Surface Mount
Power Splitter/Combiner
2 Way-0° 50Ω
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-40°C to 85°C
-65°C to 150°C
1.5W max.
0.75W max.
BP2U1+
1750 to 3000 MHz
Features
• wide bandwidth 1750-3000 MHz
• good isolation, 20 dB typ.
• good output VSWR, 1.40:1 typ.
• excellent power handling, 1.5W
• low profile
• aqueous washable
CASE STYLE: XX211
PRICE: $0.99 ea. QTY (25)
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Pin Connections
SUM PORT
PORT 1
PORT 2
GROUND
2
8
5
1,3,4,6,7
Applications
• blue tooth
• IEEE 802.11b, g
Electrical Specifications
FREQ.
RANGE
(MHz)
ISOLATION
(dB)
Typ.
Min.
10
Outline Drawing
PCB Land Pattern
INSERTION LOSS (dB)
ABOVE 3.0 dB
Typ.
0.5
Max.
1.6
PHASE
UNBALANCE
(Degrees)
Max.
4.0
AMPLITUDE
UNBALANCE
(dB)
Max.
0.4
S-Port
Typ.
1.60
VSWR
(:1)
Output-Ports
Typ.
1.40
1750-3000
20
Typical Performance Data
Frequency
(MHz)
1750.00
1800.00
1900.00
2000.00
2100.00
2200.00
2300.00
2400.00
2500.00
2550.00
2600.00
2700.00
2800.00
2900.00
3000.00
Insertion Loss
(dB)
S-1
S-2
3.42
3.42
3.43
3.43
3.43
3.45
3.48
3.52
3.56
3.59
3.63
3.71
3.82
3.96
4.14
BP2U1+
INSERTION LOSS
Amplitude
Unbalance
(dB)
0.04
0.05
0.06
0.07
0.08
0.09
0.10
0.12
0.13
0.13
0.14
0.16
0.18
0.18
0.21
Isolation
(dB)
12.10
12.89
14.80
17.29
20.75
26.34
40.24
28.92
22.75
20.76
19.38
17.10
15.46
14.21
13.20
Phase
Unbalance
(deg.)
0.48
0.49
0.43
0.45
0.41
0.40
0.32
0.32
0.23
0.14
0.16
0.01
0.01
0.27
0.39
BP2U1+
ISOLATION
VSWR
S
1.27
1.24
1.18
1.12
1.06
1.02
1.08
1.15
1.23
1.27
1.33
1.43
1.56
1.72
1.91
VSWR
1
1.50
1.46
1.37
1.28
1.19
1.11
1.05
1.10
1.19
1.24
1.30
1.41
1.55
1.71
1.88
VSWR
2
1.52
1.48
1.39
1.30
1.22
1.13
1.07
1.09
1.17
1.22
1.28
1.39
1.52
1.67
1.83
Suggested Layout,
Tolerance to be within
±.002
Outline Dimensions (
inch
)
mm
A
.163
4.14
H
.009
0.23
B
.210
5.33
J
.025
0.64
C
.077
1.96
K
.030
0.76
D
.250
6.35
M
.050
1.27
E
.220
5.59
N
.030
0.76
F
.050
1.27
G
.017
0.43
4.4
INSERTION LOSS (dB)
4.2
4.0
3.8
3.6
3.4
3.39
3.38
3.37
3.36
3.35
3.36
3.37
3.40
3.43
3.46
3.48
3.55
3.65
3.78
3.93
ISOLATION (dB)
P
wt
.270 grams
6.86
0.10
50
40
30
20
10
1750
S-1
S-2
Demo Board MCL P/N: TB-37
Suggested PCB Layout (PL-053)
3.2
1750
2000
2250
2500
2750
3000
2000
2250
2500
2750
3000
FREQUENCY (MHz)
BP2U1+
VSWR
2.2
2.0
VSWR
1.8
1.6
1.4
1.2
1.0
1750
2000
2250
2500
2750
3000
FREQUENCY (MHz)
#S-VSWR
#1-VSWR
#2-VSWR
electrical schematic
FREQUENCY (MHz)
ESD Rating
Human Body Model (HBM): Class 1A (250 v to <500 v) in accordance with ANSI/ESD STM 5.1 - 2001
Machine Model (MM): Class M1 (< 100 v) in accordance with ANSI/ESD STM 5.2 - 1999 (pass 50V)
