POWER INDUCTORS
High-Reliability Power Inductors
ML566PNB
■
High current, low DCR shielded power inductors
■
High temperature materials allow operation in ambient
temperatures up to 155°C
Core material
Ferrite
Terminations
Matte tin over nickel over phos bronze.
Weight:
2.3 g – 2.5 g
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Tape and reel packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
200/7″ reel
Plastic tape: 24 mm wide, 0.35 mm thick, 16 mm pocket spacing,
4.7mm pocket depth
Part number
1
ML566PNB102MLZ
ML566PNB152MLZ
ML566PNB272MLZ
ML566PNB332MLZ
ML566PNB472MLZ
ML566PNB562MLZ
ML566PNB682MLZ
ML566PNB822MLZ
ML566PNB103MLZ
ML566PNB123MLZ
ML566PNB153MLZ
ML566PNB183MLZ
ML566PNB223MLZ
ML566PNB273MLZ
ML566PNB333MLZ
ML566PNB393MLZ
ML566PNB473MLZ
ML566PNB563MLZ
ML566PNB683MLZ
ML566PNB823MLZ
ML566PNB104MLZ
ML566PNB124KLZ
ML566PNB154KLZ
ML566PNB184KLZ
ML566PNB224KLZ
ML566PNB274KLZ
ML566PNB334KLZ
ML566PNB394KLZ
ML566PNB474KLZ
ML566PNB564KLZ
ML566PNB684KLZ
ML566PNB824KLZ
ML566PNB105KLZ
DCR
3
Inductance
2
(mOhms)
(µH)
typ
max
1.0 ±20%
5.6
6.3
1.5 ±20%
8.7
9.7
2.7 ±20% 10.3 11.5
3.3 ±20% 15.1 16.8
4.7 ±20% 19.1 21.3
5.6 ±20% 22.1 24.6
6.8 ±20% 24.9 27.7
8.2 ±20% 27.4 30.5
10 ±20%
36.8 40.9
12 ±20%
38.9 43.3
15 ±20%
48.6 54.1
18 ±20%
51.0 56.7
22 ±20%
60.3 67.0
27 ±20%
67.5 75.0
33 ±20%
81.7 90.8
39 ±20%
95.2 105.8
47 ±20%
120.6 134.0
56 ±20%
133.8 148.7
68 ±20%
167.3 185.9
82 ±20%
188.5 209.5
100 ±20%
216.8 240.9
120 ±10%
287.2 319.2
150 ±10%
326.7 363.0
180 ±10%
379.5 421.7
220 ±10%
488.2 542.5
270 ±10%
560.1 622.4
330 ±10%
731.4 812.7
390 ±10%
813.7 904.2
470 ±10%
935.1 1039
560 ±10% 1193 1326
680 ±10% 1370 1523
820 ±10% 1590 1767
1000 ±10% 2090 2323
®
SRF
(MHz)
4
min typ
70.0 100
60.0 85.0
49.0 70.0
46.0 65.0
30.0 42.0
26.0 37.0
23.0 33.0
22.0 31.0
19.0 27.0
17.0 24.0
15.0 22.0
13.0 19.0
12.6 18.0
11.2 16.0
10.5 15.0
9.3 13.3
8.4 12.0
7.4 10.6
6.8
9.7
6.2
8.8
5.6
8.0
5.0
7.2
4.6
6.6
4.1
5.9
3.7
5.3
3.3
4.7
2.9
4.1
2.7
3.8
2.5
3.5
2.1
3.0
2.0
2.8
1.8
2.6
1.7
2.4
Isat
(A)
5
Irms
(A)
6
10% 20% 30% 20°C 40°C
drop drop drop rise rise
18.14 20.64 22.24 6.00 8.00
14.06 15.90 17.08 5.80 7.80
11.66 13.16 14.16 5.00 6.80
9.74 11.08 11.98 4.50 6.30
8.62 9.70 10.42 4.40 6.00
7.62 8.74 9.44 3.95 5.75
7.38 8.36 9.00 3.70 5.20
6.84 7.70 8.32 3.35 4.67
5.88 6.66 7.18 2.85 3.90
5.34 6.04 6.52 2.69 3.65
4.68 5.36 5.78 2.50 3.40
4.32 4.92 5.32 2.41 3.19
3.84 4.34 4.75 2.30 3.14
3.54 4.02 4.32 2.06 2.86
3.24 3.66 3.96 1.90 2.60
3.04 3.46 3.72 1.73 2.39
2.70 3.08 3.34 1.50 2.10
2.46 2.80 3.02 1.44 2.01
2.26 2.54 2.74 1.30 1.80
1.98 2.26 2.46 1.24 1.72
1.84 2.08 2.24 1.19 1.65
1.62 1.86 2.04 1.03 1.42
1.48 1.70 1.82 0.95 1.30
1.36 1.56 1.68 0.89 1.21
1.22 1.38 1.50 0.76 1.00
1.12 1.26 1.36 0.72 0.95
1.00 1.10 1.20 0.65 0.87
0.946 1.00 1.10 0.59 0.79
0.864 0.978 1.00 0.56 0.76
0.776 0.884 0.956 0.50 0.67
0.720 0.818 0.882 0.46 0.62
0.634 0.728 0.792 0.43 0.58
0.594 0.676 0.728 0.36 0.50
1. When ordering, please specify
testing
code:
ML566PNB105KLZ
Testing: Z
= COTS
H
= Screening per Coilcraft
CP-SA-10001
N
= Screening per Coilcraft
CP-SA-10004
2. Inductance measured at 100 kHz, 0.1 Vrms,
0 Adc using a Coilcraft SMD-A fixture in an
Agilent/HP 4263B LCR meter or equivalent.
3. DCR measured on a micro-ohmmeter and a
Coilcraft CCF858 test fixture.
4. SRF measured using an Agilent/HP 8753D
network analyzer.
5. DC current at which the inductance drops
the specified amount from its value without
current.
6. Current that causes the specified tempera-
ture rise from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount
Components” before soldering.
Document ML540-1 Revised 12/05/12
1102 Silver Lake Road
Cary, IL 60013
Phone 800-981-0363
Fax 847-639-1508
Email cps@coilcraft.com
www.coilcraft-cps.com
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specifications subject to change without notice.
Please check our web site for latest information.
© Coilcraft, Inc. 2012
