536490-5 Product Details
Live Product Chat
Product View
Eurocard Type C
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
536490-5
T E I nternal N umber: 5 3 6 4 9 0 - 5
Product Highlights:
l
Type C C onnectors
l
Receptacle
l
Number of Positions = 120
l
Rows Loaded = A, B, C
l
Terminate To Printed C ircuit Board
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Type C C onnectors
l
Gender
= Receptacle
l
Number of Positions
= 120
l
PC B Retention Feature
= Yes
l
PC B Mount Angle
= Vertical
l
Post Type
= Solder Post
l
Size
= Expanded
l
Make First / Break Last
= No
l
DIN Level
= II
l
Mounting Ears
= With
l
Toolless (Flat Rock) = No
Termination Related Features:
l
Termination Post Length (mm [in])
= 4.57 [0.180]
Body Related Features:
l
Rows Loaded
= A, B, C
l
PC B Retention Method
= Boardlock(s)
l
C ontact C ross Section (mm [in])
= 0.30 x 0.61 [.012 x .024]
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Polyester
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
l
Flux-Tight C oating
= Without
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
l
High Temperature Housing
= No
Other:
l
Brand = AMP
