WRE-ZD-6W&WRF-ZD-6W
Series
6W,4:1 WIDE INPUT,ISOLATED®ULATED SINGLE/DUAL OUTPUT DIP DC/DC CONVERTER
SELECTION GUIDE
Input
Order code
Nominal
WRE2405ZD-6W
WRE2412ZD-6W
WRE2415ZD-6W
WRE2424ZD-6W
WRF2403ZD-6W
WRF2405ZD-6W
WRF2412ZD-6W
24
24
24
24
24
24
24
24
24
48
48
48
48
48
48
48
48
48
Voltage(VDC)
Range
9-36
9-36
9-36
9-36
9-36
9-36
9-36
9-36
9-36
18-72
18-72
18-72
18-72
18-72
18-72
18-72
18-72
18-72
Max.
*
40
40
40
40
40
40
40
40
40
80
80
80
80
80
80
80
80
80
Voltage
(VDC)
±5
±12
±15
±24
3.3
5
12
15
24
±5
±12
±15
±24
3.3
5
12
15
24
Output
Current(mA)
Max.
±600
±250
±200
±125
1500
1200
500
400
250
±600
±250
±200
±125
1500
1200
500
400
250
Min.
±60
±25
±20
±13
150
120
50
40
25
±60
±25
±20
±13
150
120
50
40
25
Efficiency
(%,Typ)
80
82
84
87
78
80
82
84
82
80
82
84
84
77
80
82
84
84
FEATURES
◆
High Efficiency up to 84%
◆
Operating Temperature: -40℃ to +85℃
◆
3KVDC Input/Output Isolation
◆
Short Circuit Protection(Automatic recovery)
◆
Internal SMD construction
◆
No Heat Sink Required
◆
Industry Standard Pinout
◆
MTBF>1,000,000 hours
◆
RoHS Compliance
WRF2415ZD-6W
WRF2424ZD-6W
WRE4805ZD-6W
WRE4812ZD-6W
WRE4815ZD-6W
WRE4824ZD-6W
WRF4803ZD-6W
WRF4805ZD-6W
MODEL SELECTION
①
②
③ ④
⑤
⑥
WRE 24 05 Z D -6W
WRF4812ZD-6W
WRF4815ZD-6W
WRF4824ZD-6W
①Product
Series
③Output
Voltage 1st
⑤Package
Style
②Input
Voltage
④Wide
(4:1) Input Range
⑥Rated
Power
Note:
1.*Input voltage can't exceed this value, or will cause the permanent damage.
2. The load shouldn't be less than 10%, otherwise ripple will increase dramatically.
3. Operation under 10% load will not damage the converter; However, they may not meet all specification
listed.
APPLICATIONS
The
WRE_ZD-6W&WRF_ZD-6W
Series
are
specially designed for applications where a wide
range input voltage power supplies are isolated from
the input power supply in a distributed power supply
system on a circuit board.
These products apply to:
1) Where the voltage of the input power supply is wide
range (voltage range≤4:1);
2) Where isolation is necessary between input and
output (Isolation Voltage≤3000VDC);
3) Where the regulation of the output voltage and the
output ripple noise are demanded.
ISOLATION SPECIFICATIONS
Parameter
Output Power
Positive Voltage accuracy
Negative Voltage accuracy
Load Regulation
Line Regulation(at full load)
Temperature Drift(Vout)
Ripple**
Noise**
Switching Frequency
Test conditions
See below products program
Refer to recommended circuit
Refer to recommended circuit
From 10% to 100% load
Input voltage from low to high
Refer to recommended circuit
20MHz bandwidth
20MHz bandwidth
100% load,nominal Input voltage
Min.
0.6
Typ.
±1
±3
±0.5
±0.2
±0.02
20
75
300
Max.
6
±3
±5
±2*
±0.5
Units
W
%
%
%
%
%/℃
50
150
mVp-p
mVp-p
KHz
*Dual output models unbalanced load:
±5%
**Test ripple and noise by
“Parallel
Converter section, application notes.
cable”method. See detailed operation instructions at Testing of Power
MICRODC reserves the copyright
http://www.microdc.cn
Technical Enquiries-Email:tech@microdc.cn Tel:0086-20-86000646
Page 1 of 2
WRE-ZD-6W&WRF-ZD-6W
Series
OUTPUT SPECIFICATIONS
Parameter
Storage Humidity
Operating Temperature
Storage Temperature
Temp. rise at full load
Lead Temperature
Isolation voltage
Isolation resistance
No-load power consumption
Cooling
Case Material
Short Circuit Protection
MTBF
Weight
1.5mm from case for 10 seconds
Tested for 1 minute and 1mA max
Test at 500VDC
3000
1000
500
Free air convection
Plastic(UL94-V0)
Continuous, automatic recovery
1000
17
K hours
g
-40
-55
40
300
APPLICATION NOTE
Min
Typ.
Max
95
85
125
Test conditions
Unit
%
℃
℃
℃
℃
VDC
MΩ
mW
Requirement Output Load
In order to ensure the product operate efficiently and eliably, in addition
to a max load (namely full load), a minimum load is specified for this
kind of DC/DC converter. Make sure the specified range of input voltage
is not exceeded, the minimum output load no less than 10% load. If
the actual load is less than the specified minimum load, the output ripple
may increase sharply while its efficiency and reliability will reduce
greatly. If the actual output power is very small, please add an
appropriate resistor as extra loading, or contact our company for other
lower output power products.
Recommended Circuit
All the WRE_ZD-6W & WRF_ZD-6W Series have been tested
according to the following recommended
leaving factory. (See Figure 1).
testing circuit before
TYPICAL CHARECTERISTICS
If you want to further decrease the input/output ripple, you can increase
capacitance properly or choose capacitors with low ESR. However, the
capacitance of the output filter capacitor must be proper. If the
capacitance is too big, a startup problem might arise. For every channel
OUTLINE DIMENSIONS & FOOTPRINT DETAILS
MECHANICAL DIMENSIONS
RECOMMENDED FOOTPRINT(TOP VIEW)
of output, provided the safe and reliable operation is ensured, the
greatest capacitance of its filter capacitor sees (Table 1). General:
Cin:
24V&48V
10µF-47µF
Cout: 10µF/100mA
Input Current
When it is used in unregulated power supply, be sure that the fluctuating
range of the power supply and the rippled voltage do not exceed the
TUBE OUTLINE DIMENSIONS
module standard. Input current of power supply should afford the startup
current of this kind of DC/DC module (See figure 2), General:
Note:
Unit:mm[inch]
Pin diameter tolerances:±0.10mm[±0.004inch]
General tolerances:
±0.25mm[±0.010inch]
FOOTPRINT DETAILS
Pin
2,3
9
11
14
16
22,23
Single
GND
No Pin
NC
+Vo
0V
Vin
Dual
GND
0V
-Vo
+Vo
0V
Vin
Note:
Unit :mm[inch]
General tolerances:±0.50mm[±0.020inch]
L=530mm[20.866inch]
L=220mm[8.661inch]
Tube Quantity: 15pcs
Tube Quantity: 6pcs
No parallel connection or plug and play.
Ip
≤1.6*Iin-max
NC: No connection.
http://www.microdc.cn
Technical Enquiries-Email:tech@microdc.cn Tel:0086-20-86000646
Page 2 of 2
