HPT SERIES - TRIPLE OUTPUT, 15 WATT
DESCRIPTION
HPT triple output DC/DC converters provide
15 Watts of output power in an industry standard
package. HPT’s feature excellent efficiency and
industry-leading power density. The HPT has open-
frame packaging to provide maximum useable power
with minimal thermal constraints. These units are
fully compatible with production board washing
processes.
TECHNICAL SPECIFICATIONS
Input
Voltage Range
24 VDC Nominal
48 VDC Nominal
48 VDC Wide
10 - 30 VDC
34 - 75 VDC
20 - 60 VDC
FEATURES
Triple Output 2” X 2”
Open-Frame Packaging
2.5 Million Hours MTBF
Short Circuit and
Overvoltage Protection
• 500V Isolation
•
•
•
•
• Input Undervoltage
Lockout
• 3-1 Wide Voltage
Input
• 100°C Baseplate
Operation
Output
Setpoint Accuracy
Auxiliary Setpoint Accuracy
Line Regulation V
in
Min. - V
in
Max., I
out
Rated
Load Regulation I
out
Min. - I
out
Max., V
in
Nom.
Minimum Output Current
Dynamic Regulation, Loadstep
Pk Deviation
Settling Time
Ripple and Noise w/ 25 MHz BW, Pk-Pk / RMS
Current Limit Type
Current Limit Threshold Range, % of I
out
Rated
Short Circuit Current Max.
OVP Trip Range
OVP Type
±1%
5%
±1% V
out
±1% V
out
10 % I
out
Rated
25% I
out
1% V
out
250
µs
1% / 0.3% V
out
Hiccup
110 - 140%
200% I
out
Nom.
110 - 140% V
out
Nom.
Second Control Loop
General
Switching Frequency
Isolation
Input - Output
Input - Case
Output - Case
Temperature Coefficient
Case Temperature
Operating Range
Storage Range
Thermal Shutdown Range
Humidity Max., Non-Condensing
Vibration, 3 Axes, 5 Min Each
MTBF
†
(Bellcore TR-NWT-000332)
Safety
Weight (approx.)
200 kHz
500 VDC
500 VDC
500 VDC
0.02 ppm/°C
-40 to +100°C
-40 to +125°C
105 to 115°C
95%
2g
6
2.5 x 10 hrs
Consult Factory
0.85 oz
Notes
1
For negative logic, add suffix “N” to model number.
MTBF predictions may vary slightly from model to model.
†
Specifications typically at 25°C, normal line, and full load, unless otherwise stated.
Soldering Conditions: I/O pins, 260°C, ten seconds; fully compatible with
commercial wave-soldering equipment.
Safety: Agency approvals may vary from model to model. Please consult factory
for specific model information.
Units are water-washable and fully compatible with commercial spray or immersion
post wave-solder washing equipment.
1
HPT SERIES - TRIPLE OUTPUT, 15 WATT
MODELS - (See the last page of this file for options.)
Vin
(Volts)
24
24
24
24
48
48
48
48
48 WIDE
48 WIDE
48 WIDE
48 WIDE
Vin Range
(Volts)
18 - 36
18 - 36
18 - 36
18 - 36
34 - 75
34 - 75
34 - 75
34 - 75
20 - 60
20 - 60
20 - 60
20 - 60
Iin Max.*
(Amps)
1.90
1.90
1.84
1.84
0.56
0.56
0.54
0.54
0.95
0.95
0.92
0.92
Vout
(Volts)
3.3, –12
3.3, –15
5, –12
5, –15
3.3, –12
3.3, –15
5, –12
5, –15
3.3, –12
3.3, –15
5, –12
5, –15
Iout Rated
(Amps)
2.3,
2.3,
1.5,
1.5,
2.3,
2.3,
1.5,
1.5,
2.3,
2.3,
1.5,
1.5,
–0.31
–0.25
–0.31
–0.25
–0.31
–0.25
–0.31
–0.25
–0.31
–0.25
–0.31
–0.25
Ripple & Noise
Pk-Pk (mV)
100,
100,
100,
100,
100,
100,
100,
100,
100,
100,
100,
100,
–200
–200
–200
–200
–200
–200
–200
–200
–200
–200
–200
–200
Efficiency
Typ. **
80%
80%
83%
83%
80%
80%
83%
83%
80%
80%
83%
83%
Model
HPT015YEHH-A
HPT015YEJJ-A
HPT015YGHH-A
HPT015YGJJ-A
HPT015ZEHH-AS1
HPT015ZEJJ-AS1
HPT015ZGHH-AS1
HPT015ZGJJ-AS1
HPT015ZEHH-A
HPT015ZEJJ-A
HPT015ZGHH-A
HPT015ZGJJ-A
Denotes advanced product release. Consult factory for product availability.
