2.54 mm pitch connector
Female insulator for crimping(Miniature HKP series)
HKP-( )FSA01
●
Configuration of product Part No.
For cable
Crimping
HKP- ( ) F S A01
➀
➁
➂ ➃ ➄
➀
Series name
➁
No. of contacts: 2–50
➂
Type of insulator
F: Female
➃
Alignment of contacts to be inserted
S: Single-row type
➄
Type of HKP series
A: Miniature
●
Dimensions
Part No.
HKP-2FSA01
HKP-3FSA01
14.5
HKP-4FSA01
HKP-5FSA01
HKP-6FSA01
HKP-7FSA01
HKP-8FSA01
HKP-9FSA01
HKP-10FSA01
HKP-11FSA01
HKP-12FSA01
HKP-13FSA01
2.54
HKP-14FSA01
HKP-15FSA01
HKP-16FSA01
HKP-17FSA01
HKP-18FSA01
HKP-19FSA01
HKP-20FSA01
HKP-21FSA01
HKP-22FSA01
HKP-23FSA01
HKP-24FSA01
HKP-25FSA01
HKP-26FSA01
A
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
63.50
B
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
63.50
66.04
Part No.
HKP-27FSA01
HKP-28FSA01
HKP-29FSA01
HKP-30FSA01
HKP-31FSA01
HKP-32FSA01
HKP-33FSA01
HKP-34FSA01
HKP-35FSA01
HKP-36FSA01
HKP-37FSA01
HKP-38FSA01
HKP-39FSA01
HKP-40FSA01
A
66.04
68.58
71.12
73.66
76.20
78.74
81.28
83.82
86.36
88.90
91.44
93.98
96.52
99.06
B
68.58
71.12
73.66
76.20
78.74
81.28
83.82
86.36
88.90
91.44
93.98
96.52
99.06
101.60
2.54
A
B
HKP-41FSA01
101.60 104.14
HKP-42FSA01
104.14 106.68
HKP-43FSA01
106.68 109.22
HKP-44FSA01
109.22 111.76
HKP-45FSA01
117.26 114.30
HKP-46FSA01
114.30 116.84
HKP-47FSA01
116.84 119.38
HKP-48FSA01
119.38 121.92
HKP-49FSA01
121.92 124.46
HKP-50FSA01
124.46 127.00
Mating connectors:
HKP or FFC series single-row type male connector
For use with contacts:
Miniature HKP series contacts (HKP-F6@3B, HKP-F5@3B, HKP-F7@3B)
Others
Wire
wrapping Crimping Soldering
IDC
Press-in
SMT
Through
hole
