CB503218 Overview

Barrier Strip Terminal Block, 10A, 1 Row(s), 1 Deck(s),

CB503218 Parametric

Parameter Name	Attribute value
Maker	Eaton
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	94V-0
Fastening method	SCREW
Installation type	BOARD
Number of layers	1
Rows	1
Number of channels	18
Rated current	10 A
Rated voltage	300 V
safety certificate	UL; CSA; CE
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK
Wire gauge	16 AWG

Preview

Download Datasheet

View All

INDEX

Series A5000 & Series CB5000

Single Row Terminal Blocks

SPECIFICATIONS

Rating:

10A, 300V*

Center Spacing:

.250” (6.35 mm)

Wire Size:

#16-30 AWG CU

Screw Size:

#3-48 zinc plated philslot SEMS screws, wire-

ready standard

Torque Rating:

4 in-lbs. max.

Distance Between Barriers:

.20” (5.08 mm)

Recommended PCB Hole Diameter:

.062” (1.57 mm)

Operating Temperature:

105°C (221°F) max., -40°C

(-40°F) min.

Molded Material:

Black, UL Rated 94VO Thermoplastic

Breakdown Voltage:

1600V rms

Approvals:

UL E62622; CSA LR15364; CE Certified

* Max. rating shown; some options may be rated lower – consult factory.

A50110507

CB50220807

A5000 Series

MOUNTING ENDS

Mount

Overall

Centers

Length

.75

1.00

1.25

1.50

1.75

2.00

2.25

2.50

2.75

3.00

3.25

3.50

3.75

4.00

4.25

4.50

4.75

5.00

5.25

5.50

5.75

6.00

6.25

6.50

6.75

7.00

7.25

1.06

1.31

1.56

1.81

2.06

2.31

2.56

2.81

3.06

3.31

3.56

3.81

4.06

4.31

4.56

4.81

5.06

5.31

5.56

5.81

6.06

6.31

6.56

6.81

7.06

7.31

7.56

BARRIER ENDS

Pole

Overall

Centers

Length

.25

.50

.75

1.00

1.25

1.50

1.75

2.00

2.25

2.50

2.75

3.00

3.25

3.50

3.75

4.00

4.25

4.50

4.75

5.00

5.25

5.50

5.75

6.00

6.25

6.50

6.75

7.00

7.25

.56

.81

1.06

1.31

1.56

1.81

2.06

2.31

2.56

2.81

3.06

3.31

3.56

3.81

4.06

4.31

4.56

4.81

5.06

5.31

5.56

5.81

6.06

6.31

6.56

6.81

7.06

7.31

7.56

.12

(3.0)

dia.

#3-48

scre w

.250

(6.35)

.43

(10.9)

Mount End

Barrier End

Poles

.50

(12.7)

.025

(.64)

Barrier End

.25

(6.35)

Mount End

CB5000 Series

#3-48

scre w

.12

(3.0)

dia.

.250

(6.35)

.50

(12.7)

* Dimensions in inches. To convert to millimeters, multiply by 25.4.

Mount End

Barrier End

.50

(12.7)

.025

(.64)

Mount End

Barrier End
