42R02-3221-100: Description15A, 250V AC, MALE, MAINS POWER CONNECTOR, SOLDER; Categorysemiconductor Other integrated circuit (IC); File Size34KB，1 Pages; ManufacturerPower Dynamics, Inc.; Websitehttp://www.powerdynamics.com/

Download Datasheet View All

42R02-3221-100 Overview

15A, 250V AC, MALE, MAINS POWER CONNECTOR, SOLDER

Preview

Download Datasheet

View All

MATERIAL AND FINISH:

Insulator: Polycarbonate, UL-94V-0 rated

Contacts: Brass, Nickel plated

27.5+0.2

15A

250V~

D E

27.0+0.2

ORDERING CODE:

42R02-3 __ __ __ - __ __ __

1 2 3

31.0±0.2

SEE OPTION 1

0.80

1 = TERMINAL OPTIONS

1 = .187(4.8) (NOT TOOLED)

2 = .250(6.3)

2 = COLOR

1 = BLACK

2 = GRAY

3 = ELECTRICAL CIRCUIT

CONFIGURATION

1 = 15A 250V 120°C

2+GROUND

4.00

10A250V~

19.0

REPLACE WITH

CORRESPONDING

PANEL THICKNESS

2.0±0.05

D E

2 = 15A 250V 70°C

2+GROUND

CHNG CHCK APPR

14±0.2

4 = 15A 250V 70°C

2 POLE

ADD 1.0mm SNAP IN TAB

24+0.5

TOLERANCE

UNLESS OTHERWISE SPECIFIED

X ± 1

X.X ± 0.4

X.XX ± 0.20

REVISIONS

REVISED & UPDATED

4 = PANEL THICKNESS

CHANGE

9/02/04

REV

RoHS

COMPLIANT

3/3/09

DATE

PDI

42R02

ELECTRICAL SPECIFICATIONS:

Current rating: 10 A

Voltage rating: 250 VAC

Current rating: 15 A

Voltage rating: 250 VAC

24.0

19.5

20.0+0.2

R4.0 TYP.

RECOMMENDED

PANEL CUTOUT

A+0.2 17.0

12 15

19.0

3.0

SECTION A-A

4.0±0.1

16+0.5

P/N

1.0

42R02-3XXX-100 1.0

42R02-3XXX-150 1.5

1.5

2.0

42R02-3XXX-200 2.0

2.5

42R02-3XXX-250 2.5

ADDITIONAL PANEL THICKNESS

AVAILABLE ON REQUEST

Phone: 973 560-0019

Whippany, New Jersey

Fax: 973 560-0076

PART: IEC 60320 CONNECTOR; QUICK

CONNECT INLET; SNAP-IN

PART #:

DRAWN

CHECK

APPR

DATE:

8/2/01

08/14/01

SIZE:

SCALE:

42R02-3XXX-XXX

NTS

ALL DIMENSIONS FOR REFERENCE ONLY

DIMENSIONS ARE IN MILLIMETERS

SHEET

1 of 1

REV:
