SAFEB1G74AA0F00R12 datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> filter> SAFEB1G74AA0F00R12

SAFEB1G74AA0F00R12: DescriptionSAW Filter, 1 Function(s), 1747.5MHz, 5 Pin(s), Plastic; CategoryAnalog mixed-signal IC filter; File Size132KB，5 Pages; ManufacturerMurata; Websitehttps://www.murata.com

Download Datasheet Parametric View All

SAFEB1G74AA0F00R12 Overview

SAW Filter, 1 Function(s), 1747.5MHz, 5 Pin(s), Plastic

SAFEB1G74AA0F00R12 Parametric

Parameter Name	Attribute value
Maker	Murata
Reach Compliance Code	compliant
Other features	TAPE AND REEL
Center frequency or cutoff frequency (fo/fc)	1747.5 MHz
filter type	SAW FILTER
high	0.6 mm
input resistance	50 OHM
Maximum insertion loss	2.9 dB
length	1.35 mm
Manufacturer's serial number	SAFEB1G74AA0F00
Installation type	SURFACE MOUNT
Number of functions	1
Number of terminals	5
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Output impedance	50 OHM Ω
Packaging Materials	PLASTIC
physical size	L1.35XB1.05XH0.6 (mm)/L0.053XB0.041XH0.024 (inch)
width	1.05 mm

Preview

Download Datasheet

View All

SAW FILTER FOR Band3 Tx

Murata part number : SAFEB1G74AA0F00

Package Dimensions

Specification

Item

Specification

-30 to 85°C

25±2°C

1747.5MHz

2.9 dB max.

2.3 dB max.

2.0 dB

typ.

1.35±0.05

(5)

(1)

Dot Marking(φ0.3)

(4)

Nominal Center Frequency(fc)

Insertion Loss

(1710 to 1785MHz)

Absolute Attenuation

0.1 to

1670 to

1805 to

1880 to

3000 to

3600 to

5000 to

1670 MHz

1690 MHz

1880 MHz

3000 MHz

3600 MHz

5000 MHz

6000 MHz

20 dB min.

12 dB min.

20 dB min.

35 dB min.

28 dB min.

25 dB min.

S 9

(2)

(3)

1.05±0.05

20 dB min.

14 dB min.

20 dB min.

35 dB min.

28 dB min.

25 dB min.

29 dB

21 dB

26 dB

43 dB

33 dB

30 dB

(0.20)

0.6max.

5-0.325±0.050

2-0.25±0.05

(0.075)

(2)

(1)

(5)

(3)

Ripple Deviation

(1710 to 1785MHz)

VSWR

(1710 to 1785MHz)

2.2 dB max.

1.4 dB max.

1.2dB

2.4 max.

2.3 max.

50Ω

2.1

(0.05)

2-0.25±0.05

(4)

5-0.25±0.05

2-0.25±0.05

Unbalance Port Matching Impedance

(nominal)

Input Signal Level

20mW (+13dBm), 2000 hours

Marking

: Laser Printing

(1) : Unbalance Port

(4) : Unbalance Port

Others : Ground

Unit : mm

Aug 30, 2010

1/5
