PEMA Series
CHASSIS MOUNT, MULTI-STAGE EMI/RFI APPLIANCE FILTER
MECHANICAL DIMENSIONS
(Unit: mm)
C2
38.6
L
65.5
L'
2x 4.8
52.8
N
74.7
84.4
N'
28.6
G
FEATURES
The PEMA series offers high performance EMI filters. This
series offers multiple stages of filtration over a frequency
range of 10KHz to 30MHz. It is best suited for suppression
of noise and transients entering system from Line. The series
also offers filters that offer exceptional performance in the
systems where the Load impedance is low.
C4
2x 5.0
L
19.0
49.0
N
133.5
40.0
69.8
144.0
152.0
162.9
N'
L'
APPLICATIONS
Major Appliances, Measuring & control equipment,
Switching power supplies.
TECHNICAL DATA
G
•
Rated Voltage: 115/250VAC
•
Rated Current: 4A, 5A, 6A, 8A, 10A, 15A
•
Power Line Frequency: 50/60Hz
•
Max. Leakage Current each
Line to Ground:
@ 115VAC 60Hz: 0.5mA
@ 250VAC 50Hz: 1.0mA
•
Hipot Rating (one minute)
Line to Ground: 2250VDC
Line to Line: 1450VDC
•
Temperature Range: -25C to +85C
C9
50.6
25.0
L
L'
N
N'
30.0
50.0
90.0
99.5
109.0
119.4
G
Specifications subject to change without notice. Dimensions (mm).
145 Algonquin Parkway, Whippany, NJ 07981 • 973-560-0019 • FAX: 973-560-0076
e-mail: filtersales@powerdynamics.com •
www.powerdynamics.com
47
PEMA Series
Non-Medical Applications
Insertion loss in dB (50 Ohm circuit)
PDI
P/N
PEMA04Q-1-AC2
PEMA06Q-1-BC2
PEMA06Q-1-CC2
PEMA05Q-2-AC2
PEMA08Q-4-AC2
PEMA06Q-1-AC9
PEMA06Q-4-AC9
PEMA10Q-2-AC4
PEMA06Q-3-AC4
PEMA06Q-4-AC4
PEMA06Q-4-AC4
PEMA15Q-4-AC4
PEMA10Q-5-AC4
Current
Rating (A)
4
6
6
5
8
6
6
10
6
6
6
15
10
R
(Ohms)
Cx 1,2,3
(uF)
1.4
2.04
1.68
0.66
1.15
6.6
3.2
6.6
8.8
1.15
3.2
3.2
3.67
Cy
(pF)
9400
9400
9400
5080
7960
6600
7960
7960
7960
7960
7960
7960
9400
L 1,2,3
(mH x 2)
24
22
22
13
5
44
24
21
45
8.5
24
6
20.6
Comm. Mode (L-G) in MHz
.15 .5
1
5
10 30
80
86
78
51
41
62
49
83
84
58
49
49
85
94
65
86
76
78
49
75
85
84
78
76
87
91
82
59
81
89
76
46
89
97
93
76
88
81
84
67
48
67
72
76
45
68
64
64
66
69
63
72
60
38
60
60
60
40
56
53
52
53
57
51
62
43
26
32
39
42
40
39
33
32
42
40
33
50
Diff. Mode (L-L) in MHz
.15 .5
1
5
10
30
59
66
73
41
84
90
86
81
89
86
85
81
88
77
77
79
48
83
84
89
88
88
85
87
87
89
76
76
76
53
79
80
95
103
100
79
96
95
86
74
51
80
54
73
65
68
58
60
62
69
58
75
52
18
49
54
47
38
46
37
39
38
45
38
52
18
26
22
25
24
28
24
26
27
29
29
26
16
330K
50K
SCHEMATIC 1
L
LINE
L mH
L mH
Cy
L1
L mH
Cy
R
L'
LOAD
SCHEMATIC 4
L mH
L
LINE
L mH
Cy
L1
L mH
Cy
L2
L mH
L mH
L3
L mH
L'
C
1
N
G
C
2
L2
L mH
C
3
N'
C
1
N
G
R
C
2
Cy
N'
SCHEMATIC 2
L
LINE
SCHEMATIC 5
L mH
Cy
Cy
L'
LOAD
L mH
L mH
L
LINE
L mH
R
L mH
Cy
Cy
L
3
L mH
L mH
L
4
L mH
C
1
N
G
L1
L mH
R
C
2
Cy
L2
L mH
C
3
N'
C
1
N
G
L1
L mH
C
2
L
2
C
3
L mH
C
4
N'
SCHEMATIC 3
L mH
L
LINE
R
N
G
L mH
L mH
Cy
Cy
L'
LOAD
Cy
Cy
N'
C
1
L1
C
2
L2
L mH
C
3
