IBC Module
IB054Q120T53N1-00
4:1 Intermediate Bus Converter Module: Up to 650 W Output
Features
•
Input: 36 – 60 Vdc
•
Output: 12 Vdc at 48 Vin
•
Output current: up to 53 A
Size:
2.30 x 1.45 x 0.42 in
58,4 x 36,8 x 10,6 mm
•
97.8% peak efficiency
•
Low profile: 0.42” height above board
•
Industry standard 1/4 Brick pinout
[A]
•
Output power: up to 650 W
•
2,250 Vdc isolation
[A]
•
Sine Amplitude Converter
•
Low noise 1 MHz ZVS/ZCS
For lower power applications see 300 W model IB054E120T32N1-00 or 500 W model IB054E120T40N1-00
Product Overview
The Intermediate Bus Converter (IBC) Module is a very efficient, low profile, isolated, fixed
ratio converter for power system applications in enterprise and optical access networks.
Rated at up to 477 W from 36 Vin and up to 650 W from 50 to 60 Vin, the IBC
conforms to an industry standard quarter-brick footprint while supplying power greatly
exceeding competitive quarter-bricks. Its leading efficiency enables full load operation
at 55 °C with only 200 LFM airflow. Its small cross section facilitates unimpeded
airflow — above and below its thin body — to minimize the temperature rise of
downstream components.
Applications
•
Enterprise networks
•
Optical access networks
•
Storage networks
•
Automated test equipment
Absolute Maximum Ratings
Min
Input voltage (+In to –In)
Operating
36
60
75
Input voltage slew rate
EN to –IN
Output voltage (+Out to –Out)
Output current
Dielectric withstand
(input to output)
Temperature
Operating junction
Storage
-40
-55
125
125
°C
°C
Hottest Semiconductor
2,250
-0.5
-0.5
5
20
17.2
53
Vdc
Vdc
V/μs
Vdc
Vdc
A
Vdc
Pout
≤
650 W
1 min.
18.75 for 100 mS
<100 mS
Max
Unit
Notes
IBC MODULE
Page 1 of 14
Rev 1.6
11/2012
vicorpower.com
800 735.6200
IB054Q120T53N1-00
SPECIFICATIONS
All specifications valid at 48 V
IN
, 100% rated load and 25 °C ambient, unless otherwise indicated.
Electrical Characteristics
Attribute
INPUT
(Operating from DC input source)
Operating input voltage
Operating input surge withstand
Operating input dV/dt
Undervoltage protection
Turn-on
Turn-off
Turn-on/ Turn-off hysteresis
Time constant
Undervoltage blanking time
Overvoltage protection
Turn-off
Turn-on
Time constant
Turn ON delay
Start up inhibit
Turn-on delay
Output voltage rise time
Restart turn-on delay
No Load power dissipation
Enabled
Disabled
Input current
Inrush current overshoot
Input reflected ripple current
Peak short circuit input current
Repetitive short circuit peak current
Internal input capacitance
Internal input inductance
Recommended external
input capacitance
OUTPUT
DC Output voltage band
Output power
[a]
36-55 V
IN
48-55 V
IN
50-60 V
IN
Output current
Output start up load
Effective output resistance
Line regulation (K factor)
Current share accuracy
No load, over Vin range
9.0
0
0
0
P
≤
650 W
of Iout max, maximum output capacitance
V
OUT
= K • V
IN
@ no load
Full power operation; See Parallel Operation
on page 11; up to 3 units
0.245
3.9
0.250
12.0
15.0
477
600
650
53
15
0.252
10
V
W
W
W
A
%
mΩ
%
V
IN
reaching turn-on voltage
to enable function operational, see Figure 6
Enable to 10% V
OUT
; pre-applied V
IN
,see Figure 7
0 load capacitance
From 10% to 90% Vout, 10%
load, 0 load capacitance
See page 10 for restart after EN pin disable
20
25
30
50
50
250
4.0
0.15
Using test circuit in Figure 21, 15% load, highline
At max power;
Using test circuit in Figure 22
13
5.0
0.20
13.5
18.9
650
45
25
17.6
5
200 nH maximum source inductance
47
470
ms
µs
µs
ms
W
W
A
A
mArms
A
A
μF
nH
μF
36
<100 mS
0.003
31
29
2
UV blanking time is enabled after startup
50
76
75
100
48
60
75
5
36
34
7
200
79.5
78
4
Vdc
Vdc
V/us
Vdc
Vdc
Vdc
µs
µs
Vdc
Vdc
µs
Symbol
Conditions / Notes
Min
Typ
Max
Unit
IBC MODULE
Page 2 of 14
Rev 1.6
11/2012
vicorpower.com
800 735.6200
IB054Q120T53N1-00
SPECIFICATIONS (CONT.)
