High Power DC-12GHz SPDT Switch
Elite
CS-32
Latching
The CS-32 is a broadband, SPDT Switch designed to switch microwave signals
from a common input to either of two outputs. Designed for 50 Ohms transmission
lines. The switch is available with either failsafe or latching type actuators operating
on 28 VDC or other special DC voltages. The primary advantages of this switch
over the miniature versions, shown on previous pages is the higher power handling
capability and additional connector options.
Specifications
RF Contacts:
Actuator
Switching Time:
Connectors:
Weight:
Shock:
Vibration:
Humidity:
Typical
Contact Life:
RF Power Handling
Break before make
Voltage (VDC) 20
O
C
Current (mA)
20 msec max
SMA, TNC, N Type
6 oz. max
MIL-STD-202 Method 213, Condition D (500G Non Operating)
MIL-STD-202 Method 214, Condition D (10G RMS Non Operating)
Moisture Seal Available
5
Million
Cycles
12
15
28
150 120 60
Temperature Range:
-55
O
C to +85
O
C (Operating)
3000
Hig
h
800
400
Typical Performance
cto
Sta
n
dar
d
Power CW (Watts)
NT
ype
rs
rs
Co
nne
200
cto
80
40
Return Loss
15
25
Po
we
r
Co
nne
10
0.01
0.1
1.0
4.0
Frequency GHz
10
18
26.5
Frequency GHz
12.0
Specifications
VSWR (max)
Insertion Loss (max)
Isolation (min)
*Connector
Type
SMA
N Type
TNC
DC-1 GHz 1-4 GHz
1.25:1
0.30 dB
70.0 dB
Max
(f)
12 GHz
11.5 GHz
11 GHz
1.40:1
0.40 dB
60.0 dB
4-12 GHz*
1.70:1
0.50 dB
60.0 dB
0.4
IL dB
0.01
Frequency GHz
12.0
Specifications subject to change without notice.
www.teledynecoax.com
email: coax@teledyne.com
Tel: (800) 351-7368
10/2008
Isolation dB
60
70
80
90
0.0
High Power DC-12GHz SPDT Switch
Elite
CS-32
Latching
Indicators
TTL
Analog
H = 1.70 MAX. STD MODEL
H = 2.30 MAX. TTL MODEL
H = 1.70 MAX. STD MODEL
H = 2.30 MAX. TTL MODEL
N Type Outline
TNC Outline
Part Numbering System for CS-32 (Latching)
CS-32 S 6 C - T
Series
Connectors
Actuator Voltage
Connector
N: N Type Female
T: TNC Female
Actuator Voltage
6: 28Vdc Latching
7: 15Vdc Latching
8: 12Vdc Latching
Actuator Type
O: No Indicator Contacts
C: Indicator Contacts
D: Self Cutoff Only
E: Indicators and Self
Cutoff
Options
T: TTL Drivers with Diodes
R: Positive + Common
Options
Actuator Type
For other options contact Factory
Specifications subject to change without notice.
www.teledynecoax.com
email: coax@teledyne.com
Tel: (800) 351-7368
10/2008
