PSMN6R0-25YLB
N-channel 25 V 6.1 mΩ logic level MOSFET in LFPAK using
NextPower technology
Rev. 2 — 31 October 2011
Product data sheet
1. Product profile
1.1 General description
Logic level enhancement mode N-channel MOSFET in LFPAK package. This product is
designed and qualified for use in a wide range of industrial, communications and domestic
equipment.
1.2 Features and benefits
High reliability Power SO8 package,
qualified to 175°C
Low parasitic inductance and
resistance
Optimised for 4.5V Gate drive utilising
NextPower Superjunction technology
Ultra low QG, QGD, & QOSS for high
system efficiencies at low and high
loads
1.3 Applications
DC-to-DC converters
Load switching
Synchronous buck regulator
1.4 Quick reference data
Table 1.
Symbol
V
DS
I
D
P
tot
T
j
R
DSon
Quick reference data
Parameter
drain-source voltage
drain current
total power dissipation
junction temperature
drain-source on-state resistance
V
GS
= 4.5 V; I
D
= 20 A; T
j
= 25 °C;
see
Figure 12
V
GS
= 10 V; I
D
= 20 A; T
j
= 25 °C;
see
Figure 12
Dynamic characteristics
Q
GD
Q
G(tot)
gate-drain charge
total gate charge
V
GS
= 4.5 V; I
D
= 20 A; V
DS
= 12 V;
see
Figure 14;
see
Figure 15
-
-
2.6
9
-
-
nC
nC
Conditions
25 °C
≤
T
j
≤
175 °C
T
mb
= 25 °C; V
GS
= 10 V;
see
Figure 1
T
mb
= 25 °C; see
Figure 2
Min
-
-
-
-55
-
-
Typ
-
-
-
-
6.7
5.1
Max
25
73
58
175
7.9
6.1
Unit
V
A
W
°C
mΩ
mΩ
Static characteristics
NXP Semiconductors
PSMN6R0-25YLB
N-channel 25 V 6.1 mΩ logic level MOSFET in LFPAK using NextPower technology
2. Pinning information
Table 2.
Pin
1
2
3
4
mb
Pinning information
Symbol Description
S
S
S
G
D
source
source
source
gate
mounting base; connected to drain
1 2 3 4
mbb076
Simplified outline
mb
Graphic symbol
D
G
S
SOT669 (LFPAK; Power-SO8)
3. Ordering information
Table 3.
Ordering information
Package
Name
PSMN6R0-25YLB
LFPAK;
Power-SO8
Description
plastic single-ended surface-mounted package; 4 leads
Version
SOT669
Type number
4. Limiting values
Table 4.
Symbol
V
DS
V
DGR
V
GS
I
D
I
DM
P
tot
T
stg
T
j
T
sld(M)
V
ESD
I
S
I
SM
E
DS(AL)S
Limiting values
Parameter
drain-source voltage
drain-gate voltage
gate-source voltage
drain current
peak drain current
total power dissipation
storage temperature
junction temperature
peak soldering temperature
electrostatic discharge voltage
source current
peak source current
non-repetitive drain-source
avalanche energy
MM (JEDEC JESD22-A115)
T
mb
= 25 °C
pulsed; t
p
≤
10 µs; T
mb
= 25 °C
V
GS
= 10 V; T
j(init)
= 25 °C; I
D
= 73 A;
V
sup
≤
25 V; unclamped; R
GS
= 50
Ω;
see
Figure 3
V
GS
= 10 V; T
mb
= 25 °C; see
Figure 1
V
GS
= 10 V; T
mb
= 100 °C; see
Figure 1
pulsed; t
p
≤
10 µs; T
mb
= 25 °C;
see
Figure 4
T
mb
= 25 °C; see
Figure 2
Conditions
25 °C
≤
T
j
≤
175 °C
25 °C
≤
T
j
≤
175 °C; R
GS
= 20 kΩ
Min
-
-
-20
-
-
-
-
-55
-55
-
220
-
-
-
Max
25
25
20
73
52
292
58
175
175
260
-
53
292
15
Unit
V
V
V
A
A
A
W
°C
°C
°C
V
A
A
mJ
In accordance with the Absolute Maximum Rating System (IEC 60134).
Source-drain diode
Avalanche ruggedness
PSMN6R0-25YLB
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2011. All rights reserved.
Product data sheet
Rev. 2 — 31 October 2011
2 of 15
NXP Semiconductors
PSMN6R0-25YLB
N-channel 25 V 6.1 mΩ logic level MOSFET in LFPAK using NextPower technology
80
I
D
(A)
60
003aag105
120
P
der
(%)
80
03na19
40
40
20
0
0
50
100
150
T
mb
(
°
C)
200
0
0
50
100
150
T
mb
(°C)
200
Fig 1.
Continuous drain current as a function of
mounting base temperature
10
2
Fig 2.
Normalized total power dissipation as a
function of mounting base temperature
003aag106
I
AL
(A)
(1)
10
(2)
1
10
-3
10
-2
10
-1
1
t
AL
(ms)
10
Fig 3.
Single pulse avalanche rating; avalanche current as a function of avalanche time
PSMN6R0-25YLB
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2011. All rights reserved.
Product data sheet
Rev. 2 — 31 October 2011
3 of 15
NXP Semiconductors
PSMN6R0-25YLB
N-channel 25 V 6.1 mΩ logic level MOSFET in LFPAK using NextPower technology
10
3
I
D
(A)
10
2
Limit R
DSon
= V
DS
/ I
D
t
p
=10
μ
s
100
μ
s
10
DC
1 ms
10 ms
100 ms
003aag107
1
10
-1
10
-1
1
10
V
DS
(V)
10
2
Fig 4.
Safe operating area; continuous and peak drain currents as a function of drain-source voltage
PSMN6R0-25YLB
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2011. All rights reserved.
Product data sheet
Rev. 2 — 31 October 2011
4 of 15
NXP Semiconductors
PSMN6R0-25YLB
N-channel 25 V 6.1 mΩ logic level MOSFET in LFPAK using NextPower technology
5. Thermal characteristics
Table 5.
Symbol
R
th(j-mb)
Thermal characteristics
Parameter
thermal resistance from junction to mounting base
Conditions
see
Figure 5
Min
-
Typ
2.35
Max
2.57
Unit
K/W
10
Z
th(j-mb)
(K/W)
δ
= 0.5
0.2
0.1
0.05
10
-1
0.02
single shot
tp
003aag093
1
P
δ
=
tp
T
t
T
10
-2
10
-6
10
-5
10
-4
10
-3
10
-2
10
-1
t
p
(s)
1
Fig 5.
Transient thermal impedance from junction to mounting base as a function of pulse duration
PSMN6R0-25YLB
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2011. All rights reserved.
Product data sheet
Rev. 2 — 31 October 2011
5 of 15