All specifications valid at 48 V
IN
, 100% rated load and 25 °C ambient, unless otherwise indicated.
Electrical Characteristics
(Continued)
Attribute
OUTPUT
(Continued)
Efficiency
50% load
Full load
Internal output inductance
Internal output capacitance
Load capacitance
Output OVP set point
Output voltage ripple
Output Overload protection threshold
Over current protection time constant
Short circuit current response time
Switching frequency
Transient Response
Voltage overshoot & undershoot
Response time
V
IN
step
Pre-bias voltage
[a]
Symbol
Conditions / Notes
Min
Typ
Max
Unit
See Figure 1,2 and 3
See Figure 1,2 and 3
97.5
97.0
97.8
97.3
1.6
75
3,000
17.2
60
150
150
1.2
1.5
1.0
Nominal load
Module will shutdown
20 MHz bandwidth, using test circuit in
Figure 23
Of Iout max., will not shutdown when started
into max Cout; and 15% load
Auto restart with duty cycle <10%
0
16.2
%
%
nH
μF
μF
Vdc
mVp-p
%
ms
µs
MHz
mV
µS
V
Vdc
105
25% load step; 1A /μS; See Figures 11–14
See Figures 11–14
5 V step in 1
μS
within Vin operating range
Unit will start up
into pre-bias voltage on output
100
1
1.25
0
15
Does not exceed IPC-9592 derating guidelines. At 70 °C ambient, full power operation may exceed IPC-9592 guidelines, but does not exceed
component ratings, does not activate OTP and does not compromise reliability.
General Characteristics
Attribute
MTBF
Service life
Over temperature shut down
Dielectric withstand
Insulation resistance
Mechanical
Weight
Length
Width
Height above customer board
Clearance to customer board
Agency approvals
(pending for baseplate version)
Altitude, operating
Relative humidity, Operating
RoHS compliance
Conditions: 25 °C case, 75% rated load and specified input voltage range unless otherwise specified.
Symbol
Conditions / Notes
Calculated per Telcordia SR-332, 40°C
Calculated at 30°C
T
J
; Converter will reset when over
temperature condition is removed
Input to output
Input to output
Min
1.0
7
125
2,250
30
1.38 /39.1
2.30 /58.4
1.45 /36.8
0.41/10.5
From lowest component on IBC
UL /cUL 60950-1, EN60950-1, IEC60950-1
Low voltage directive (CE Mark)
Derate operating temp 1 °C
per 1,000 feet above sea level
Non condensing
Compatible with RoHS directive 2002/95/EC
0.12/0.30
130
135
Typ
Max
Unit
Mhrs
Years
°C
Vdc
MΩ
oz/g
in/mm
in/mm
in/mm
in/mm
-500
10
10,000
90
Feet
%
IBC MODULE
Page 3 of 14
Rev 1.6
11/2012
vicorpower.com
800 735.6200
IB054Q120T53N1-00
SPECIFICATIONS (CONT.)
