BEMG-4221/4222
NEW
Features
Energy Data Concentrator
with 6 x USB, 4 x COM/
8 x COM, 128 Devices
Motion Control
Onboard Intel
®
Atom™ N450/D510 1.67GHz processors
2 x 10/100/1000 Base-T RJ-45 port, 6 x USB 2.0 ports
2 x Mini PCIe slot with 1 x SIM slot support
Isolation between chassis and power ground
Supports wide operating temperatures from -10 ~ 70°C
Supports 8 x COM ports (BEMG-4222)
Built-in Windows
®
CE with WebAccess Energy Data Concentrator
Configured through web browser
Supports various protocol drivers to communicate with different devices
Support data transfer to Advantech BEMS
Hazardous Location
Energy Automation
Building Automation
Systems
Automation Software
BEMG-4221
BEMG-4222
Operator Panels
Introduction
BEMG-4221 and BEMG-4222 are powerful data concentrators bundled with SCADA software - WebAccess. With Intel Atom N450/D510 1.67GHz CPUs, Gigabit Ethernet ports, rich I/O,
and 2 x Mini PCIe socket. Both products have Energy Star certification, IP40 anti-dust ingress protection and wide operating temperatures (-10 ~ 70°C), providing high performance
and high versatility with low power consumption.
WebAccess communicates with automation equipment used in manufacturing facilities, industrial plants and building automation systems. The software acquire, display, monitor and
store real-time data and allows operators to change set-points, equipment status and other parameters in end-device.
Automation Panel PCs
Industrial Monitors
Specifications
General
Certification
Energy Star, CE, FCC Class A, UL, CCC,
C-Tick Class A, BSMI
Dimensions (W x D x H)
BEMG-4221: 255 x 152 x 50 mm (10' x 6.0' x 2.0")
BEMG-4222: 255 x 152 x 59 mm (10' x 6.0' x 2.3")
Enclosure
Aluminum +SECC
Mounting
DIN-rail, Wallmount, VESA
Industrial Grounding
Isolation between chassis and power ground
Power Consumption
BEMG-4221: 12W (Typical)
BEMG-4222: 16W (Typical)
Power Requirements
9 ~ 36 V
DC
(e.g +24 V @ 1.5 A) (Min. 36 W), ATX
Power Suspend Mode
S3, S4
Weight
2.5 kg
System Design
Fanless design with no internal cabling
Industrial Ethernet
I/O Interface
Serial Ports
BEMG-4221: 2 x RS-232/485 (COM1-2),
2 x RS-232/422/485 w/ 128kB FIFO
(COM A-B)
BEMG-4222: 2 x RS-232/485 (COM1-2),
2 x RS-232/422/485 w/ 128kB FIFO
(COM A-B),
4 x RS-232/485 from DB25 print port
(COM3-6)
50-115.2 kbps (COM 1-6 in RS-232/485 mode)
50-115.2 kbps (COM A/B in RS-232 mode)
50-921.6 kbps (COM A/B in RS-422/485 mode)
2 x 10/100/1000 Base-T RJ-45 port
(Built-in boot ROM in flash BIOS)
6 x USB 2.0
Line in, Line out, Mic in (5.1 channel HD audio)
Device Servers &
Gateways
Serial Communication
Cards
Serial Port Speed
LAN
USB Ports
Audio
Embedded Auto.
Computers
PACs
System Hardware
CPU
Memory
Indicators
Keyboard/Mouse
Storage
BEMG-4221: Intel
®
Atom™ D510 Dual Core 1.67GHz
BEMG-4222: Intel
®
Atom™ N450 1.67GHz
2 GB DDR2 SDRAM built-in
LEDs for Power, CF, LAN (Active, Status), Serial (Tx, Rx)
1 x PS/2
CF: 1 x front-accessible type I/II CompactFlash
®
slot
HDD: 1 x built-in 2.5" SATA HDD/SSD bracket
DB15 VGA connector
BEMG-4221 supports:1400 x 1050
BEMG-4222 supports: up to 2048 x 1536
Programmable 256 levels timer interval, from 1 to 255 sec
1 x Printer port (BEMG-4222)
Environment
Humidity
Operating Temperature
Ingress Protection
Shock Protection
Vibration Protection
95% @ 40°C (non-condensing)
IEC 60068-2-2 with 100% CPU/ I/O loading
-10 ~ 70°C (14 ~ 158°F)
IP40
IEC 60068-2-27
CompactFlash
®
: 50 G @ wall mount, half sine, 11 ms
HDD: 20 G @ wall mount, half sine, 11 ms
IEC 60068-2-64 (Random 1 Oct./min, 1hr/axis.)
CompactFlash
®
: 2 Grms @ 5 ~ 500 Hz,
HDD: 1 Grms @ 5 ~ 500 Hz
M2M I/O
Distributed Nano
Controllers
Display
Watchdog Timer
Printer Port
RS-485 I/O
Ordering Information
BEMG-4221-P21C-AE
BEMG-4222-P31C-AE
Energy Data Concentrator, Atom N450 1.67GHz, 2GB RAM
Energy Data Concentrator, Atom D510 1.67GHz, 2GB RAM
UNO-2000 series VESA mount kit
Mini PCIe card for WLAN
SMA/I-PEX cable 11CM
5dBi Dipole Antenna
Advantech Remote Monitoring & Diagnosis Utility
Ethernet I/O
Accessories
UNO-FPM21-AE
968EMW0021
1700001854
1750003222
PCLS-DIAGAW10
DAQ Boards
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Online Download
www.advantech.com/products
