MS563PKA153MSZ

Description
High-Reliability Power Inductors
CategoryPassive components    inductor
File Size630KB,2 Pages
ManufacturerCOILCRAFT
Websitehttp://www.coilcraft.com/
Download Datasheet Parametric View All

MS563PKA153MSZ Overview

High-Reliability Power Inductors

MS563PKA153MSZ Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerCOILCRAFT
package instruction5239
Reach Compliance Codecompliant
ECCN codeEAR99
uppercase and lowercase codes5239
structureFlat Top
core materialFERRITE
DC Resistance0.058 Ω
Nominal inductance(L)15 µH
Inductor ApplicationsPOWER INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
JESD-609 codee0
Number of functions1
Number of terminals2
Maximum operating temperature155 °C
Minimum operating temperature-55 °C
Package height5.71 mm
Package length13.21 mm
Package formSMT
Package width9.91 mm
method of packingTR, Plastic, 13 Inch
Maximum rated current2.6 A
self resonant frequency25 MHz
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldNO
surface mountYES
Terminal surfaceTin/Lead (Sn63Pb37)
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Test frequency0.1 MHz
Tolerance20%
Base Number Matches1
3316 POWER INDUCTOR
High-Reliability Power Inductors
MS563PKA
High temperature materials allow operation in ambient
temperatures up to 155°C.
Tin-lead (Sn-Pb) soldered self-leaded construction for
excellent solderability.
Very low DCR values and excellent current handling
Core material
Ferrite
Terminations
Tin-lead (63/37) over copper
Weight
0.95 – 1.25 g
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
750 per 13″ reel
Plastic tape: 24 mm wide, 0.35 mm thick, 12 mm pocket spacing,
6.4 mm pocket depth
DCR
(mOhm)
typ
max
2.6
3.0
5.1
6.0
5.1
6.0
7.7
9.0
6.8
10
9.4
11
11.1
13
15.3
18
20.4
24
21.3
25
25.5
30
29.8
35
32.3
38
40.8
48
49.3
58
59.5
70
72.3
85
85
100
109
128
116
136
146
172
170
200
221
260
264
310
306
360
384
452
432
508
525
618
618
727
819
963
935 1100
1105 1300
1360 1600
SRF
(MHz)
3
min
typ
200
122
100
86
74
63
57
54
46
43
38
35
30
26
25
21
20
19
16
14
12
11
10
9.5
8.3
8.3
7.0
6.0
5.3
4.6
4.4
3.9
3.6
238
153
125
108
92
79
71
68
57
53
48
44
38
33
31
27
25
24
20
18
15
14
13
12
10
10
8.7
7.5
6.6
5.8
5.5
4.8
4.3
Isat
(A)
4
10%
20%
30%
drop drop drop
14.0
8.6
7.0
6.2
6.0
5.1
4.7
4.3
4.0
3.6
3.3
2.9
2.7
2.5
2.2
2.1
1.9
1.7
1.5
1.3
1.2
1.1
0.85
0.82
0.80
0.70
0.65
0.62
0.50
0.44
0.42
0.41
0.35
16.0
10.2
8.4
7.4
6.7
6.0
5.5
5.2
4.4
4.1
3.7
3.4
3.1
2.9
2.5
2.4
2.1
1.9
1.7
1.5
1.4
1.3
1.2
1.1
0.96
0.85
0.80
0.70
0.70
0.54
0.48
0.46
0.44
17.0
10.9
9.3
8.1
7.2
6.4
6.0
5.5
4.8
4.4
4.0
3.7
3.4
3.1
2.8
2.6
2.3
2.1
1.9
1.7
1.5
1.4
1.3
1.2
1.1
0.98
0.86
0.80
0.65
0.62
0.58
0.53
0.48
Irms
(A)
5
20°C 40°C
rise
rise
8.0 12.0
6.1
8.8
3.4
5.6
3.2
5.0
2.9
4.5
2.7
4.2
2.4
4.0
2.4
4.0
2.4
3.7
2.2
3.3
2.2
3.3
2.2
3.2
2.1
3.1
1.7
2.7
1.9
2.6
1.9
2.5
1.8
2.4
1.3
1.9
1.3
1.8
1.3
1.8
1.1
1.5
0.9
1.3
0.82 1.2
0.81 1.2
0.80 1.1
0.68 0.90
0.63 0.87
0.54 0.76
0.53 0.73
0.43 0.62
0.41 0.57
0.38 0.53
0.34 0.47
1. When ordering, specify
testing
code:
MS563PKA301MSZ
Testing: Z
= COTS
H
= Screening per Coilcraft
CP-SA-10001
N
= Screening per Coilcraft
CP-SA-10004
2. Inductance tested at 100 kHz,
0.1 Vrms, 0 Adc using an Agilent/HP
4263B LCR meter or equivalent.
3. SRF measured using Agilent/
HP 8753D network analyzer or
equivalent..
4. Typical DC current at which the
inductance drops 10% (typ) from its
value without current.
5. Typical Current that causes a 40°C
temperature rise from 25°C ambient.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface
Mount Components” before soldering.
Part number
1
MS563PKA301MSZ
MS563PKA901MSZ
MS563PKA122MSZ
MS563PKA182MSZ
MS563PKA222MSZ
MS563PKA272MSZ
MS563PKA332MSZ
MS563PKA392MSZ
MS563PKA472MSZ
MS563PKA562MSZ
MS563PKA682MSZ
MS563PKA822MSZ
MS563PKA103MSZ
MS563PKA123MSZ
MS563PKA153MSZ
MS563PKA183MSZ
MS563PKA223MSZ
MS563PKA273MSZ
MS563PKA333MSZ
MS563PKA393MSZ
MS563PKA473MSZ
MS563PKA563MSZ
MS563PKA683MSZ
MS563PKA823MSZ
MS563PKA104MSZ
MS563PKA124MSZ
MS563PKA154MSZ
MS563PKA184MSZ
MS563PKA224MSZ
MS563PKA274MSZ
MS563PKA334MSZ
MS563PKA394MSZ
MS563PKA474MSZ
Inductance
±20% (µH)
0.3
0.9
1.2
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
2
®
Document MS196-1 Revised 04/22/11
1102 Silver Lake Road
Cary, IL 60013
Phone 800-981-0363
Fax 847-639-1508
Email cps@coilcraft.com
www.coilcraft-cps.com
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specifications subject to change without notice.
Please check our web site for latest information.
© Coilcraft, Inc. 2012
