ACA0862 - B, D
1 GHz CATV Line Amplifier MMIC
fEATURES
•
•
•
•
•
•
•
•
•
•
•
Flat Gain
Very Low Distortion
Excellent Input/Output Match
Low DC Power Consumption
Good RF Stability with High VSWR Load
Conditions
Surface Mount Package Compatible with
Automatic Assembly
Low Cost
Repeatability of Monolithic Fabrication
Meets Cenelec Standard
RoHS-Compliant Packaging
DATA SHEET - Rev 2.1
1 GHz Specified Performance
S7 Package
16 Pin Wide Body SOIC
with Heat Slug
PRODUCT DESCRIPTION
The ACA0862 family of surface mount monolithic
GaAs RF Linear Amplifiers has been developed to
replace, in new designs, the standard CATV Hybrid
amplifiers currently in use. The ACA0862 can also
replace the ACA0861 with the addition of tuning
capacitors to the output (see Figure 3). The MMICs
consist of two parallel amplifiers, each with 12 dB gain.
The Amplifiers are optimized for exceptionally low
distortion and noise figure while providing flat gain and
excellent input and output return loss. The ACA0862B
and ACA0862D are optimized for different output
powers, and can be used separately or cascaded to
support a variety of applications. A Hybrid equivalent
is formed when two ACA0862 devices are cascaded
between transmission line baluns. For low gain
applications a single ACA0862 can be used; for higher
gain applications more than two can be cascaded. See
the ACA0861 application note for more information.
RF Input
15dB
12dB
15dB
ACA1206
12dB
ACA0862B/D
RF Output
figure 1: Hybrid Application Diagram
10/2012
ACA0862 - B, D
Output Stages
The ACA0862B and ACA0862D are designed as output
stage amplifiers. These parts can be used alone for
low gain, high output level applications or can be
cascaded with an ACA1206 input stage amplifier for
higher gain. The ACA0862B is a low power dissipation
part, while the ACA0862D is a higher power dissipation
part. Cascaded, an ACA1206 and ACA0862B provide
exceptional push-pull hybrid equivalent performance;
an ACA1206 and an ACA0862D cascade provides
exceptional power doubling hybrid equivalent
performance. An ACA0862B can also be cascaded
with an ACA0862D to create a power doubler with
even better distortion performance.
1
2
3
4
5
6
7
8
GND
N/C
RF
INA
GND
GND
RF
INB
I
ADJ
GND
figure 2: Pin Out
GND
V
A
RF
OUTA
GND
GND
RF
OUTB
V
B
GND
16
15
14
13
12
11
10
9
Table 1: Pin Description
P
I
N
1
2
3
4
5
6
7
8
2
N AME
GND
N/C
RF
INA
GND
GND
RF
INB
I
ADJ
GND
D ESCRIPTION
Groun d
No C onnectio n
Input to Amplifier A
Groun d
Groun d
Input to Amplifier B
Current Adjust
Groun d
PIN
9
10
11
12
13
14
15
16
DATA SHEET - Rev 2.1
10/2012
NAME
GND
V
B
RF
OUTB
GND
GND
RF
OUTA
V
A
GND
D ESCR IPTION
Groun d
Supply for Amplifi er B
Output from Amplifier B
Groun d
Groun d
Output from Amplifier A
Supply for Amplifi er A
Groun d
ACA0862 - B, D
ELECTRICAL CHARACTERISTICS
Table 2: Absolute Minimum and Maximum Ratings
PARAMETER
Amplifier Supplies (pi ns 10, 11, 14, 15)
RF Input Power (pi ns 3, 6)
Storage Temperature
Soldering Temperature
Soldering Time
M
I
N
0
-
-6 5
-
-
MAX
+15
+70
+15 0
+260
5.0
UN IT
VDC
dBmV
°C
°C
se c
Stresses in excess of the absolute ratings may cause permanent damage.
functional operation is not implied under these conditions. Exposure to
absolute ratings for extended periods of time may adversely affect reliability.
Notes:
(1) Pins 3 and 6 should be AC-coupled. No external DC bias should be
applied.
(2) Pin 7 must be terminated through a resistor to either Vd or GND.
P/N
Resistor (Pin7)
Termination
ACA0862B
4.32K(R1)
GND
ACA0862D
9.09K(R2)
VD
Refer to figure 17 (Test Circuit) and Table 6, page 8.