* Maximum input current at minimum input voltage, maximum rated output power.
** At nominal Vin, rated output.
MECHANICAL DRAWING
2.00"
(50.8mm)
0.18"
(4.6mm)
3
1.200"(30.5mm)
0.700"(17.8mm)
0.500"(12.7mm)
4
1
2
0.800"(20.3mm)
2.00"
(50.8mm)
DIA 0.040"
(1.0mm)
BOTTOM VIEW
5
0.400"(10.2mm)
6
0
-0.40"(-10.2mm)
0.025" REF.
1.800"(45.7mm)
0
-0.10"(-2.5mm)
(0.6mm)
0.40"
(10.2mm)
Thermal Impedance
Natural Convection
100 LFM
200 LFM
300 LFM
400 LFM
11.2
9.6
6.8
5.1
4.2
°C/W
°C/W
°C/W
°C/W
°C/W
Pin
1
2
3
4
5
6
Function
+V
in
-V
in
+V
out
+V
out
-V
out
-V
out
Tolerances
Inches:
.XX ± 0.020
.XXX ± 0.010
Pin:
± 0.002
(Millimeters)
.X ± 0.5
.XX ± 0.25
Note:
Thermal impedance data is dependent on
many environmental factors. The exact
thermal performance should be validated for
specific application.
± 0.05
(Dimensions as listed unless otherwise
specified.)
2
OPTIONS
When ordering equipment options, use the following suffix information. Select the option(s) that
you prefer and add them to the model number. Example ordering options are located below the
options table.
OPTION
Negative Logic
Lucent Compatible Trim
Terminal Strip
Trim
Enable
Trim and Enable
Current Share
Headerless
SUFFIX
N
T
TS
1
2
3
4
Y
APPLICABLE SERIES
HAS, HBD, HBS, HES, LES, QBS,
QES, TES, TQD
HAS, HBD, HBS, HES, QBS, QES
XWS, XWD, XWT
IAS, LES
IAD, IAS, LES, SMS
IAS, LES
SMS
Encapsulated EWS, IWS, OWS
REMARKS
TTL “Low” Turns Module ON
TTL “High” Turns Module OFF
PIN LENGTH AND HEATSINK
OPTIONS
0.110” (2.8mm) Pin Length
0.150” (3.8mm) Pin Length
0.24” (6.1mm) Horizontal Heatsink
0.24” (6.1mm) Vertical Heatsink
0.45” (11.4mm) Horizontal
Heatsink
0.45” (11.4mm) Vertical Heatsink
0.95” (24.1mm) Horizontal
Heatsink
0.95” (24.1mm) Vertical Heatsink
8
9
1H
1V
2H
2V
3H
3V
All Units (Except SMS)
All Units (Except SMS)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
Standard Pin Length is 0.180”
(4.6mm)
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Example Options:HBS050ZG-ANT3V = HBS050ZG-A with negative logic, Lucent compatible trim, and
0.95” vertical heatsink.
LES015YJ-3N = LES015YJ with optional trim and enable, negative logic.
QBS066ZG-AT8 = QBS066ZG-A with Lucent compatible trim and 0.110” pin length.
NUCLEAR AND MEDICAL APPLICATIONS
Power-One products are not authorized for use as critical components in life support systems,
equipment used in hazardous environments, or nuclear control systems without the express written consent of the President of Power-One, Inc.
TECHNICAL REVISIONS
The appearance of products, including safety agency certifications pictured on labels, may change depending on the
date manufactured. Specifications are subject to change without notice.
