1-phase filters
FN 610
General purpose EMI filter
n
n
n
n
Rated currents from 1 to 30A
Good overall differential and common-
mode attenuation
Optional medical versions (B type)
Optional safety versions (A type)
Approvals
Technical specifications
Maximum continuous operating voltage:
Operating frequency:
Rated currents:
High potential test voltage:
250VAC, 50/60Hz
dc to 400Hz
1 to 30A @ 40°C max.
P –> E 2000VAC for 2 sec
P –> E 2500VAC for 2 sec (B types)
P –> N 760VAC for 2 sec
-25°C to +100°C (25/100/21)
UL 94V-2 or better
UL 1283, CSA 22.2 No. 8 1986, IEC/EN 60939
1,200,000 hours
Typical electrical schematic
R
P
E
N
Line
Load
N‘
Cx
L
Cy
P‘
Temperature range (operation and storage):
Flammability corresponding to:
Design corresponding to:
MTBF @ 40°C/230V (Mil-HB-217F):
Features and benefits
n
Typical applications
n
FN 610 filters are designed for easy and
Multiple terminal connections like faston
n
n
n
n
n
n
Electrical and electronical equipment
Consumer goods
Household equipment
Medical equipment
Office automation equipment
Datacom equipment
fast chassis mounting.
n
with additional spade solder possibility,
wire connection and screw connection.
n
FN 610 filters offer a perfect combination
of performance/size ratio.
n
Optional safety (A type) or medical (B type)
All filters provide a good symmetrical and
versions with low leakage current.
n
asymmetrical attenuation performance,
based on chokes with high saturation
resistance and excellent thermal behavior.
n
FN 610 filters are also available as two-
stage filters (FN 660, FN 670 series).
n
Custom-specific versions on request.
General purpose filter attenuation perform-
ance suitable to be used in a broad range
of applications.
> Components
> FN 610
Filter selection table
Filter*
Rated current
@ 40°C (25°C)
[A]
1 (1.15)
3 (3.4)
6 (6.9)
10 (11.5)
20 (23)
30 (34)
1 (1.15)
3 (3.4)
6 (6.9)
10 (11.5)
1 (1.15)
3 (3.4)
6 (6.9)
10 (11.5)
20 (23)
Leakage current**
@ 230VAC/50Hz
[µA]
190
190
190
190
190
190
40
40
40
40
2
2
2
2
2
Inductance
L
[mH]
3
2
0.75
0.45
0.48
0.61
3
2
0.75
0.45
3
2
0.75
0.45
0.48
Capacitance
Cx
Cy
[nF]
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
[nF]
2.2
2.2
2.2
2.2
2.2
2.2
0.47
0.47
0.47
0.47
Resistance
R
[kΩ]
-06
-06
-06
-06
-06
-03
1000
1000
1000
1000
1000
1000
1000
1000
1000
-06
-06
-06
-06
-06
-06
-06
-06
-06
-07
-07
-07
-07
-07
-07
-07
-07
-07
-07
-07
-07
Input/Output
Weight
connections -03/-06 -07
[g]
55
60
60
85
220
630
55
60
60
85
55
60
60
85
220
[g]
65
70
70
95
FN 610-1-..
FN 610-3-..
FN 610-6-..
FN 610-10-..
FN 610-20-06
FN 610-30-03
FN 610A-1-..
FN 610A-3-..
FN 610A-6-..
FN 610A-10-..
FN
FN
FN
FN
FN
*
**
65
70
70
95
65
70
70
95
610B-1-..
610B-3-..
610B-6-..
610B-10-..
610B-20-06
To compile a complete part number, please replace the -.. with the required I/O connection style (e.g. FN 610-1-06, FN 610B-30-03).
Maximum leakage under normal operating conditions. Note: if the neutral line is interrupted, worst case leakage could reach twice this level.
Typical filter attenuation
Per CISPR 17; A = 50Ω/50Ω sym; B = 50Ω/50Ω asym; C = 0.1Ω/100Ω sym; D = 100Ω/0.1Ω sym
1 to 6A types
10 and 20A types
30A types
> Components
> FN 610
Mechanical data
Connection style -06, 1 to 10A types
B
E
H
I
BN
BN
P
Connection style -07, 1 to 10A types (same dimensions as style -06)
A F
N
K
D
G
J
GNYE BU
BU
O
L
M
C
Connection style -06, 20A types
B
E
H
I
Connection style -03, 30A types
B
E
Q
H
I
A F
N
D
G
J
M
A F D
N
G
J
K
L
C
K
L
M
C
Dimensions
1A
3A
6A
10A
20A
30A
Tolerances
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Connection style -03
N
Q
Connection style -07
O
P
AWG type wire
Wire length
64
35
19.3
43.5
32.5
54
21
9.3
15.3
16.25
5.3
6.3
0.7
6.3 x 0.8
64
35
19.3
43.5
32.5
54
21
9.3
15.3
16.25
5.3
6.3
0.7
6.3 x 0.8
64
35
19.3
43.5
32.5
54
21
9.3
15.3
16.25
5.3
6.3
0.7
6.3 x 0.8
64
35
29.3
43.5
32.5
54
21
9.3
15.3
16.25
5.3
6.3
0.7
6.3 x 0.8
71
52.6
29.3
50.5
50.5
61
21
14.3
20.3
25.25
5.3
6.3
0.7
6.3 x 0.8
105
126
38.6 ±1
84.5 ±1
98.5 ±1
95
40
19.6
10.1
42.25
4.4
6
1.2
±0.5
±0.5
±0.5
±0.3
±0.5
±0.2
±0.5
±0.5
±0.5
±0.5
M6
51
8.3
21.75
AWG 20
140
8.3
21.75
AWG 18
140
8.3
21.75
AWG 16
140
8.3
21.75
AWG 14
140
±0.1
±0.5
±0.5
±5
All dimensions in mm; 1 inch = 25.4mm
Tolerances according: ISO 2768 / EN 22768
Your local partner:
To find your local partner within Schaffner’s global network, please go to
www.schaffner.com
July 2007
