ACTIVE (DIGITAL) DELAY LINES
SINGLE, DUAL, TRIPLE, QUAD DELAYS
RESISTORS CAPACITORS COILS DELAY LINES
A0 SERIES
RoHS
Term.W
is Pb-free
and RoHS
compliant
RCD
A03AG
1 50NS
1
RCD
A04AG
100NS
Economical cost, prompt delivery!
Wide range of values, 5nS to 500nS
TTL schottky interfaced
Low cost solution for multiple timing delays in a single package!
RCD’s digital delay lines have been designed to provide precise fixed delays with all
the necessary drive and pick-off circuitry. All inputs and outputs are schottky-type and
require no additional components to achieve specified delays. Designed to meet
the applicable environmental requirements of MIL-D-23859. Type A01 features a
single fixed delay, type A02 features two isolated delays, A03 features three delays,
and A04 features 4 delays (single delay SIP available). Application Guide available.
OPTIONS
Opt.T= trailing edge design
Opt. F =fast TTL, H =HCMOS, C =FACT
Opt.A = auto-insertable design
Opt.39 = -40 to +85°C operating temp.
Tighter tolerances, faster rise times
Low power design
Military screening
PACKAGE STYLES
.500 [12.7]
Max
.015 [.4]
SIDE VIEW
SIDE
.40 [10.2]Max
.500 [12.7]
Max
8
5
↑
.
295 [7.5]
Max.
.285 [7.24]
TOP VIEW
.300±.01
[7.6±.25]
1
4
STANDARD DELAY TIMES
5nS, 10nS, 15nS, 20nS. 25nS, 50nS,
75nS, 100nS, 250nS, 500nS
Intermediate values available on special order.
↓
↑
→
.300 ±.01
[7.62±.25]
.120 [3] Min
←.
100 [2.54]
↓
.250
[6.35]
←
←
.300 [7.6]
→
←
.420 [10.67]
→
.020 [.5] .10 [2.54]
→ ←
→
PACKAGE STYLE 8P (8-Pin DIP)
PACKAGE STYLE 8SM (8-Pin SM DIP)
←
14
SPECIFICATIONS
Operating Temp: 0 to 70°C
Delay Tol: ±2nS or ±5%, whichever greater
Rise Time: 4nS
Peak Soldering Temp: +230°C
↓
↑
←
.800 [20.3] Max.
→
SIDE VIEW
↑
.
295 [7.5]
Max.
.120 [3] Min
←.
100 [2.54]
.40
[10.2]Max
.800 [20.3] Max
→
8
.285 [7.24]
TOP VIEW
1
7
↓
.300
[7.6]
→
←
←
.300 [7.6]
→
←
.420 [10.67]
→
.015 [.4]
←
.600 ± .010
→
[15.2 ± .25]
→
.300±.01
[7.6±.25]
.020 [.5]
→ ←
.10 [2.54]
CHARACTERISTICS
RCD
Type
A 01
A 01S
A 01A G
A 02A
A 02S A
A 02A G
A 03
A 03S
A 03A G
A 03S A G
A 04
A 04A G
Independent
Delays
Single
Single
Single
Dual
Dual
Dual
Triple
Triple
Triple
Triple
Quadruple
Quadruple
P a cka g e
Style
14P
8P
14S M
8S M
14P
8P
14S M
8S M
14P
8P
14S M
8S M
14P
14S M
Circuit
A
B
A
B
C
D
C
D
E
F
E
F
G
G
PACKAGE STYLE 14P (14-Pin DIP)
PACKAGE STYLE 14SM (14-Pin SM DIP)
CIRCUIT SCHEMATICS
Circuit A
14
(VCC)
Circuit B
8
(OUT)
8
(VCC)
5
(OUT)
Circuit C
14
(VCC)
12
(OUT)
8
(OUT)
Circuit D
8
(VCC)
7
(OUT)
5
(OUT)
A01SAG Single
DELAY
DELAY
DELAY
DELAY
DELAY DELAY
1
(IN)
7
(GND)
1
(IN)
4
(GND)
1
(IN)
5
(IN)
7
(GND)
1
(IN)
3
(IN)
4
(GND)
A02SAG Dual
Circuit E
14
(VCC)
12
(OUT)
10
(OUT)
8
(OUT)
Circuit F
8
(VCC)
7
(OUT)
6
(OUT)
5
(OUT)
14
(Vcc)
Circuit G
12
(OUT)
10
(OUT)
9
(OUT)
8
(OUT)
DELAY
DELAY
DELAY
DELAY DELAY DELAY
DELAY
DELAY DELAY DELAY
1
(IN)
3
(IN)
5
(IN)
7
(GND)
1
(IN)
2
(IN)
3
(IN)
4
(GND)
1
(IN)
3
(IN)
4
(IN)
5
(IN)
7
(GND)
TEST CONDITIONS @25°C
1.) Input test pulse voltage: 3.2V
2.) Input pulse width: 50nS or 1.2x the total
delay (whichever is greater)
3.) Input rise time: 2.0nS (0.75V to 2.4V)
4.) Delay measured at 1.5V on leading edge
only with no loads on output (specify opt. T
for trailing edge design)
5.) Supply Voltage (Vcc): 5V
6.) Pulse spacing: 2x pulse width minimum
P/N DESIGNATION:
A01A
Type:
A01, A01S, A01AG, etc.
Options:
T, H, F, C, A, 39 (leave blank if std.)
Delay Time:
5nS, 10nS, etc
Packaging:
B=Bulk (Magazine tube is standard)
Termination:
W= Lead-free, Q= Tin/Lead
(leave blank if either is acceptable)
- 100nS - B W
RCD Components Inc.,
520 E. Industrial Park Dr., Manchester, NH, USA 03109
Tel: (603) 669-0054 Fax:(603) 669-5455 E-mail:sales@rcdcomponents.com
www.rcdcomponents.com
FA077 Sale of this product is in accordance with GF-061. Specifications subject to change without notice.
