LP07 Series
SMT High Current Inductors
Features
•
•
•
•
Low cost design
Saturation current rating up to 85A
Low DCR
Suitable for pick and place applica-
tions
Applications
• AC/DC and DC/DC Converters
• Servers/Workstations
• Telecom Switches
• Voltage Regulator Modules
Packaging
Reel Diameter: 13”, Reel Width: 24mm, Pieces/reel: 350
Mechanical
A
6.5 max
2.5
4.6
13.0 max
6.5
A= LP07-181:
15.3mm max
LP07-451 ~ 801: 15.0mm max
LP07-142 ~ 392: 14.5mm max
Recommended PCb layout
S
Schematic
LP07-XXX
YYWW
F
unit: mm
Electrical Specifications
Part
Number
LP07-181
LP07-451
LP07-801
LP07-142
LP07-202
LP07-282
LP07-392
Inductance
1
DCR
DCR
(µH,nom.)
(m , typ) (m ,max)
0.18
0.45
0.80
1.40
2.00
2.80
3.90
0.32
0.69
1.20
1.90
2.60
3.90
4.50
0.45
0.90
1.40
2.20
3.00
4.30
5.25
Isat
5
(A)
85
53
36
28
24
20
16
Idc
6
(A)
45
40
31
26
21
17
16
1. Tested at 100kHz, 0.1Vrms.
2. Electrical specifications at 25°C.
3. Operating range: -40°C to +130°C. This is a combina-
tion of ambient plus temperature rise.
4. Meets UL 94V-0.
5. Isat is the DC current required to reduce to nominal
inductance by 20% at an ambient temperature of 25°C.
6. Idc is the DC current required to produce a temperature
rise of 40°C at an ambient temperature of 25°C.
7. Inductance tolerance is +/-20%.
8. For Lead Free components, please add “-LF” as suffix.
Specifications subject to change without notice.
800.729.2099 tel
www.icecomponents.com
14
(02/08) LP07-1
