F-210-1
LSEM–150–04.0–F–DV–A–N–K–TR
LSEM–120–06.0–F–DV–A–N–K–TR
TM
LSEM–120–01–L–DH–A–N–K–TR
(0,80mm) .0315"
LSEM SERIES
SYSTEM
HIGH SPEED HERMAPHRODITIC STRIP
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?LSEM
Insulator Material:
Black Liquid Crystal
Polymer
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27µm) Ni
Current Rating:
1.2A @ 95°C ambient
(6 positions powered)
Operating Temp Range:
-55°C to +125°C
RoHS Compliant:
Yes
Mates with:
LSEM
High Speed/High Density
Audible click when
properly mated
Low cost
Blade & Beam
contact
Self-mating
system can
reduce
inventory costs
Mated height
variety/flexibility
• High retention
contacts
• Audible click
when mated
• Shrouded
Processing:
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10mm) .004" max
Board Stacking:
For applications requiring more
than two connectors per board,
contact ipg@samtec.com
Optional Vertical or
Right Angle orientation
Slim
Row-to-Row
design
LSEM
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
TAIL
OPTION
A
N
K
TR
–K
APPLICATION
–F
= Gold flash
on contact,
Matte Tin on tail
20, 30, 40, 50
LSEM
MATED
HEIGHT
–DV
= Vertical
–L
=10µ" (0,25µm)
Gold on contact,
Matte Tin on tail
–DH
= Right Angle
(Lead style –01 only)
= (5,50mm)
.217" DIA
Polyimide
film Pick &
Place Pad
–TR
= Tape &
Reel
LEAD STYLE
MATED
HEIGHT*
(6,00) .236
(7,00) .276
(8,00) .315
(9,00) .354
(10,00) .394
(12,00) .472
–03.0 & –03.0
–03.0 & –04.0
–04.0 & –04.0
–03.0 & –06.0
–04.0 & –06.0
–06.0 & –06.0
LEAD
STYLE
No. of positions x
(0,80) .0315 + (4,40) .173
(-DH only)
A
NA
(4,45)
.175
(5,45)
.215
(7,45)
.293
B
NA
(1,50)
.059
(2,50)
.098
(4,50)
.177
–01
–03.0
–04.0
–06.0
No. of positions x
(0,80) .0315 + (4,40) .173
02
*Processing conditions will
affect mated height.
01
(0,80) .0315
01
(7,80) .307
(5,13)
.202
(4,98)
.196
A
B
No. of positions x
(0,80) .0315 + (1,70) .067
(0,85)
.033
(0,80) .0315
No. of positions x
(0,80) .0315 + (1,70) .067
02
(1,40)
.055
(1,32)
.052
DIA
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
–DH–N
–DV–N
WWW.SAMTEC.COM
