GS8162Z18BGD-150VT datasheet, PDF

Datasheet> All Categories > storage> storage> GS8162Z18BGD-150VT

GS8162Z18BGD-150VT: DescriptionZBT SRAM, 1MX18, 7.5ns, CMOS, PBGA165, 13 X 15 MM, 1 MM PITCH, ROHS COMPLIANT, FPBGA-165; Categorystorage storage; File Size2MB，32 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/; Environmental Compliance

Download Datasheet Parametric View All

GS8162Z18BGD-150VT Overview

ZBT SRAM, 1MX18, 7.5ns, CMOS, PBGA165, 13 X 15 MM, 1 MM PITCH, ROHS COMPLIANT, FPBGA-165

GS8162Z18BGD-150VT Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	GSI Technology
Parts packaging code	BGA
package instruction	13 X 15 MM, 1 MM PITCH, ROHS COMPLIANT, FPBGA-165
Contacts	165
Reach Compliance Code	unknown
ECCN code	3A991.B.2.B
Maximum access time	7.5 ns
Other features	FLOW-THROUGH OR PIPELINED ARCHITECTURE; ALSO OPERATES WITH 2.5V SUPPLY
JESD-30 code	R-PBGA-B165
JESD-609 code	e1
length	15 mm
memory density	18874368 bit
Memory IC Type	ZBT SRAM
memory width	18
Humidity sensitivity level	3
Number of functions	1
Number of terminals	165
word count	1048576 words
character code	1000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	1MX18
Package body material	PLASTIC/EPOXY
encapsulated code	LBGA
Package shape	RECTANGULAR
Package form	GRID ARRAY, LOW PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	1.4 mm
Maximum supply voltage (Vsup)	2 V
Minimum supply voltage (Vsup)	1.7 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal form	BALL
Terminal pitch	1 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
width	13 mm

Preview

Download Datasheet

View All

GS8162ZxxB(B/D)-xxxV

119- & 165-Bump BGA

Commercial Temp

Industrial Temp

Features

• NBT (No Bus Turn Around) functionality allows zero wait

Read-Write-Read bus utilization; fully pin-compatible with

both pipelined and flow through NtRAM™, NoBL™ and

ZBT™ SRAMs

• 1.8 V or 2.5 V core power supply

• 1.8 V or 2.5 V I/O supply

• User-configurable Pipeline and Flow Through mode

• ZQ mode pin for user-selectable high/low output drive

• IEEE 1149.1 JTAG-compatible Boundary Scan

• On-chip write parity checking; even or odd selectable

• On-chip parity encoding and error detection

• LBO pin for Linear or Interleave Burst mode

• Pin-compatible with 2M, 4M, and 8M devices

• Byte write operation (9-bit Bytes)

• 3 chip enable signals for easy depth expansion

• ZZ Pin for automatic power-down

• JEDEC-standard 119- and 165-bump BGA packages

• RoHS-compliant 119- and 165-bump BGA packages

available

18Mb Pipelined and Flow Through

Synchronous NBT SRAM

250 MHz–150 MHz

1.8 V or 2.5 V V

1.8 V or 2.5 V I/O

Functional Description

for

The GS8162ZxxB(B/D)-xxxV is an 18Mbit Synchronous

Static SRAM. GSI's NBT SRAMs, like ZBT, NtRAM, NoBL

or other pipelined read/double late write or flow through read/

single late write SRAMs, allow utilization of all available bus

bandwidth by eliminating the need to insert deselect cycles

when the device is switched from read to write cycles.

Parameter Synopsis

-250

3.0

4.0

280

330

5.5

210

240

sig

Pipeline

3-1-1-1

tCycle

Curr (x18)

Curr (x32/x36)

tCycle

Curr (x18)

Curr (x32/x36)

Flow Through

2-1-1-1

Rev: 1.03 9/2008

1/32

n—

sco

inu

-200

3.0

5.0

230

270

6.5

185

205

Because it is a synchronous device, address, data inputs, and

read/write control inputs are captured on the rising edge of the

input clock. Burst order control (LBO) must be tied to a power

rail for proper operation. Asynchronous inputs include the

Sleep mode enable (ZZ) and Output Enable. Output Enable can

be used to override the synchronous control of the output

drivers and turn the RAM's output drivers off at any time.

Write cycles are internally self-timed and initiated by the rising

edge of the clock input. This feature eliminates complex off-

chip write pulse generation required by asynchronous SRAMs

and simplifies input signal timing.

The GS8162ZxxB(B/D)-xxxV may be configured by the user

to operate in Pipeline or Flow Through mode. Operating as a

pipelined synchronous device, in addition to the rising-edge-

triggered registers that capture input signals, the device

incorporates a rising edge triggered output register. For read

cycles, pipelined SRAM output data is temporarily stored by

the edge-triggered output register during the access cycle and

then released to the output drivers at the next rising edge of

clock.

The GS8162ZxxB(B/D)-xxxV is implemented with GSI's high

performance CMOS technology and is available in a JEDEC-

standard 119-bump or 165-bump BGA package.

-150

3.8

6.7

185

210

7.5

170

190

Unit

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
