POWER INDUCTORS
High-Reliability Power Inductors
MS598PTA
■
High temperature materials allow operation in ambient
temperatures up to 155°C.
■
Tin-lead (Sn-Pb) termination for the best possible board
adhesion
Core material
Ferrite
Terminations
Tin-lead (63/37) over tin over nickel over phos bronze.
Weight
2.6 – 2.8 g
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
500 per 13″ reel;
Plastic tape: 24 mm wide, 0.4 mm thick, 16 mm pocket spacing,
6.6 mm pocket depth
DCR (mOhm)
3
typ
max
0.77
0.77
2.36
2.36
2.36
5.50
5.50
5.50
9.83
9.83
0.85
0.85
2.60
2.60
2.60
6.05
6.05
6.05
10.81
10.81
SRF (MHz)
4
min
typ
140
112
52.5
35.0
29.4
23.8
22.4
19.6
18.2
16.8
200
160
75.0
50.0
42.0
34.0
32.0
28.0
26.0
24.0
Isat
(A)
5
10% drop 20% drop
36
23
32
17
12
11
9.5
8.0
7.5
6.2
41
27
33
19
13
12
11
9.0
8.5
7.0
Irms
(A)
6
20°C rise 40°C rise
13.0
13.0
9.5
9.5
9.5
7.1
7.1
7.1
5.5
4.4
16.9
16.9
13.0
13.0
13.0
9.4
9.4
9.4
7.6
7.2
Part number
1
MS598PTA331KSZ
MS598PTA651KSZ
MS598PTA102KSZ
MS598PTA182KSZ
MS598PTA272KSZ
MS598PTA402KSZ
MS598PTA472KSZ
MS598PTA602KSZ
MS598PTA802KSZ
MS598PTA103KSZ
Inductance
2
±10% (µH)
0.33
0.65
1.0
1.8
2.7
4.0
4.7
6.0
8.0
10
30% drop
43
28
33.5
20
14
13
12
9.5
9.0
7.5
1. When ordering, please specify
testing
code:
MS598PTA103KSZ
Testing: Z
= COTS
H
= Screening per Coilcraft CP-SA-10001
N
= Screening per Coilcraft CP-SA-10004
C
= Custom screening (please specify when ordering)
2. Inductance measured at 100 kHz, 0.1 Vrms, 0 Adc on an Agilent/HP 4284A or equivalent.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using an Agilent/HP 8753D network analyzer.
5. Typical DC current at which the inductance drops 10% (typ) from its value without current.
6. Typical current that causes a 40°C temperature rise from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
Specifications subject to change without notice.
Please check our website for latest information. Document MS290-1
Revised 09/29/10
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2010
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
POWER INDUCTORS
MS598PTA Series
Typical L vs Frequency
12
11
10
9
10.0 µH
Typical L vs Current
12
11
10
9
8
7
6
5
4
3
2
1
0
6.0 µH
4.7 µH
4.0 µH
1.8 µH
1.0 µH
8.0 µH
10.0 µH
Inductance (µH)
8
7
6
5
4
3
2
1
0
0.01
0.1
8.0 µH
6.0 µH
4.7 µH
4.0 µH
1.8 µH
1.0 µH
0.33 µH
Inductance (µH)
0.33 µH
1
10
0.1
1
10
100
Frequency (MHz)
Current (A)
0.500 ±0.012
12,7 ±0,3
Current Derating
120
110
1
2
Percent of rated current
100
90
80
70
60
50
40
20
10
0
-40 -20
0.496 ±0.012
12,6 ±0,3
3
Terminal 3 is for
mounting stability only.
Isat
Irms
0
20
25°C
30
0.215 ±0.014
5,45 ±0,35
0.006 / 0,152
40
60
80
100
120 140 160
Ambient temperature (°C)
0.110 ±0.008
2,8 ±0,2
Temperature Rise vs Current
10.0 µH
8.0 µH
6.0 µH
4.7 µH
4.0 µH
1.8 µH
1.0 µH
0.33 µH
80
0.173 ±0.008
4,4 ±0,2
0.110 ±0.008
2,8 ±0,2
0.094 ±0.008
2,4 ±0,2
Temperature rise (from 25°C)
70
60
50
40
30
20
10
0
0
5
0.070 ±0.008
1,78 ±0,2
0.367 ±0.008
9,32 ±0,2
0.063 ±0.008
1,60 ±0,2
0.089
2,26
0.121
3,07
0.163
4,14
0.121
3,07
2
1
0.330
8,38
0.089
2,26
Recommended
Land Pattern
3
0.109
2,77
10
15
20
25
Dimensions are in
inches
mm
Current (A rms)
®
Specifications subject to change without notice.
Please check our website for latest information. Document MS290-2
Revised 09/29/10
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2010
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
