SM220
RECTIFIER SPECIALISTS
THRU
SM260
TECHNICAL SPECIFICATIONS OF SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
VOLTAGE RANGE - 20 to 60 Volts
CURRENT - 2.0 Amperes
FEATURES
* High current capability
* Ideal for surface mounted applications
* Low leakage current for high efficiency
SM-1(DO-213AB)
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
*Terminals: Solder plated solderable per
MIL-STD-202E, Method 208 guaranteed
* Polarity: Color band denotes cathode end
* Mounting position: Any
* Weight: 0.12 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
SYMBOL
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
at T
A
=90
o
C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum Instantaneous Forward Voltage at 2.0A DC
Maximum DC Reverse Current at
Rated DC Blocking Voltage
Typical Thermal Resistance (Note1)
Typical Junction Capacitance (Note 2)
Storage Operating Temperature Range
@T
A
= 25
o
C
@T
A
= 100
o
C
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
I
R
R
θ
JA
C
J
T
J
, T
STG
SM220
20
14
20
SM230
30
21
30
SM240
40
28
40
2.0
40
SM250
50
35
50
SM260
60
42
60
UNITS
Volts
Volts
Volts
Amps
Amps
.45
.55
.60
2.0
20
40
200
-65 to + 125
.75
mAmps
0
C/ W
pF
0
C
NOTES : 1. Thermal Resistance (Junction to Ambient), .24in
2
(6.0mm
2
) copper pads to each terminal.
2. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
PRO-AN Electronic Co., Ltd.
Email:info@proan.com.hk
Http://www.proan.com.hk
