1278 POWER INDUCTORS
Outgassing Compliant Power Inductors
AE612PNB
■
High current, low DCR shielded power inductors
■
Passes NASA low outgassing specifications
■
High temperature materials allow operation in ambient
temperatures up to 165°C.
■
Tin-lead (Sn-Pb) terminations for the best possible board
adhesion
Core material
Ferrite
Terminations
Tin-lead (63/37) over tin over nickel over phos bronze.
Weight:
3.8 g – 4.6 g
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
500/13″ reel;
Plastic tape: 24 mm wide, 0.4 mm thick, 16 mm pocket spacing,
8.1 mm pocket depth
DCR
3
Inductance
2
(mOhms)
(µH)
typ
max
1.0 ±30%
6.3
7.0
1.4 ±30%
8.8
9.8
2.2 ±30%
9.4 10.5
2.7 ±30% 10.1 11.3
3.9 ±30% 11.7 13.0
4.7 ±20% 13.9 15.5
5.6 ±20% 15.7 17.5
6.8 ±20% 19.1 21.3
8.2 ±20% 20.3 22.6
10 ±20%
21.8 24.3
12 ±20%
23.2 25.8
15 ±20%
27.9 31.0
18 ±20%
30.8 34.3
22 ±20%
35.5 39.5
27 ±20%
45.0 50.0
33 ±20%
61.9 68.8
39 ±20%
69.1 76.8
47 ±20%
72.3 80.4
56 ±20%
80.2 89.2
68 ±20%
91.3 101.5
82 ±20%
125.9 139.9
100 ±20% 135.1 150.2
120 ±10% 182.3 202.6
150 ±10% 216.5 240.6
180 ±10% 229.0 254.5
220 ±10% 323.6 359.6
270 ±10% 415.6 461.8
330 ±10% 487.3 541.5
390 ±10% 533.6 592.9
470 ±10% 707.5 786.2
560 ±10% 777.4 863.8
680 ±10% 1045 1162
820 ±10% 1166 1296
1000 ±10% 1334 1482
®
Part number
1
AE612PNB102NSZ
AE612PNB142NSZ
AE612PNB222NSZ
AE612PNB272NSZ
AE612PNB392NSZ
AE612PNB472MSZ
AE612PNB562MSZ
AE612PNB682MSZ
AE612PNB822MSZ
AE612PNB103MSZ
AE612PNB123MSZ
AE612PNB153MSZ
AE612PNB183MSZ
AE612PNB223MSZ
AE612PNB273MSZ
AE612PNB333MSZ
AE612PNB393MSZ
AE612PNB473MSZ
AE612PNB563MSZ
AE612PNB683MSZ
AE612PNB823MSZ
AE612PNB104MSZ
AE612PNB124KSZ
AE612PNB154KSZ
AE612PNB184KSZ
AE612PNB224KSZ
AE612PNB274KSZ
AE612PNB334KSZ
AE612PNB394KSZ
AE612PNB474KSZ
AE612PNB564KSZ
AE612PNB684KSZ
AE612PNB824KSZ
AE612PNB105KSZ
SRF
4
Isat
(A)
5
Irms
(A)
6
1. When ordering, please specify
testing
code:
(MHz)
10% 20% 30% 20°C 40°C
AE612PNB105KSZ
min typ
drop drop drop rise rise
Testing: Z
= COTS
80 115
31.84 35.04 36.84 7.1 10.1
H
= Screening per Coilcraft
60
85
25.04 27.76 29.52 6.8 9.8
CP-SA-10001
42
60
22.56 24.80 25.96 6.3 9.2
N
= Screening per Coilcraft
28
40
18.76 20.72 22.04 6.1 8.6
CP-SA-10004
25
35
16.52 18.24 19.20 5.7 7.7
2. Inductance tested at 100 kHz, 0.1 Vrms,
0 Adc using an Agilent/HP 4263B LCR
23
33
15.30 16.90 17.76 4.3 6.2
meter or equivalent.
21
30
13.38 14.86 15.74 4.3 6.2
16
23
12.10 13.56 14.20 4.2 6.0
3. DCR measured on a micro-ohmmeter and a
Coilcraft CCF858 test fixture.
14
20
11.38 12.60 13.28 4.1 5.9
4. SRF measured using an Agilent/HP 8753D
12
17
10.62 11.82 12.48 4.0 5.7
network analyzer.
11
15
8.90 9.88 10.44 3.7 5.2
5. Typical DC current at which the inductance
9.0 13
8.36 9.32 9.94 3.5 4.9
drops the specified amount from its value
8.4 12
8.00 8.88 9.36 3.0 4.5
without current.
7.7 11
7.08 7.88 8.34 2.9 4.0
6. Typical current that causes the specified
7.0 10
6.32 7.08 7.54 2.6 3.6
temperature rise from 25°C ambient.
6.6
9.5
5.96 6.56 6.98 2.3 3.1
7. Electrical specifications at 25°C.
6.0
8.5
5.38 5.94 6.28 2.1 3.0
Refer to Doc 362 “Soldering Surface Mount
5.3
7.5
4.76 5.40 5.66 2.0 2.9
Components” before soldering.
4.9
7.0
4.40 4.98 5.30 1.9 2.7
4.6
6.5
3.92 4.46 4.74 1.8 2.6
3.5
5.0
3.66 4.08 4.38 1.6 2.3
3.1
4.5
3.12 3.56 3.78 1.5 2.2
3.0
4.3
3.02 3.36 3.58 1.4 1.9
2.9
4.1
2.60 2.94 3.10 1.3 1.8
2.8
4.0
2.36 2.68 2.84 1.2 1.7
2.4
3.4
2.24 2.50 2.62 1.0 1.6
2.2
3.1
1.94 2.18 2.34 0.90 1.2
2.0
2.9
1.72 1.92 2.06 0.80 1.0
1.9
2.7
1.62 1.82 1.92 0.75 1.0
1.6
2.2
1.44 1.64 1.74 0.66 0.90
1.4
2.0
1.40 1.54 1.66 0.60 0.80
1.2
1.7
1.24 1.32 1.46 0.55 0.75
1.0
1.4
1.14 1.28 1.42 0.50 0.70
0.90 1.3
0.982 1.08 1.18 0.48 0.68
Specifications subject to change without notice.
Please check our website for latest information.
Document AE598-1 Revised 07/26/11
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2011
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
