RoHS
10/100 Base T Quad Port LAN Filter Module
AHSC-4001S
Ethernet based LAN, WAN and other networking applications
Polarity: 1-40, 4-37, 6-35, 9-32, 11-30, 14-27, 16-25, 19-22, In-Phase
Cw/w 50PF Typ @100KHz, 0.2V
LL: 0.5µH Max @ 100KHz, 0.2V
DCR: 0.9
Ω
Max
Operating Temp: 0ºC to 70ºC
Electrical Specifications @ 25°C
Part
Number
AHSC-4001S
OCL(uH Min)
@ 100kHz, 200mV
With 8mA DC Bias
350
Turns Ratio
chip: cable
(±5%)
1CT:1CT
Insertion Loss
(dB Max)
0.3-100MHz
-1.1
0.3-30MHz
-18
Return Loss
(dB Min)
50MHz
40MHz
-14.4
-13.1
60-80MHz
-12
Electrical Specifications @ 25°C
Part
Number
AHSC-4001S
0.3-30MHz
-40
Common Mode Rejection
(dB Min)
60MHz
-35
Cross Talk
(dB Min)
80-100MHz
-30
0.3-60MHz
-42
60-100MHz
-33
Isolation
HI-POT
(Vrms)
1500
All specifications subject to change without notice.
MECHANICAL
1.106(28.10)
1.106(28.10)
0.092(2.34)
0.092(2.34)
0.472
0.476
0.472
0.476
(12.00)
(12.10)
(12.00)
(12.10)
ALLIED
AHSC-4001S
DATECODE
0.630
0.630
(16.00)
(16.00)
0.660(16.76)
0.660(16.76)
0.050
0.050
(1.27)
(1.27)
0.018
0.018
(0.46)
(0.46)
0.050
0.050
(1.27)
(1.27)
0.030
0.030
(0.76)
(0.76)
0.010
0.012
0.010
0.012
(0.25)
(0.30)
(0.25)
(0.30)
0.950(24.13)
0.950(24.13)
0.244
0.244
(6.20)max
(6.20)max
0.051(1.30)
0°-8°
0.051(1.30)
0°-8°
Dimensions:inch( mm)
Dimensions:inch( mm)
Unless otherwise specified, all tolerances are ±0.010(0.25)
Unless otherwise specified, all tolerances are ±0.010(0.25)
SCHEMATICS
TX1
40
39
38
RX1
37
36
35
RX2
34
33
32
TX2
31
30
TX3
29
28
27
RX3
26
25
RX4
24
23
22
TX4
21
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
16
17
18
19
10
11
12
13
14
TD1
RD1
RD2
TD2
TD3
RD3
15
RD4
TD4
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 11/19/12
15
www.alliedcomponents.com
20
1
2
3
4
5
6
7
8
9
