HV37-20F
20kV 200mA HIGH VOLTAGE DIODE
Outline Drawings :
mm
HV37
is high reliability resin molded type high voltage
diode in small size package which is sealed a multilayed
mesa type silicon chip by epoxy resin.
Lot No.
Cathode Mark
o 4.2
o 0.8
Features
High speed switching
Low VF
High surge resisitivity for CRT discharge
High reliability design
Ultra small pakage
25 min.
15
25 min.
Applications
X light Power supply
Laser
Voltage doubler circuit
Microwave emission power
Cathode Mark
Type
Mark
HV
HV37-20F
37-20F
Maximum Ratings and Characteristics
Absolute Maximum Ratings
Items
Repetitive Peak Renerse Voltage
Average Output Current
Suege Current
Junction Temperature
Allowable Operation Case Temperature
Storage Temperature
Symbols
V
RRM
I
O
I
FSM
T
j
Tc
T
stg
Condition
HV37-20F
20
Units
kV
mA
A
peak
°C
°C
°C
Ta=25°C,Resistive Load
200
15
155
125
-40 to +155
Electrical Characteristics (Ta=25°C Unless otherwise specified )
Items
Maximum Forward Voltage Drop
Maximum Reverse Current
Symbols
V
F
IR
1
IR
2
Maximum Reverse Recovery Time
Junction Capacitance
Trr
Cj
Conditions
at 25°C,I
F
=I
F(AV)
at 25°C,V
R
=V
RRM
at 100°C,V
R
=V
RRM
at 25°C
at 25°C,V
R
=0V,f=1MHz
HV37-20F
35
5.0
50
80
15
Units
V
µA
µA
nS
pF
GETE ELECTRONICS CO.,LTD
Http://www.getedz.com
E-mail:sales@getedz.com