Table 3: Operating Ranges
PARAMETER
RF Frequency
Supply: V
D
(pi ns 10, 11, 14, 15)
Operating Temperature: T
A
MIN
40
-
-40
TYP
-
+12
-
MAX
1000
-
+110
UNIT
MHz
VD C
°C
The device may be operated safely over these conditions; however, parametric
performance is guaranteed only over the conditions defined in the electrical
specifications.
3
DATA SHEET - Rev 2.1
10/2012
ACA0862 - B, D
Table 4: Electrical Specifications
(T
A
= +25 °C, V
D
= +12 VDC)
ACA0862B
PARAMETER
MIN
Gain
(1)
Gain Flatness
(1)
Noise Fi gure
(1)
AC A0862D
UNIT
COMMENTS
MIN
10 . 8
-
-
-
-
-
-
-
-
-
-
-
-
-0.5
18
-
TYP
-
-
4
-
-
-
-
-
-
-
-
-
530
-
22
-
MAX
11.8
±0.3
4. 5
-78
-73
-
-68
-56
-
-72
-71
-
61 0
1.0
-
6.0
O
TYP
-
-
4
-
-
-
-
-
-
-
-
-
39 5
-
22
-
MAX
11.7
±0.3
4.5
-70
-71
-
-68
-66
-
-65
-68
-
44 5
1.0
-
6.0
10.7
-
-
-
-
-
-
-
-
-
-
-
-
(1)
dB
dB
dB
CTB
(1), (2)
77 C hannels
110 Channels
128 Channels
CSO
(1), (2)
77 C hannels
110 Channels
128 Channels
XMOD
(1), (2)
77 C hannels
110 Channels
128 Channels
Supply C urrent
(3)
Cable Equivalent Slope
dB c
dB c
dB c
mA
dB
dB
C/W
-0.5
18
Return Loss (Input/Output)
(1)
Thermal Resi stance (θ
JC
)
-
Notes:
(1) Measured with a balun on input and output of the device. See Figure 3 for test setup.
(2) “B” device measured with 79 analog channels, +47 dBmV output power at 1002 MHz with a 3 dB tilt and QAM to
1002 MHz. “D” device measured with 79 analog channels, +56 dBmV output power at 1002 MHz with a 15.6 dB tilt
and QAM to 1002 MHz. QAM channels are -6 dB relative to analog channels.
(3) A fixed resistor is needed (see Table 6) to set the devices’ current draw. Bias voltage is +12 VDC.
4
DATA SHEET - Rev 2.1
10/2012
ACA0862 - B, D
figure 3: ACA0862B P1dB vs frequency
81
figure 4: ACA0862D P1dB vs frequency
81
80
P1db (dBmV)
80
P1db (dBmV)
79
79
78
78
77
0
200
400
600
Frequency (MHz)
800
1000
77
0
200
400
600
800
1000
Frequency (MHz)
figure 5: ACA0862B MER - 64 QAM @ 85 MHz
55
50
45
40
MER (dB)
figure 6: ACA0862D MER - 64 QAM @ 85 MHz
55
50
45
40
MER (dB)
35
30
25
CHANNEL UNDER TEST = 85MHz
CHANNEL UNDER TEST = 85MHz
35
30
25
20
15
56
58
60
62
64
66
68
70
72
74
76
78
80
Pout (dBmV)
MER - 64QAM
4 CH.
3 CH.
2 CH.
1 CH.
MER - 64QAM
4 CH.
3 CH.
2 CH.
1 CH.
20
15
56
58
60
62
64
66
68
70
72
74
76
78
80
Pout (dBmV)
figure 7: ACA0862B MER - 64 QAM @ 543 MHz
55
50
45
40
MER (dB)
35
30
25
figure 8: ACA0862D MER - 64 QAM @ 543 MHz
55
50
45
40
MER (dB)
35
30
CHANNEL UNDER TEST = 543MHz
CHANNEL UNDER TEST = 543MHz
MER - 64QAM
4 CH.
3 CH.
2 CH.
1 CH.
MER - 64QAM
4 CH.
3 CH.
2 CH.
1 CH.
25
20
15
20
15
56
58
60
62
64
66
68
70
72
74
76
78
80
Pout (dBmV)
56
58
60
62
64
66
68
70
72
74
76
78
80
Pout (dBmV)
5
DATA SHEET - Rev 2.1
10/2012
