Unshielded Radial Power Inductor
AIUR-01 Series
FEATURES:
• Ferrite core with heat shrink tube
• High Reliability
APPLICATIONS:
• Switching Power Supplies
• Noise Filtering
• DC to DC Converters
Pb
RoHS
Compliant
7.5 x ϕ8.0 mm
• Electronic Household Appliances
• Buzzers and Alarm Systems
• Television and Audio Equipment
STANDARD SPECIFICATIONS:
PARAMETERS
ABRACON P/N:
Operating temperature:
Storage temperature:
Part Number
Units
Symbol
AIUR-01-101
AIUR-01-121
AIUR-01-151
AIUR-01-181
AIUR-01-221
AIUR-01-271
AIUR-01-331
AIUR-01-391
AIUR-01-471
AIUR-01-561
AIUR-01-681
AIUR-01-821
AIUR-01-102
AIUR-01-122
AIUR-01-152
AIUR-01-182
AIUR-01-222
AIUR-01-272
AIUR-01-332
AIUR-01-392
AIUR-01-472
AIUR-01-562
AIUR-01-682
AIUR-01-822
AIUR-01-103
AIUR-01-123
AIUR-01-153
Inductance
μH
L
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
AIUR-01 Series
-25°C to + 85°C
-25°C to + 125°C
Tolerance
%
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
Q (Min)
DCR
(Max)
Ω
DCR
2
3
3
3
3
3
4
4
5
6
6
7
9
9
11
12
14
15
25
30
32
36
40
45
55
65
80
Saturation
Current (Max)
mA
Isat*
200
200
200
200
150
150
150
100
100
100
100
50
50
50
50
50
50
50
40
40
40
30
30
30
20
20
20
SRF (Min)
MHz
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
1.8
1.6
1.5
1.4
0.9
0.9
0.8
0.7
0.7
0.6
0.6
0.5
0.5
60
60
60
60
60
60
60
60
60
60
60
60
80
80
80
80
80
80
80
80
80
80
80
80
60
60
60
Test Conditions and equipments
Test frequency: 100KHz 0.1Vrms
DCR: QuadTech Milliohmmeter
Isat: 10% inductance drops from initial value
ABRACON IS
ISO 9001 / QS 9000
ISO 9001:2008
CE RTIFIED
Revised: 07.24.12
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
Unshielded Radial Power Inductor
AIUR-01 Series
OPTIONS & PART IDENTIFICATION:
(Left blank if standard)
Pb
RoHS
Compliant
7.5 x ϕ8.0 mm
Packing (200pcs / box)
AIUR-01-
Inductance Code
Please refer to the
Electrical Spec Table
Tolerance
K: ±10%
OUTLINE DRAWING:
Polyolefin Shrink Tube
Dimension: inch/mm
ATTENTION:
Abracon Corporation’s products are COTS – Commercial-Off-The-Shelf products; suitable for Commercial, Industrial and, where designated, Automotive Applica-
tions. Abracon’s products are not specifically designed for Military, Aviation, Aerospace, Life-dependant Medical applications or any application requiring high reliability where
component failure could result in loss of life and/or property. For applications requiring high reliability and/or presenting an extreme operating environment, written consent and
authorization from Abracon Corporation is required. Please contact Abracon Corporation for more information.
ABRACON IS
ISO 9001 / QS 9000
ISO 9001:2008
CE RTIFIED
Revised: 07.24.12
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000| fax 949-546-800
www.abracon.com
1|
Visit www.abracon.com for Terms & Conditions of Sale
