Polypropylene
Film Capacitors
F
EATURES
•
•
Negative temperature coefficient can be used in critical circuits
Excellent long-term stability and high reliability
TPPN
(Axial Tubular)
Series
MERITEK
S
PECIFICATIONS
1. Operating temperature:
2.
3.
4.
5.
6.
Capacitance range:
Capacitance tolerance:
Rated voltage:
Dissipation factor:
Insulation resistance:
-40
o
C to +85
o
C
0.001μF to 0.47μF
±5%(J), ±10%(K), ±20%(M)
100VDC, 250VDC, 400VDC, 630VDC
0.1% max. at 1KHz, 25
o
C
>50000MΩ
P
ART
N
UMBERING
S
YSTEM
Meritek Series
Capacitance
CODE
( pF )
( nF )
(
μF
)
102
1,000
1
0.001
103
10,000
10
0.01
104
100,000
100
0.1
105
1000
1
TPPN
TPPN
103
J
2A
are constructed with polypropylene film
dielectric, aluminum foil electrodes, tinned copper
leads, an outer wrapping of polyester film tape, and
epoxy resin end seals. They are ideal for coupling
and bypassing in precision timing and oscillation
circuits
.
Tolerance
CODE
Tolerance (%)
J
±5
K
± 10
M
± 20
MIN
35mm
MAX
L
MIN
35mm
MAX
OD
Rated Voltage
CODE
2A
100V
2E
250V
2G
400V
2J
630V
d
Tape & Reel / Tape & Ammo available for diameter 10mm or smaller
Please contact factory for part numbers
Dimensions in millimeters (mm)
250VDC
dØ
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
OD
5.0
5.0
5.0
5.0
6.0
6.0
7.0
7.0
8.0
10.0
10.0
11.0
12.0
14.0
16.0
15.0
19.0
L
14.0
14.0
14.0
14.0
14.0
14.0
14.0
16.0
16.0
16.0
21.0
21.0
27.0
27.0
27.0
32.0
32.0
dØ
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
OD
5.0
6.0
5.0
6.0
7.0
8.0
8.0
9.0
10.0
12.5
14.0
12.0
14.0
17.0
18.0
20.0
400VDC
L
14.0
14.0
14.0
14.0
14.0
14.0
16.0
16.0
16.0
21.0
21.0
27.0
27.0
27.0
32.0
32.0
dØ
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
OD
5.0
7.0
7.0
7.0
8.0
8.0
10.0
9.0
11.0
13.0
13.0
15.0
16.0
18.0
630VDC
L
14.0
14.0
14.0
14.0
14.0
16.0
16.0
21.0
21.0
21.0
27.0
27.0
32.0
32.0
dØ
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
Rated Voltage
DIM.
CAP(uF)
0.001
0.0015
0.0022
0.0033
0.0047
0.0068
0.01
0.015
0.022
0.033
0.047
0.068
0.10
0.15
0.22
0.33
0.47
OD
5.0
5.0
5.0
5.0
6.0
6.0
6.0
7.0
7.0
8.0
9.0
11.0
10.0
12.0
13.0
15.0
16.0
100VDC
L
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
14.0
16.0
16.0
21.0
21.0
27.0
27.0
32.0
Custom sizes and lead spacing available upon request
Custom values and tolerances available upon request
Specifications are
subject to change without notice.
rev.6a
