DMF-2A-1500: DescriptionDouble Balanced Mixer, 700MHz Min, 2000MHz Max, 9dB Conversion Loss-Max, Hybrid, 8 PIN; CategoryWireless rf/communication Radio frequency and microwave; File Size124KB，1 Pages; ManufacturerMerrimac Industries（Crane）; Websitehttp://www.craneae.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

DMF-2A-1500 Overview

Double Balanced Mixer, 700MHz Min, 2000MHz Max, 9dB Conversion Loss-Max, Hybrid, 8 PIN

DMF-2A-1500 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Merrimac Industries（Crane）
package instruction	FL8,.39,150/100
Reach Compliance Code	unknown
Characteristic impedance	50 Ω
Maximum frequency conversion loss	9 dB
Maximum input power (CW)	24.77 dBm
Installation features	SURFACE MOUNT
Number of terminals	8
Maximum operating frequency	2000 MHz
Minimum operating frequency	700 MHz
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	FL8,.39,150/100
RF/Microwave Device Types	DOUBLE BALANCED
surface mount	YES
technology	HYBRID

Preview

Download Datasheet

View All

DMF-2A Series

UBLEBALANC D MIXE S

500 kHz to 3 G / + 7 to +13 dBmLO/ Flatpack

PERFORMANCE SPECIFICATIONS

Model

Number

DMF-2A-250

RF/LO

Frequency,

MHz

0.50 - 500

Frequency,

MHz

DC - 500

Operating

Range,

MHz

0.5 - 1.0

1.0 - 300

300 - 500

10 - 50

50 - 500

500 -1000

10 - 600

600 -1000

1000 -1500

50 - 500

500 - 1400

700 - 1000

1000 - 2000

500 - 2000

1000 - 2000

2000 - 3000

Conversion

Loss, dB,

Max. Typ.

8.0

7.0

8.0

7.5

8.5

8.0

9.5

9.0

8.0

9.5

7.0

6.0

7.0

6.5

7.5

7.0

8.5

7.5

8.0

7.0

6.0

7.0

8.0

Port Isolation, Min.

L-R

L-X

––

R-X

Sense

Pos.

DMF-2A-505

10 - 1000

DC - 1000

Pos.

DMF-2A-700

10 - 1500

DC - 1000

Neg.

DMF-2A-750

DMF-2A-1500

DMF-2A-1700

DMF-2A-2000

50 - 1400

700 - 2000

500 - 2000

1000 - 3000

DC - 1000

DC - 300

DC - 1000

Pos.

Neg.

All specifications are as measured in a 50Ω system, at nominal LO power, in a down converter application

Package Outline

GENERAL SPECIFICATIONS

+7 dBm nom.

Ω

nom.

Within

±1

dB of

Conversion Loss

Maximum Input Power: 300 mW @ 25°C

LO Drive:

Impedance:

Noise Figure:

(Derate linearly to 0 mW @ 125°C)

1 dB Compression Point: 0 dBm input, typ.

Input Intercept Point:

+12 dBm, typ.

NOTES:

1. Tolerance on 3 place decimals

±.010(.25)

except as noted.

2. Dimensions in inches over millimeters.

3. Dimensions marked with * apply only at body.

4. All unmarked pins are case ground.

General Notes:

The DMF-2A series uses a four diode configura-

tion for both general purpose and high perform-

ance applications.

22Feb96

RRIMAC/ 41 Fairfield Pl., West Caldwell, NJ, 07006 /

F further inform

ation contact

973-575-1300

/ FAX

973-575-0531

DMF-2A-1500 Related Products

	DMF-2A-1500	DMF-2A-505	DMF-2A-700	DMF-2A-1700	DMF-2A-750	DMF-2A-2000
Description	Double Balanced Mixer, 700MHz Min, 2000MHz Max, 9dB Conversion Loss-Max, Hybrid, 8 PIN	Double Balanced Mixer, 10MHz Min, 1000MHz Max, 8.5dB Conversion Loss-Max, Hybrid, 8 PIN	Double Balanced Mixer, 10MHz Min, 1500MHz Max, 9.5dB Conversion Loss-Max, Hybrid, 8 PIN	Double Balanced Mixer, 500MHz Min, 2000MHz Max, 8dB Conversion Loss-Max, Hybrid, 8 PIN	Double Balanced Mixer, 50MHz Min, 1400MHz Max, 9dB Conversion Loss-Max, Hybrid, 8 PIN	Double Balanced Mixer, 1000MHz Min, 3000MHz Max, 9.5dB Conversion Loss-Max, Hybrid, 8 PIN
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	FL8,.39,150/100	FL8,.39,150/100	FL8,.39,150/100	FL8,.39,150/100	FL8,.39,150/100	FL8,.39,150/100
Reach Compliance Code	unknown	unknow	unknown	unknown	unknown	unknown
Characteristic impedance	50 Ω	50 Ω	50 Ω	50 Ω	50 Ω	50 Ω
Maximum frequency conversion loss	9 dB	8.5 dB	9.5 dB	8 dB	9 dB	9.5 dB
Maximum input power (CW)	24.77 dBm	24.77 dBm	24.77 dBm	24.77 dBm	24.77 dBm	24.77 dBm
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Number of terminals	8	8	8	8	8	8
Maximum operating frequency	2000 MHz	1000 MHz	1500 MHz	2000 MHz	1400 MHz	3000 MHz
Minimum operating frequency	700 MHz	10 MHz	10 MHz	500 MHz	50 MHz	1000 MHz
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Encapsulate equivalent code	FL8,.39,150/100	FL8,.39,150/100	FL8,.39,150/100	FL8,.39,150/100	FL8,.39,150/100	FL8,.39,150/100
RF/Microwave Device Types	DOUBLE BALANCED	DOUBLE BALANCED	DOUBLE BALANCED	DOUBLE BALANCED	DOUBLE BALANCED	DOUBLE BALANCED
surface mount	YES	YES	YES	YES	YES	YES
technology	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID
Maker	Merrimac Industries（Crane）	Merrimac Industries（Crane）	Merrimac Industries（Crane）	-	-	Merrimac Industries（Crane）
