Self Bias Network
Functional Application
Benefits
•
Wireless communication modules
•
MIC broadband high gain RF/Microwave modules
•
Bias line voltage divider and integrated decoupling capacitor
Physical Characteristics
•
Improves gain flatness and stability in GaAs FET
•
Simplifies assembly with 1 component
•
Miniature size: .020 x .034 (.5mm x .86mm)
Equivalent Schem atic Representation
Typical application requires 2 networks
Recom m ended M ounting:The
self Bias N etwork should be
mounted with fully metalized side down directly on the RF
ground plane for best performance.
Product N um ber I
dentification
B
Product
B=Bias N etwork
28
Width
28
BJ
Material
BJ+/-15% TC
SBN 01
N etwork Type
Physical Characteristics
Typical Application
Custom N etworks can be designed per customer specification. Please consult factory for additional information or special requirements.
21
Bias Filter Network
Functi
onalA pplcati
i on
Benefi
ts
•
W ireless com m unication m odules
•
Idealvaractor decoupling elem ent
•
H igh gain RF/M icrowave m odules
•
IdealG aAs FET gate biasing device
•
M M IC m ultichip m odules
Physi Characteri cs
cal
sti
•
Filters noise and RF from Supplies
•
Reduces RF feedback through bias supplies
•
Sim plifies assem bly -one com ponent replaces m any
•
D esigned with large 4 m ilwirebond pads for assem bly ease
Equi entSchem ati Representati
val
c
on
TotalSeri Resi
es
stance:
600 nom inal
TotalShuntCapaci
tance:
BT m aterial-140pF nom inal
BH m aterial-95pF nom inal
D C Rati
Vol M ax:50V
ng:
ts
I m a)M
ax:10M a
(
Recom m ended M ounti
The Bias Fil Network shoul be
ng:
ter
d
m ounted with f l m etalized side down directl on RF ground
uly
l
y
pl f m axim um isol
ane or
ation perf ance.
orm
ProductNum berI
denti cati
fi on
B
Product
B=Bias Network
20
W idth
28
BL
M aterial
BL +/-25% TC
BFN01
Network Type
I ati vs.Frequency
sol on
Typi A pplcati
cal
i on
Custom Networks can be designed per custom er specif
ication. Pl
ease consul f
t actory f additionalinf ation or specialrequirem ents.
or
