DC60A60 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> DC60A60

DC60A60: DescriptionTRANSISTOR OUTPUT SOLID STATE RELAY, 2500 V ISOLATION-MAX; CategoryLED optoelectronic/LED; File Size1006KB，6 Pages; ManufacturerCrydom; Websitehttp://www.crydom.com/en/index.shtml

Download Datasheet Parametric Compare View All

DC60A60 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	DC60A60	-	-	View	Buy Now

DC60A60 Overview

TRANSISTOR OUTPUT SOLID STATE RELAY, 2500 V ISOLATION-MAX

DC60A60 Parametric

Parameter Name	Attribute value
Maximum operating temperature	65 Cel
Minimum operating temperature	-20 Cel
Number of functions	1
Processing package description	ROHS COMPLIANT, PLASTIC PACKAGE-4
state	ACTIVE
Optoelectronic device type	transistor output
Maximum input control current	13 mA
Maximum insulation voltage	2500 V
On-state resistance	0.0104 ohm
Maximum output current	60000 A

Preview

Download Datasheet

View All

PowerPlus DC

• Optically Isolated MOSFET output

• Ratings from 10A to 100A @ 48 VDC

• AC or DC control

• Relays are easily paralleled for higher-current applications

• LED Status Indicator

• Optional IP20 Cover

• UL Recognized, CE and RoHS Compliant

• PWM to 1K Hz

PRODUCT SELECTION

Control Voltage

4-32 VDC

90-140 VAC

10A

DC60D10

DC60A10

20A

DC60D20

DC60A20

40A

DC60D40

DC60A40

60A

DC60D60

DC60A60

80A

DC60D80

100A

DC60D100

AVAILABLE OPTIONS

OUTPUT SPECIFICATIONS (1)

Description

Operating Voltage [Vdc] (2)

Blocking Voltage

Rated Load Current [Adc] (3)

Minimum Load Current [mA] (4)

Maximum Surge Current [Adc] (10ms)

Maximum On-State Voltage Drop @ Rated Current [Vdc]

Maximum Off-State Leakage Current @ Rated Voltage [mA]

Thermal Resistance Junction to Case (Rjc) [°C/W]

Maximum On-State Resistance @ Rated Current [RDS-ON][mOhms]

Maximum PWM [Hz] (5)

10A

1-48 VDC

2.5

0.33

0.1

2.1

33.4

20A

1-48 VDC

2.5

108

0.35

0.1

1.2

17.6

40A

1-48 VDC

2.5

163

0.62

0.1

1.1

15.6

900

60A

1-48 VDC

2.5

200

0.62

0.1

0.8

10.4

900

80A

7-48 VDC

2.5

258

0.75

0.1

0.7

9.4

700

100A

7-48 VDC

100

2.5

326

0.59

0.1

0.53

5.9

700

DC60A60 Related Products

	DC60A60	DC100A40CH	DC60D100
Description	TRANSISTOR OUTPUT SOLID STATE RELAY, 2500 V ISOLATION-MAX	TRANSISTOR OUTPUT SOLID STATE RELAY, 2500 V ISOLATION-MAX	TRANSISTOR OUTPUT SOLID STATE RELAY, 2500 V ISOLATION-MAX
Maximum operating temperature	65 Cel	65 Cel	65 Cel
Minimum operating temperature	-20 Cel	-20 Cel	-20 Cel
Number of functions	1	1	1
Processing package description	ROHS COMPLIANT, PLASTIC PACKAGE-4	ROHS COMPLIANT, PLASTIC PACKAGE-4	ROHS COMPLIANT, PLASTIC PACKAGE-4
state	ACTIVE	ACTIVE	ACTIVE
Optoelectronic device type	transistor output	transistor output	transistor output
Maximum input control current	13 mA	13 mA	13 mA
Maximum insulation voltage	2500 V	2500 V	2500 V
On-state resistance	0.0104 ohm	0.0156 ohm	0.0156 ohm
Maximum output current	60000 A	40000 A	40000 A
