3008 POWER INDUCTORS
High Reliability Power Inductors
MS369PJB
■
High temperature materials allow operation in ambient
temperatures up to 155°C
■
Special construction allows it to pass vibration testing to
80 G and shock testing to 1000 G.
■
Tin-lead (Sn-Pb) termination for the best possible board
adhesion
Core material
Ferrite
Terminations
Tin-lead (63/37) over tin over nickel.
Weight
22 – 25 mg
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Tape and reel packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
1000/7″ reel
Plastic tape: 12 mm wide, 0.23 mm thick, 8 mm pocket spacing,
1.37 mm pocket depth
Recommended pick and place nozzle
OD: 3 mm; ID:
≤1.5
mm
Part number
1
MS369PJB561MSZ
MS369PJB801MSZ
MS369PJB102MSZ
MS369PJB152MSZ
MS369PJB222MSZ
MS369PJB332MSZ
MS369PJB472MSZ
MS369PJB562MSZ
MS369PJB682MSZ
MS369PJB822MSZ
MS369PJB103MSZ
MS369PJB123MSZ
MS369PJB183MSZ
MS369PJB223MSZ
MS369PJB333MSZ
MS369PJB473MSZ
MS369PJB683MSZ
MS369PJB104MSZ
MS369PJB124MSZ
MS369PJB154MSZ
MS369PJB184MSZ
MS369PJB224MSZ
MS369PJB334MSZ
Inductance
2
±20% (µH)
0.56
0.80
1.0
1.5
2.2
3.3
4.7
5.6
6.8
8.2
10
12
18
22
33
47
68
100
120
150
180
220
330
DCR max
3
(Ohms)
0.072
0.092
0.125
0.134
0.175
0.285
0.350
0.450
0.500
0.600
0.650
0.790
1.25
1.50
2.30
3.00
4.75
6.85
7.00
8.00
9.00
11.50
18.00
SRF (MHz)
4
min
typ
231
330
178
255
154
220
119
170
105
150
79.8
114
60.9
87
54.6
78
52.5
75
42.7
61
39.2
56
34.3
49
26.6
38
24.5
35
16.1
23
14.7
21
12.6
18
9.8
14
9.1
13
7.7
11
7.0
10
6.3
9
4.9
7
10% drop
1.8
1.6
1.3
1.1
1.0
0.81
0.68
0.62
0.58
0.52
0.46
0.45
0.35
0.29
0.27
0.22
0.18
0.15
0.084
0.080
0.070
0.067
0.059
Isat
(A)
5
20% drop
2.0
1.7
1.4
1.3
1.1
0.86
0.73
0.67
0.61
0.56
0.51
0.48
0.38
0.33
0.30
0.23
0.19
0.16
0.094
0.088
0.078
0.073
0.064
30% drop
2.1
1.8
1.5
1.3
1.1
0.88
0.74
0.70
0.63
0.58
0.52
0.50
0.40
0.34
0.31
0.24
0.20
0.16
0.10
0.092
0.082
0.076
0.066
Irms
(A)
6
20°C rise 40°C rise
1.1
1.6
0.88
1.3
0.72
1.0
0.70
0.96
0.68
0.88
0.59
0.76
0.54
0.64
0.46
0.58
0.40
0.54
0.36
0.48
0.34
0.45
0.30
0.40
0.26
0.35
0.23
0.30
0.20
0.26
0.17
0.22
0.14
0.18
0.13
0.17
0.11
0.15
0.10
0.14
0.10
0.13
0.080
0.12
0.070
0.10
1.When ordering, please specify
testing
code:
MS369PJB104MSZ
Testing: Z
= COTS
H
= Screening per Coilcraft CP-SA-10001
N
= Screening per Coilcraft CP-SA-10004
2. Inductance tested at 100 kHz, 0.1 Vrms using an Agilent/HP 4192A or
equivalent.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using an Agilent/HP 8753ES or equivalent.
5. Typical DC current at which the inductance drops the specified amount
from its value without current.
6. Typical current that causes the specified temperature rise from 25°C
ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
Specifications subject to change without notice.
Please check our website for latest information.
Document MS438-1
Revised 08/11/11
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2011
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
