19-0065; Rev 6; 10/03
+5V, RS-232 Transceivers
with 0.1µF External Capacitors
General Description
The MAX200–MAX211/MAX213 transceivers are
designed for RS-232 and V.28 communication inter-
faces where ±12V supplies are not available. On-board
charge pumps convert the +5V input to the ±10V need-
ed for RS-232 output levels. The MAX201 and MAX209
operate from +5V and +12V, and contain a +12V to
-12V charge-pump voltage converter.
The MAX200–MAX211/MAX213 drivers and receivers
meet all EIA/TIA-232E and CCITT V.28 specifications at
a data rate of 20kbps. The drivers maintain the ±5V
EIA/TIA-232E output signal levels at data rates in
excess of 120kbps when loaded in accordance with the
EIA/TIA-232E specification.
The 5µW shutdown mode of the MAX200, MAX205,
MAX206, and MAX211 conserves energy in battery-
powered systems. The MAX213 has an active-low shut-
down and an active-high receiver enable control. Two
receivers of the MAX213 are active, allowing ring indica-
tor (RI) to be monitored easily using only 75µW power.
The MAX211 and MAX213 are available in a 28-pin
wide small-outline (SO) package and a 28-pin shrink
small-outline (SSOP) package, which occupies only
40% of the area of the SO. The MAX207 is now avail-
able in a 24-pin SO package and a 24-pin SSOP. The
MAX203 and MAX205 use no external components,
and are recommended for applications with limited
circuit board space.
Next-Generation Device Features
♦
For Low-Cost Applications:
MAX221E: ±15kV ESD-Protected, +5V, 1µA,
Single RS-232 Transceiver with AutoShutdown™
♦
For Low-Voltage and Space-Constrained
Applications:
MAX3222E/MAX3232E/MAX3237E/MAX3241E/
MAX3246E: ±15kV ESD-Protected, Down to 10nA,
+3.0V to +5.5V, Up to 1Mbps, True RS-232
Transceivers (MAX3246E Available in UCSP™
Package)
♦
For Space-Constrained Applications:
MAX3228E/MAX3229E: ±15kV ESD-Protected,
+2.5V to +5.5V, RS-232 Transceivers in UCSP
♦
For Low-Voltage or Data Cable Applications:
MAX3380E/MAX3381E: +2.35V TO +5.5V, 1µA,
2Tx/2Rx RS-232 Transceivers with ±15kV ESD-
Protected I/O and Logic Pins
♦
For Low-Power Applications:
MAX3224E–MAX3227E/MAX3244E/MAX3245E:
±15kV ESD-Protected, 1µA, 1Mbps, +3.0V to
+5.5V, RS-232 Transceivers with AutoShutdown
Plus™
MAX200–MAX211/MAX213
Applications
Computers
Laptops, Palmtops, Notebooks
Battery-Powered Equipment
Hand-Held Equipment
Ordering Information appears at end of data sheet
AutoShutdown, AutoShutdown Plus, and UCSP are trademarks
of Maxim Integrated Products, Inc.
Selector Guide
Part
Number
MAX200
MAX201
MAX202
MAX203
MAX204
MAX205
MAX206
MAX207
MAX208
MAX209
MAX211
MAX213
Power-Supply
Voltage (V)
+5
+5 and +9.0 to +13.2
+5
+5
+5
+5
+5
+5
+5
+5 and +9.0 to +13.2
+5
+5
No. of RS-
232 Drivers
5
2
2
2
4
5
4
5
4
3
4
4
No. of
RS-232
Receivers
0
2
2
2
0
5
3
3
4
5
5
5
No. of
Receivers Active
in Shutdown
0
0
0
0
0
0
0
0
0
0
0
2
No. of External
Capacitors
(0.1µF)
4
2
4
None
4
None
4
4
4
2
4
4
Low-Power
Shutdown/
TTL Three-State
Yes/No
No/No
No/No
No/No
No/No
Yes/Yes
Yes/Yes
No/No
No/No
No/Yes
Yes/Yes
Yes/Yes
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
