Miniature Metallized Polyester
Film Capacitors
F
EATURES
•
•
•
•
•
Space saving miniature size
Non-inductive construction
Self-healing properties
Good solderability
Available on tape and reel for automatic insertion
MPEM
Series
(Radial Dipped)
MERITEK
S
PECIFICATIONS
1. Operating temperature:
2.
3.
4.
5.
6.
Capacitance range:
Capacitance tolerance:
Rated voltage:
Dissipation factor:
Insulation resistance:
-40
o
C to +85
o
C
0.01μF to 1.0μF
±5%(J), ±10%(K), ±20%(M)
50VDC, 63VDC, 100VDC, 250VDC
1.0% max. at 1KHz, 25
o
C
>10000MΩ (C
≤
0.33
μF)
> 3300MΩ
• μF
(C > 0.33
μF)
MPEM
are constructed with a special metallized
1J
TR
polyester film dielectric, tinned copper leads, and
an epoxy resin coating. They are suitable for
-5
blocking, circuit isolation, bypassing, filtering, and
signal coupling and decoupling. MPEM are ideal for
use in telecommunication equipment, data
processing equipment, industrial instruments, and
automatic control systems.
MPEM
Meritek Series
Capacitance
CODE
( pF )
( nF )
(
μF
)
103
10,000
10
0.01
J
±5
1J
63V
Blank
Bulk
-5
5 mm
104
100,000
100
0.1
K
± 10
2A
100V
105
1000
1
M
± 20
2E
250V
TA
Tape & Ammo
154
K
Tolerance
CODE
Tolerance (%)
Rated Voltage
CODE
1H
50V
Packaging
CODE
TR
Tape & Reel
-7.5
7.5 mm
Lead spacing (optional)
CODE
Dimensions in millimeters (mm)
50VDC/63VDC
100VDC
P
W
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
H
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
8.0
8.5
T
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
4.0
4.0
P
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
W
H
250VDC
T
P
RV
DIM.
CAP(
μ
F)
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
W
H
T
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
8.0
8.5
8.5
9.0
9.5
9.5
9.5
9.5
9.5
10.0
10.5
3.5
3.5
3.5
3.5
3.5
3.5
4.0
4.5
4.5
5.0
5.5
5.5
6.0
6.0
6.0
6.0
6.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
10.0
10.0
10.0
10.0
10.0
10.0
8.5
8.5
8.5
8.5
8.5
8.5
4.0
4.0
4.0
4.0
4.0
4.0
7.5
7.5
7.5
7.5
7.5
7.5
Specifications are
subject to change without notice.
rev.6a
