MTCH6301
MTCH6301 Projected Capacitive Touch Controller
Summary
The MTCH6301 is a turnkey projected capacitive touch
controller that allows easy integration of multitouch and
gestures to create a rich user interface in your design.
Through a sophisticated combination of Self and
Mutual Capacitive scanning for both XY screens or
touch pads, the MTCH6301 allows designers to quickly
and easily integrate projected capacitive touch into
their application.
A new Projected Capacitive Configuration Utility with
an autotune feature allows fast customization for
different sizes and top layer thicknesses.
For further customization, designers can also get
access to the firmware library to optimize and improve
designs as needed.
Power Management
• Configurable Sleep mode
• Integrated Power-on Reset and Brown-out Reset
• 20 µA sleep current (typical)
Communication Interface
• I
2
C™ module (up to 400 kbps)
Operating Conditions
• 2.4V to 3.6V, -40ºC to +105ºC
Package Types
• 44-Lead TQFP
• 44-Lead QFN
Touch Features
•
•
•
•
•
Multitouch (up to 10 touches)
Gesture detection and reporting
Single and dual touch drawing
Self/Mutual signal acquisition
Built-in noise detection and filtering
Applications
• Human-machine interfaces with configurable
button, keypad or scrolling functions
• Single finger gesture interfaces to swipe, scroll, or
doubletap controls
• Home automation control panels
• Security control keypads
• Automotive center stack controls
• Gaming devices
• Remote control touch pads
Touch Performance
• >100 reports per second single touch
• >60 reports per second dual touch
• Up to 12-bit resolution coordinate reporting
Touch Sensor Support
• Up to 13RX x 18TX channels
• Individual channel tuning
• Works with Printed Circuit Board (PCB) sensors,
film and glass-based sensors, and Flexible
Printed Circuits (FPC)
• Cover layer support:
- Plastic: up to 3 mm
- Glass: up to 5 mm
2012 Microchip Technology Inc.
DS41666A-page 1
