MMSZ5226B - MMSZ5257B — Zeners
February 2012
MMSZ5226B - MMSZ5257B
Zeners
Tolerance = 5%
SOD-123
Absolute Maximum Ratings *
Symbol
P
D
R
θJA
T
STG
T
A
= 25°C unless otherwise noted
Parameter
Power Dissipation @25°C
Thermal Resistance, Juncion to Ambient **
Storage Temperature Range
Value
500
340
-55 to +150
Units
mW
°C/W
°C
°C
T
J
Operating Junction Temperture
+150
* These ratings are limiting values above which the serviceability of the diode may be impaired.
** FR-4 or FR-5 = 3.5
×
1.5 inches using minimumrecommended land pads.
Electrical Characteristics
Device
MMSZ5226B
MMSZ5227B
MMSZ5228B
MMSZ5229B
MMSZ5230B
MMSZ5231B
MMSZ5232B
MMSZ5233B
MMSZ5234B
MMSZ5235B
MMSZ5236B
MMSZ5237B
MMSZ5238B
MMSZ5239B
MMSZ5240B
MMSZ5241B
MMSZ5242B
MMSZ5243B
MMSZ5244B
MMSZ5245B
MMSZ5246B
MMSZ5247B
Mark
D1
D2
D3
D4
D5
E1
E2
E3
E4
E5
F1
F2
F3
F4
F5
H1
H2
H3
H4
H5
J1
J2
Min.
3.135
3.42
3.705
4.085
4.465
4.845
5.32
5.7
5.89
6.46
7.125
7.79
8.265
8.645
9.5
10.45
11.4
12.35
13.3
14.25
15.2
16.15
T
A
= 25°C unless otherwise noted
V
Z
(V)
Typ.
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6
6.2
6.8
7.5
8.2
8.7
9.1
10
11
12
13
14
15
16
17
Max.
3.465
3.78
4.095
4.515
4.935
5.355
5.88
6.3
6.51
7.14
7.875
8.61
9.135
9.555
10.5
11.55
12.6
13.65
14.7
15.75
16.8
17.85
Z
Z
(Ω) @ I
ZK
(mA)
28
24
23
22
19
17
11
7.0
7.0
5.0
6.0
8.0
8.0
10
17
22
30
13
15
16
17
19
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
9.5
9.0
8.5
7.8
7.4
Z
ZK
(Ω) @ I
ZK
(mA)
1,600
1,700
1,900
2,000
1,900
1,600
1,600
1,600
1,000
750
500
500
600
600
600
600
600
600
600
600
600
600
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
I
R
(μA) @ V
R
(V)
25
15
10
5.0
5.0
5.0
5.0
5.0
5.0
3.0
3.0
3.0
3.0
3.0
3.0
2.0
1.0
0.5
0.1
0.1
0.1
0.1
1.0
1.0
1.0
1.0
2.0
2.0
3.0
3.5
4.0
5.0
6.0
6.5
6.5
7.0
8.0
8.4
9.1
9.9
10
11
12
13
V
F
Foward Voltage = 0.9V Maximum @ I
F
= 10mA for all MMSZ5200 series
© 2012 Fairchild Semiconductor Corporation
MMSZ5226B - MMSZ5257B Rev. E2
1
www.fairchildsemi.com
