IF-XS-1W&IF-XD-1W
Series
FIXED INPUT,ISOLATED & REGULATED Single Output DC/DC Converter
SELECTION GUIDE
Input
Order code
Voltage(VDC)
Output
Range
Voltage
(VDC)
Current(MA)
Max
Min
Nominal
Efficiency
(%,Typ)
Switching
Frequency
(KHz,Typ)
IF0505XS-W75
IF0505XS-1W
5
5
5
5
5
12
12
12
12
12
24
24
24
24
24
5
5
5
5
5
12
12
12
12
12
24
24
24
24
24
4.75-5.25
4.75-5.25
4.75-5.25
4.75-5.25
4.75-5.25
11.4-12.6
11.4-12.6
11.4-12.6
11.4-12.6
11.4-12.6
22.8-25.2
22.8-25.2
22.8-25.2
22.8-25.2
22.8-25.2
4.75-5.25
4.75-5.25
4.75-5.25
4.75-5.25
4.75-5.25
11.4-12.6
11.4-12.6
11.4-12.6
11.4-12.6
11.4-12.6
22.8-25.2
22.8-25.2
22.8-25.2
22.8-25.2
22.8-25.2
5
5
9
12
15
5
5
9
12
15
5
5
9
12
15
5
5
9
12
15
5
5
9
12
15
5
5
9
12
15
150
200
111
83
67
150
200
111
83
67
150
200
111
83
67
150
200
111
83
67
150
200
111
83
67
150
200
111
83
67
15
20
12
9
7
15
20
12
9
7
15
20
12
9
7
15
20
12
9
7
15
20
12
9
7
15
20
12
9
7
68
66
70
72
73
68
67
71
73
74
68
67
72
73
74
68
66
70
72
73
68
67
71
73
74
68
67
72
73
74
83
83
83
83
250
100
83
83
83
83
83
83
83
83
300
83
83
83
83
250
100
83
83
83
83
83
83
83
83
300
FEATURES
◆
RoHS compliant
◆
Efficiency up to 86%
◆
SIP/DIP Package
◆
Wide temperature performance at full
IF0509XS-1W
IF0512XS-1W
IF0515XS-1W
IF1205XS-W75
IF1205XS-1W
IF1209XS-1W
IF1212XS-1W
IF1215XS-1W
1 Watt load,-40°C to 85°C
◆
UL 94V-0 package material
◆
No heatsink required
◆
Low ripple and good EMC Features
◆
Industry standard pinout
◆
Power sharing on output
◆
3KVDC isolation
◆
Continuous Short Circuit Protection
◆
Internal SMD construction
◆
No external components required
◆
Good dynamic feature
IF2405XS-W75
IF2405XS-1W
IF2409XS-1W
IF2412XS-1W
IF2415XS-1W
IF0505XD-W75
IF0505XD-1W
IF0509XD-1W
IF0512XD-1W
IF0515XD-1W
IF1205XD-W75
IF1205XD-1W
IF1209XD-1W
IF1212XD-1W
IF1215XD-1W
IF2405XD-W75
IF2405XD-1W
IF2409XD-1W
MODEL SELECTION
IF
①
05
②
05
③
X
④
S
⑤
-1W
⑥
①Product
Series
③Output
Voltage
⑤SIP
Package
②Input
Voltage
④Fixed
Input
⑥Rated
Power
IF2412XD-1W
IF2415XD-1W
ISOLATION SPECIFICATIONS
Parameter
Isolation test voltage
Isolation resistance
Test conditions
Flash tested for 1 minute and 1mA max
Test at Viso=500VDC
Min.
3000
1000
Typ.
Max.
Units
VDC
MΩ
DESCRIPTION
The IF_XS-1W & IF_XD-1W series are specially designed for
applications where a group of polar power supplies are
isolated from the input power supply in a distributed power
supply system on a circuit board.
These products apply to:
1) where the voltage of the input power supply is fixed
(voltage variation ≤±5%);
2) where isolation is necessary between input and output
(isolation voltage ≤3000VDC);
3) where the regulation of the output voltage and the output
ripple noise are demanded.
OUTPUT SPECIFICATIONS
Parameter
Output power
Line regulation
Load regulation
Output voltage accuracy
Temperature drift
Output Ripple*
Output Noise*
Switching frequency
For Vin change of ±5%
10% to 100% full load
100% full load
100% full load
20MHz Bandwidth
20MHz Bandwidth
Full load,nominal input
10
50
100
Test conditions
Min
0.1
Typ.
Max.
