W23-X1A3G-50 Product Details
Live Product Chat
Product Photo
Thermal Circuit Breakers
C onve rte d to EU R oHS but not ELV C om plia nt
(
Find R oHS C om plia nt
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
W23-X1A3G-50
(8-1393246-0)
T E I nternal N umber: 8 - 1 3 9 3 2 4 6 - 0
Product Highlights:
l
W23 Series
l
Number of Poles = 1
l
Actuator Style = Push/Pull
l
C urrent Rating = 50 Amps.
l
Button C olor = Black with White Amp Rate Marking and
White Trip Band
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Obsolete
C ontact Product Information C enter
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Actuator Style
= Push/Pull
l
Button C olor
= Black with White Amp Rate Marking and White Trip
Band
l
Termination Type
= 8-32 Screws 90? to Each Other (Screws and
Washers Installed)
Electrical Characteristics:
l
C urrent Rating (Amps.)
= 50
l
Operating Voltage, Max.
= 50 VDC , 250 VAC
Body Related Features:
l
Series
= W23
Contact Related Features:
l
Number of Poles
= 1
l
Trip Time at 200%
= 6 to 22 Seconds
l
Interrupt C apacity
= 1,000 A @ 50 VDC or 250 VAC
l
Mounting Options
= Knurled Nut/Hex Nut
l
Mounting Bushing
= 3/8"-24 Threaded Bushing .375" [9.53 mm]
Long, Silver C olor
l
Approved Standards = UL Recognized, C SA C ertified
Configuration Related Features:
l
C ircuit Function
= Series Trip
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS/Not ELV C ompliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS not
ELV directives
Other:
l
Brand = Potter & Brumfield