Control & Interface Specifications
Attribute
Enable (negative logic)
Module enable threshold
Module enable current
Module disable threshold
Module disable current
Disable hysteresis
Enable pin open circuit voltage
EN to –IN resistance
Enable (positive logic)
Module enable threshold
Module disable threshold
EN source current (operating)
EN voltage (operating)
Symbol
Conditions / Notes
Referenced to –IN
0.8
V
EN
= 0.8 V
V
EN
= 2.4 V
2.0
Open circuit
Referenced to –IN
2.0
V
EN
= 5 V
4.7
5
500
2.5
35
2.5
130
200
2.4
10
3.0
Vdc
µA
Vdc
µA
mV
Vdc
kΩ
Vdc
Vdc
mA
Vdc
Min
Typ
Max
Unit
3.0
1.45
2
5.3
IPC-9592A, Based on Class II Category 2 the following detail is applicable. – Pre-conditioning required
Environmental Qualification
Test Description
Test Detail
Low Temp
High Temp
Rapid Thermal Cycling
6 DOF Random Vibration Test
Input Voltage Test
Output Load Test
Combined Stresses Test
(72 hr presoak required) 1000 hrs – Continuous Bias
Power cycle - On 42 minutes
Off 1 minute, On 1 minute, Off 1 minute, On 1 minute, Off 1 minute,
On 1 minute, Off 1 minute, On 1 minute, Off 10 minutes. Alternating
between maximum and minimum operating Voltage every hour.
700 cycles , 30 minute dwell at each extreme – 20C minimum ramp rate.
Reference IPC-9592A
Random Vibration – Operating IEC 60068-2-64 (normal operation vibration)
Random Vibration Non-operating (transportation) IEC 60068-2-64
Shock Operating - normal operation shock IEC 60068-2-27
Free fall - IEC 60068-2-32
Drop Test 1 full shipping container (box)
5.2.14.1 Corrosion Resistance – Not required
5.2.14.2 Dust Resistance – Unpotted class II GR-1274-CORE
5.2.14.3 SMT Attachment Reliability IPC-9701 - J-STD-002
5.2.14.4 Through Hole solderability – J-STD-002
Sample size assumes CDM testing
Quantity Tested
3
3
3
3
3
3
3
30
5.2.3 HALT (Highly Accelerated Life testing)
5.2.4 THB (Temp. Humidity Bias)
5.2.5 HTOB (High Temp. Operating Bias)
30
5.2.6 TC (Temp. Cycling)
5.2.7 Power Cycling
30
3
3
3
3
3
12
N/A
3
3
5
12
161
5.2.8 – 5.2.13 Shock and Vibration
5.2.14 Other Environmental Tests
ESD Classification Testing
Total Quantity
IBC MODULE
Page 4 of 14
Rev 1.6
11/2012
vicorpower.com
800 735.6200
IB054Q120T53N1-00
SPECIFICATIONS (CONT.)
WAVEFORMS
99%
98%
Efficiency T
AMB
25 °C
99%
98%
Efficiency T
AMB
55 °C
Efficiency (%)
Efficiency (%)
97%
96%
95%
94%
93%
92%
5
16
V
IN
:
38 V
27
37
55 V
48
97%
96%
95%
94%
93%
92%
5
16
V
IN
:
38 V
27
37
48 V
55 V
48
Iout (A)
48 V
Iout (A)
Figure 1
— Efficiency vs. output current, 25 °C ambient
Figure 2
— Efficiency vs. output current, 55 °C ambient
99%
98%
Efficiency T
AMB
70 °C
Efficiency (%)
97%
96%
95%
94%
93%
92%
5
16
V
IN
:
38 V
27
37
48 V
55 V
48
Iout (A)
Figure 3
— Efficiency vs. output current, 70 °C ambient
Figure 4
— Inrush current at high line 15% load; 5 A/div,
Max load capacitance
Figure 5
— Input reflected ripple current at nominal line, full load.
See Fig 22 for setup.
Figure 6
— Turn on delay time;
V
IN
turn on delay at nominal line, 15% load
IBC MODULE
Page 5 of 14
Rev 1.6
11/2012
vicorpower.com
800 735.6200
