CHIP COIL
LPC 12065
SPEER ELECTRONICS, INC.
WIRE WOUND SMT CHOKE COIL
CHIP COIL
- Small size allows for High Mounting Density
- Suitable for Reflow Solder
- Large DC Current capability with Low DC resistance
- Embossed Carrier Tape available
- Polarity Identification available
CHIP
INDUCTORS
- E - 6 Series of Values (customs available)
DIMENSIONS
DIMENSIONS
mm
in
L
12.4±0.2
.488
W
10.0±0.2
.393
H
7.5 max.
.295 max.
a
12.0±0.2
0.472
b
3.7±0.2
0.488
ORDERING & SPECIFYING INFORMATION*
LPC
Type
Wound
Wire Form
12065
Size Code
Core Diameter: 12 mm
Product Height: 12.4 mm
TE
Packaging
TE: Embossed Taping
No Designation: Bulk
331
Nominal Inductance
Example
331: 330
µ
H
K
Tolerance
K:
±10%
M:
±
20%
*Please Note: KSE’s Part Numbers Do Not Contain any Spaces or Hyphens.
TELEPHONE:
814-362-5536
54
FAX:
814-362-8883
CHIP COIL
LPC 12065
SPEER ELECTRONICS, INC.
WIRE WOUND SMT CHOKE COIL
STANDARD APPLICATIONS
ORDERING
CODE
LPC12065TE R68
LPC12065TE 1R0
LPC12065TE 1R5
LPC12065TE 2R2
LPC12065TE 3R3
LPC12065TE 4R7
LPC12065TE 6R8
LPC12065TE 100
LPC12065TE 150
LPC12065TE 220
LPC12065TE 330
LPC12065TE 470
LPC12065TE 680
LPC12065TE 101
LPC12065TE 151
LPC12065TE 221
LPC12065TE 331
LPC12065TE 471
LPC12065TE 681
LPC12065TE 102
LPC12065TE 152
LPC12065TE 222
LPC12065TE 332
LPC12065TE 472
LPC12065TE 682
INDUCTANCE
(µH)
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1,000
1,500
2,200
3,300
4,700
6,800
30
K(±10%)
15
20
M(±20%)
30
N(±30%)
40
INDUCTANCE
TOLERANCE
(%)
QUALITY
FACTOR
(MIN)
SELF
(MIN) (MHz)
77
60
47
38
30
24
19
15
12
9.5
7.5
6.2
4.9
4.0
3.2
2.5
2.0
1.6
1.3
1.0
0.83
0.67
0.53
0.43
0.34
DC
MAX. (Ω)
0.005
0.007
0.008
0.010
0.012
0.016
0.022
0.031
0.046
0.065
0.093
0.130
0.182
0.260
0.380
0.540
0.790
1.08
1.55
2.21
3.20
4.60
6.60
9.30
13.20
ALLOWABLE
MAX. (A)
10.0
9.50
9.00
8.00
6.50
5.40
4.50
3.63
3.00
2.40
2.05
1.70
1.38
1.14
0.94
0.77
0.65
0.53
0.44
0.35
0.29
0.23
0.19
0.16
100KHz
2.52 MHz
7.00
MEASURING
(Hz)
RESONANCE RESISTANCE DC CURRENT FREQUENCY
ENVIRONMENTAL & MECHANICAL CHARACTERISTICS
PARAMETER
High Temp. Exposure
Low Temp. Exposure
Moisture Exposure
Temperature Cycling
PERFORMANCE REQUIREMENT
±5%
±5%
±5%
±5%
TEST METHODS
+85°C, 500h
-40°C, 500h
+40°C, 90%~95%RH,500h
+40°C (30min.) /+85°C (30min.), 100 cycles
TELEPHONE:
814-362-5536
55
FAX:
814-362-8883
CHIP
INDUCTORS
Industrial Control Electronics