1
±0.25
±1
±3
0.03
20
100
Units
W
%
%
%
%/°C
MV p-p
MV p-p
Khz
MICRODC reserves the copyright
* Test ripple and noise by "parallel cable" method. See detailed operation instructions at Testing of Power
Converter section, application notes.
http://www.microdc.cn
Technical Enquiries-Email:tech@microdc.cn Tel:0086-20-86000646
Page 1 of 2
IF-XS-1W&IF-XD-1W
Series
TEMPERATURE CHARACTERISTICS
Parameter
Storage humidity range
NO-load power consumption
Operating temperature
Storage temperature
Lead temperature
Temp.rise at full load
Cooling
Case material
IF(XX)05X(S)D-1W
Short circuit protection
Others
MTBF
Weight
3500
5.2
1
s
K hours
g
1.5mm from case for 10 seconds
-40
-55
15
85
125
300
25
Free air convection
Plastic(UL94-V0)
Continuous
°C
Filtering
Min.
Typ.
Max.
95
Conditions
Units
%
°C
°C
°C
To get an extreme low ripple,an "LC"filtering network
may be connected to the input and output ends of the
DC/DC converter.Which may produce a more significant
filtering effect.It should also be noted that the inductance
and the frequency of the "LC"filtering network should be
staggered with the DC/DC frequency to avoid mutual
interference see (Figure 1).
*Supply voltage must be discontinued at the end of short circuit duration.
TYPICAL CHARACTERISTICS
Temperature Derating Graph
In some circuits which are sensitive to noise and
ripple.a filtering capacitor may be added to the DC/DC
output end andinput end to reduce the noise and ripple.
However, the capacitance of the output filter capacitor
must be proper. If the capacitance is too big, a startup
problem might arise. For every channel of output,
provided the safe and reliable operation is ensured, the
greatest capacitance of its filter capacitor sees (Table 1).
EXTERNAL CAPACITOR TABLE (TABLE 1)
Cin
Vout
Vin
(VDC)
5
12
24
-
(μF)
4.7
2.2
1.0
-
(VDC)
5
9
12
15
Cout
(μF)
10
4.7
2.2
1.0
It's not recommend to connect any external capacitor in
the application field with less than 0.5 watt output.
OUTLINE DIMENSIONS & PIN CONNECTIONS
IF-XS-1W SIP
IF-
SIZE Graph
IF-XD-1W DIP
IF-
Overload Protection
Under normal operating conditions, the output circuit of
these products has no protection against over-current
andshort-circuits.The simplest method is to connect a
self-recovery fuse in series at the input end or add a
circuit breaker to the circuit.
Requirement On Output Load
Toensure this module can operate efficiently and reliably,
a minimum load is specified for this kind of DC/DC
converter in addition to a maximum load (namely full
load).During operation,make sure the specified range
of input voltage is not exceeded,the minimum output
load is not less than 10% of the full load, and that this
product should never be operated under no load! If the
actual output power is very small, please connect a
resistor with proper resistance at the output end in
parallel to increase the load, or use our company°s
products with a lowerrated output power (IF_S(D)-W25
Series).
When the environment temperature is higher than
71 C, the product output power should be less then
71°C,
60% of the rated power.
No parallel connection or plug and play.
Use dual output simultaneously, forbid opening
output pin (0V) to use as single output.
RECOMMENDED FOOTPRINT
Top view,grid:2.54mm(0.1inch)
diameter:1.00mm(0.039inch)
FOOTPRINT DETAILS
Pin
1
2
4
6
FOOTPRINT DETAILS
Note:
Unit:mm(inch)
Pin section:0.50*0.3mm(0.020*0.012inch)
Pin section tolerances: 0.10mm( 0.004inch)
General tolerances: 0.25mm( 0.010inch)
Function
Vin
GND
0V
+V0
Pin
1
2
9
11
14
Function
GND
NC
+V0
0V
Vin
RoHS COMPLIANT INFORMATION
This series is compatible with RoHS soldering systems with a peak wave solder temperature
of 300°C for 10 seconds.
The pin termination finish on the SIP package type is Tin Plate, Hot Dipped over Matte Tin
with Nickel Preplate. The DIP types are Matte Tin over Nickel Preplate. Both types in this
series are backward compatible with Sn/Pb soldering systems.
Microdc Professional Power Module,Inc.
Tel:0086-20-86000646
E-mail:tech@microdc.cn
Website:http://www.microdc.cn
REACH COMPLIANT INFORMATION
This series has proven that this product does not contain harmful chemicals, it also has
harmful chemical substances through the registration, inspection and approval.
http://www.microdc.cn
Technical Enquiries-Email:tech@microdc.cn Tel:0086-20-86000646
Page 2 of 2
