. Suffix “ L “ for Wire type.
SYMBOL
V
F
I
R
HVM5
8.0
5.0
HVM8
HVM10
HVM12
HVM14
HVM15
HVM16
UNITS
Volts
uAmps
2013-01
14.0
o
RATING AND CHARACTERISTIC CURVES ( HVM5 THRU HVM16 )
FIG. 1 - TYPICAL FORWARD CURRENT
DERATING CURVE
500
400
300
200
100
0
0
50
100
150
175
AMBIENT TEMPERATURE, ( )
Single Phase Half Wave
60Hz Inductive or
Resistive Load
PEAK FORWARD SURGE CURRENT, (A)
AVERAGE FORWARD CURRENT, (mA)
FIG. 2 - MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
60
50
40
30
20
10
0
1
10
100
NUMBER OF CYCLES AT 60Hz
8.3ms Single Half Sine-Wave
(JEDEC Method)
FIG. 3 - TYPICAL REVERSE CHARACTERISTICS
INSTANTANEOUS FORWARD CURRENT, (mA)
INSTANTANEOUS REVERSE CURRENT, (uA)
FIG. 4 - TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS
1000
10
6
4
2
1.0
.6
.4
.2
.1
.06
.04
.02
.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)
TJ = 25
HV
M
5
100
10
1.0
TJ = 25
Pulse Width = 300us
1% Duty Cycle
0.1
5
6
7
8
9
10
11
12
13
14
INSTANTANEOUS FORWARD VOLTAGE, (V)
RECTRON
HV
M8
~H
V
M1
6
RECTRON
Attachment information about HVMXX
1. Internal Circuit
Anode
Cathode
2. Marking on the body
-------------
-------------
Rectron Logo
Cathode Band
Part No.
Voltage-code
5-------5000V
8-------8000V
10----10000V
12----12000V
14-------14000V
15-------15000V
16-------16000V
HVMXX
4. Items marked on the carton
CUSTOMER
TYPE
QUANTITY
LOT NO.
REMARK
DISCLAIMER NOTICE
Rectron Inc reserves the right to make changes without notice to any product
specification herein, to make corrections, modifications, enhancements or other
changes. Rectron Inc or anyone on its behalf assumes no responsibility or liabi-
lity for any errors or inaccuracies. Data sheet specifications and its information
contained are intended to provide a product description only. "Typical" paramet-
ers which may be included on RECTRON data sheets and/ or specifications ca-
n and do vary in different applications and actual performance may vary over ti-
me. Rectron Inc does not assume any liability arising out of the application or
use of any product or circuit.
Rectron products are not designed, intended or authorized for use in medical,
life-saving implant or other applications intended for life-sustaining or other rela-
ted applications where a failure or malfunction of component or circuitry may di-
rectly or indirectly cause injury or threaten a life without expressed written appr-
oval of Rectron Inc. Customers using or selling Rectron components for use in
such applications do so at their own risk and shall agree to fully indemnify Rect-
ron Inc and its subsidiaries harmless against all claims, damages and expendit-
ures.
